Smart Key Code Saving (Button) Diagnosis - Hev: Diagnosis Kia Optima III

DTC

DTC

Scheme 613

DTC Detecting Condition

Scheme 614

Scheme 615

Scheme 616

1. IG KEY "ON" & Engine "OFF".
2. Erase DTC after connecting GDS.
3. Check Smart key status if DTC is retrieved.
4. Is the Smart key PCM learnt status? YES Fault is intermittent caused by poor contact in Smart key PCM and/or PCM's connector or was repaired and Smart key PCM memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(ref-535822-S26803027152013031200000) " procedure. NO Go to " «COMPONENT INSPECTION»(ref-535822-S24716997862013031200000) " procedure.

Inspection Repair

1. Check Smart Key PCM Inspection IG KEY "ON" & Engine "OFF". Neutralize smart key PCM with GDS. Perform key teaching procedure for smart key PCM with GDS. CAUTION: Pin code must be prepared to Neutralize Smart Key PCM and to perform key teaching procedure. Is the neutralization of Smart Key PCM, Engine PCM and key teaching normal? YES Fault is intermittent caused by poor contact in Smart Key PCM and/or PCM's connector or was repaired and Smart key PCM memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(ref-535822-S26803027152013031200000) " procedure. NO Substitute with a known-good Smart Key PCM and check for proper operation. If the problem is corrected, replace Smart Key PCM and then go to " «VERIFICATION OF VEHICLE REPAIR»(ref-535822-S26803027152013031200000) " procedure. NOTE: PIN code is programmed in Smart key PCM, Transponder, FOB. If the Smart key PCM is not registered with PIN, key teaching process is not proceeded. Registering PIN is available after Smart Key PCM is neutralized. Neutralization of Engine PCM is available with GDS. (Registering PIN code) If the virgin engine PCM is installed on vehicle, Engine PCM is automatically programmed PIN code by Smart Key PCM. Registering PIN code is only possible for virgin or neutralized status. It is possible to access to All of the learning procedure only with GDS. And, FOB key must be inserted in FOB holder in order to proceed learning procedure. (There is only one menu for registering Smart key on the GDS that makes registering all of the component. In case of replacing each module, New registration should be done with GDS) Smart Key PCM Learning Before learning procedure for FOB Key, Smart Key PCM should be registered PIN code first. In case of replacing Smart Key PCM, All of the keys should be newly registered again. In case that Smart Key PCM receives 3 times with wrong PIN, It is not allowed for neutralization and Key Teaching for 1 hour. If the battery is discharged during neutralization or Teaching, Timer will start again from beginning. Therefore, it is avoidable to wail for 1 hour.

Scheme 617

Scheme 618

Scheme 619

1. IG KEY "ON" & Engine "OFF".
2. Erase DTC after connecting GDS.
3. Check Smart Key PCM status parameter if DTC is retrieved.
4. Is the smart Key PCM learnt? YES Fault is intermittent caused by poor contact in Smart key PCM and/or PCM's connector or was repaired and Smart key PCM memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(ref-535822-S10958081932013031200000) " procedure. NO Go to " «WIRE HARNESS INSPECTION»(ref-535822-S39139892022013031200000) " procedure.

Terminal and Connector Inspection

1. Many malfunctions in the electrical system are caused by poor harness and terminal connections. Faults can also be caused by interference from other electrical systems, and mechanical or chemical damage.
2. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage.
3. Has a problem been found? YES Repair as necessary and go to " «VERIFICATION VEHICLE REPAIR»(ref-535822-S10958081932013031200000) " procedure. NO Go to " «SIGNAL CIRCUIT INSPECTION»(ref-535822-S35096076732013031200000) " procedure.

Scheme 620

Scheme 621

1. IG KEY OFF.
2. Disconnect Engine PCM connector.
3. IG KEY "ON"
4. Measure voltage between signal terminal of PCM harness connector and chassis ground. Specification: About 12V
5. Is the measured voltage within specification? YES Go to " «COMPONENT INSPECTION»(ref-535822-S24716997862013031200000) " procedure. NO Check open or short to signal circuit and then, go to " «VERIFICATION OF VEHICLE REPAIR»(ref-535822-S10958081932013031200000) " procedure.

