| Item | Specification | ||
|---|---|---|---|
| Model | Radio/CD/MP3 (PA710) | Radio/CD/MP3/Sirius (PA710S) | |
| Power supply | DC 14.4V | ||
| Rated output | Max 43W x 4 | ||
| Speaker impedance | 4ohms x 4 | ||
| Antenna | 80PF 75ohms | ||
| Tuning type | PLL synthesized type | ||
| Frequency range/Channel space | FM | 87.5~107.9 MHz/200KHz | |
| AM | 530~1710 KHz/10KHz | ||
AUDIO SPECIFICATION CHART
Description
The AUX, IPOD and USB JACK on the center console is for customers who like to listen to external portable music players like the MP3, iPOD, USB memory stick, CD player and etc., through the vehicle's sound system when it is linked to this jack. The customer has this added option.
If audio distortion is present, check the volume settings on the device connected to Aux jack.
Scheme 1
Scheme 2
Scheme 3
- Disconnect the negative(-) battery terminal.
- After removing the console switch assembly (A), disconnect the connector.
- Remove the console upper cover (A).
- Remove the multimedia jack from the console upper cover after disconnecting the jack connector and loosening 2 screws.
- Installation is the reverse of removal.
Introduction to SIRIUS radio
SIRIUS-Radio is a Satellite Based Radio Broadcast System that operates around 2.3 GHz from two 15,000 watts satellites; The service covers US and Canada. But the service in Canada is not guaranteed.
Due to the limitations of satellite transmission, the signal is not able to penetrate buildings, so it cannot effectively cover dense urban areas. The terrestrial repeater network extends SDARS coverage and allows providers to reach the greatest number of subscribers and provide quality coverage. The repeaters receive the SIRIUS signal directly from the satellites and then re-transmit it to SIRIUS radios anywhere.
SIRIUS provides digitalized radio programs in terms of channels. Each channel is a program that the user can tune to. A category is a group of channels. Examples of categories are classical, news and sports.
SIRIUS is a paid service. That means users have to make a subscription to SIRIUS before they can enjoy the programs. However, SIRIUS does give some free-to-air channels. The users can listen to one of them without making any subscription.
Scheme 4