Component Inspection

1. Check Smart Key PCM inspection IG KEY "ON" & Engine "OFF". Neutralize smart key PCM with GDS. Perform key teaching procedure for smart key PCM with GDS. CAUTION: Pin code must be prepared to Neutralize Smart Key PCM and to perform key teaching procedure. Is the neutralization of Smart Key PCM, Engine PCM and key teaching normal? YES Fault is intermittent caused by poor contact in Smart Key PCM and/or PCM's connector or was repaired and Smart key PCM memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(ref-535822-S10958081932013031200000) " procedure. NO Substitute with a known-good Smart Key PCM and check for proper operation. If the problem is corrected, replace Smart Key PCM and then go to " «VERIFICATION OF VEHICLE REPAIR»(ref-535822-S10958081932013031200000) " procedure. NOTE: PIN code is programmed in Smart key PCM, Transponder, FOB. If the Smart key PCM is not registered with PIN, key teaching process is not proceeded. Registering PIN is available after Smart Key PCM is neutralized. Neutralization of Engine PCM is available with GDS. (Registering PIN code) If the virgin engine PCM is installed on vehicle, Engine PCM is automatically programmed PIN code by Smart Key PCM. Registering PIN code is only possible for virgin or neutralized status. It is possible to access to All of the learning procedure only with GDS. And, FOB key must be inserted in FOB holder in order to proceed learning procedure. (There is only one menu for registering Smart key on the GDS that makes registering all of the component. In case of replacing each module, New registration should be done with GDS) Smart Key PCM Learning Before learning procedure for FOB Key, Smart Key PCM should be registered PIN code first. In case of replacing Smart Key PCM, All of the keys should be newly registered again. In case that Smart Key PCM receives 3 times with wrong PIN, It is not allowed for neutralization and Key Teaching for 1 hour. If the battery is discharged during neutralization or Teaching, Timer will start again from beginning. Therefore, it is avoidable to wail for 1 hour.

Scheme 622

Scheme 623

Scheme 624

Scheme 625

1. IG KEY "ON" & Engine "OFF".
2. Connect GDS and select ID Register.
3. Check Engine status parameter with GDS.
4. Is the PCM status normal? YES Neutralize the Engine PCM after erasing the DTC with GDS. Check that system is normal after checking the DTC again. (If the DTC is set again, replace Engine PCM) Wait for more than 1 min. with IG ON so that smart key PCM register PIN into Engine PCM automatically. NO Perform key teaching procedure after replacing PCM and then, go to " «VERIFICATION OF VEHICLE REPAIR»(ref-535822-S05763074992013031200000) " Procedure. NOTE: PIN code is programmed in Smart key PCM, Transponder, FOB. If the Smart key PCM is not registered with PIN, key teaching process is not proceeded. Registering PIN is available after Smart Key PCM is neutralized. Neutralization of Engine PCM is available with GDS. (Registering PIN code) If the virgin engine PCM is installed on vehicle, Engine PCM is automatically programmed PIN code by Smart Key PCM. Registering PIN code is only possible for virgin or neutralized status. It is possible to access to All of the learning procedure only with GDS. And, FOB key must be inserted in FOB holder in order to proceed learning procedure. (There is only one menu for registering Smart key on the GDS that makes registering all of the component. In case of replacing each module, New registration should be done with GDS) Smart Key PCM Learning Before learning procedure for FOB Key, Smart Key PCM should be registered PIN code first. In case of replacing Smart Key PCM, All of the keys should be newly registered again. In case that Smart Key PCM receives 3 times with wrong PIN, It is not allowed for neutralization and Key Teaching for 1 hour. If the battery is discharged during neutralization or Teaching, Timer will start again from beginning. Therefore, it is avoidable to wail for 1 hour.

Scheme 626

Scheme 627

Scheme 628

1. IG KEY "ON" & Engine "OFF".
2. Erase DTC after connecting GDS.
3. Check Smart Key PCM status parameter if DTC is retrieved.
4. Is the smart Key PCM learnt? YES Fault is intermittent caused by poor contact in Smart key PCM and/or PCM's connector or was repaired and Smart key PCM memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(ref-535822-S29497811252013031200000) " procedure. NO Go to " «COMPONENT INSPECTION»(ref-535822-S01062222742013031200000) " procedure.

1. Check Smart Key PCM inspection IG KEY "ON" & Engine "OFF". Neutralize smart key PCM with GDS. Perform key teaching procedure for smart key PCM with GDS. CAUTION: Pin code must be prepared to Neutralize Smart Key PCM and to perform key teaching procedure. Is the neutralization of Smart Key PCM, Engine PCM and key teaching normal? YES Fault is intermittent caused by poor contact in Smart Key PCM and/or PCM's connector or was repaired and Smart key PCM memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(ref-535822-S29497811252013031200000) " procedure. NO Substitute with a known-good Smart Key PCM and check for proper operation. If the problem is corrected, replace Smart Key PCM and then go to " «VERIFICATION OF VEHICLE REPAIR»(ref-535822-S29497811252013031200000) " procedure. NOTE: PIN code is programmed in Smart key PCM, Transponder, FOB. If the Smart key PCM is not registered with PIN, key teaching process is not proceeded. Registering PIN is available after Smart Key PCM is neutralized. Neutralization of Engine PCM is available with GDS. (Registering PIN code) If the virgin engine PCM is installed on vehicle, Engine PCM is automatically programmed PIN code by Smart Key PCM. Registering PIN code is only possible for virgin or neutralized status. It is possible to access to All of the learning procedure only with GDS. And, FOB key must be inserted in FOB holder in order to proceed learning procedure. (There is only one menu for registering Smart key on the GDS that makes registering all of the component. In case of replacing each module, New registration should be done with GDS) Smart Key PCM Learning Before learning procedure for FOB Key, Smart Key PCM should be registered PIN code first. In case of replacing Smart Key PCM, All of the keys should be newly registered again. In case that Smart Key PCM receives 3 times with wrong PIN, It is not allowed for neutralization and Key Teaching for 1 hour. If the battery is discharged during neutralization or Teaching, Timer will start again from beginning. Therefore, it is avoidable to wail for 1 hour.

Scheme 629

Scheme 630

Scheme 631

1. IG KEY "ON" & Engine "OFF".
2. Connect GDS and select ID Register.
3. Check Engine status parameter with GDS.
4. Is the PCM status displayed "Lock"? YES Wait for 1 hour until PCM status is unlock with IG ON. After PCM status is unlock, perform the key teaching procedure. Finally, go to " «VERIFICATION OF VEHICLE REPAIR»(ref-535822-S29625276262013031200000) " procedure. NO Fault is intermittent caused by poor contact in Smart Key PCM and/or PCM's connector or was repaired and Smart key PCM memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(ref-535822-S29625276262013031200000) " procedure. NOTE: PIN code is programmed in Smart key PCM, Transponder, FOB. If the Smart key PCM is not registered with PIN, key teaching process is not proceeded. Registering PIN is available after Smart Key PCM is neutralized. Neutralization of Engine PCM is available with GDS. (Registering PIN code) If the virgin engine PCM is installed on vehicle, Engine PCM is automatically programmed PIN code by Smart Key PCM. Registering PIN code is only possible for virgin or neutralized status. It is possible to access to All of the learning procedure only with GDS. And, FOB key must be inserted in FOB holder in order to proceed learning procedure. (There is only one menu for registering Smart key on the GDS that makes registering all of the component. In case of replacing each module, New registration should be done with GDS) Smart Key PCM Learning Before learning procedure for FOB Key, Smart Key PCM should be registered PIN code first. In case of replacing Smart Key PCM, All of the keys should be newly registered again. In case that Smart Key PCM receives 3 times with wrong PIN, It is not allowed for neutralization and Key Teaching for 1 hour. If the battery is discharged during neutralization or Teaching, Timer will start again from beginning. Therefore, it is avoidable to wail for 1 hour.
