Electronic Stability Control System Diagnosis - Except Hev: Specifications Kia Optima III

Anti-Lock/traction Control 32 illustrations ~513 words

Specification

Normal Voltage RangeENG "ON"
10V ~ 16V

VOLTAGE SPECIFICATIONS

Scheme 50

Scheme 50: Diagnostic Circuit Diagram
Scheme 50: Diagnostic Circuit Diagram

Scheme 51

Scheme 51: Monitor GDS Data
Scheme 51: Monitor GDS Data
  1. Connect GDS to Data Link Connector (DLC).
  2. Ignition "ON" & Engine "ON".
  3. Monitor the "BATTERY VOLTAGE" parameter on the GDS. Specification : Below. 17.5V
  4. Is parameter displayed within specifications? YES Fault is intermittent caused by poor connection in power harness (IGN+) and/or HECU's connector or was repaired and HECU memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair or replace as necessary and then go to «VERIFICATION OF VEHICLE REPAIR»(ref-429651-S07222644072011101500000) procedure. NO Go to «TERMINAL AND CONNECTOR INSPECTION»(ref-429651-S06444748522011101500000) procedure.
Normal Voltage RangeENG "ON"
10V ~ 16V

VOLTAGE SPECIFICATIONS

Scheme 52

Scheme 52: Diagnostic Circuit Diagram
Scheme 52: Diagnostic Circuit Diagram

Scheme 53

Scheme 53: Monitor GDS Data
Scheme 53: Monitor GDS Data
  1. Connect GDS to Data Link Connector (DLC).
  2. IG "ON".
  3. Monitor the "BATTERY VOLTAGE" parameter on the GDS. Specification : Above. 9 ± 0.5V
  4. Is parameter displayed within specifications? YES Fault is intermittent caused by poor connection in power harness (IGN+) and/or HECU's connector or was repaired and HECU memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair or replace as necessary and then go to «VERIFICATION OF VEHICLE REPAIR»(ref-429651-S41758521972011101500000) procedure. NO Go to «TERMINAL AND CONNECTOR INSPECTION»(ref-429651-S25569257992011101500000) procedure.
Sensor TypeOutput VoltageAir Gap
HIGHLOW
Active Type1.4V0.7V0.4~1.5 mm

WHEEL SPEED SENSOR SPECIFICATIONS

Scheme 54

Scheme 54: Diagnostic Circuit Diagram
Scheme 54: Diagnostic Circuit Diagram

Scheme 55

Scheme 55: Signal Waveform
Scheme 55: Signal Waveform
Sensor TypeOutput VoltageAir Gap
HIGHLOW
Active Type1.4V0.7V0.4~1.5 mm

WHEEL SPEED SENSOR SPECIFICATIONS

Scheme 56

Scheme 56: Diagnostic Circuit Diagram
Scheme 56: Diagnostic Circuit Diagram

Scheme 57

Scheme 57: Signal Waveform
Scheme 57: Signal Waveform
Sensor TypeOutput VoltageAir Gap
HIGHLOW
Active Type1.4V0.7V0.4~1.5 mm

WHEEL SPEED SENSOR SPECIFICATIONS

Scheme 58

Scheme 58: Diagnostic Circuit Diagram
Scheme 58: Diagnostic Circuit Diagram

Scheme 59

Scheme 59: Signal Waveform
Scheme 59: Signal Waveform
Sensor TypeOutput VoltageAir Gap
HIGHLOW
Active Type1.4V0.7V0.4~1.5 mm

WHEEL SPEED SENSOR SPECIFICATIONS

Scheme 60

Scheme 60: Diagnostic Circuit Diagram
Scheme 60: Diagnostic Circuit Diagram

Scheme 61

Scheme 61: Signal Waveform
Scheme 61: Signal Waveform
Sensor TypeOutput VoltageAir Gap
HIGHLOW
Active Type1.4V0.7V0.4~1.5 mm

WHEEL SPEED SENSOR SPECIFICATIONS

Scheme 62

Scheme 62: Diagnostic Circuit Diagram
Scheme 62: Diagnostic Circuit Diagram

Scheme 63

Scheme 63: Signal Waveform
Scheme 63: Signal Waveform
Sensor TypeOutput VoltageAir Gap
HIGHLOW
Active Type1.4V0.7V0.4~1.5 mm

WHEEL SPEED SENSOR SPECIFICATIONS

Scheme 64

Scheme 64: Diagnostic Circuit Diagram
Scheme 64: Diagnostic Circuit Diagram

Scheme 65

Scheme 65: Signal Waveform
Scheme 65: Signal Waveform
Sensor TypeOutput VoltageAir Gap
HIGHLOW
Active Type1.4V0.7V0.4~1.5 mm

WHEEL SPEED SENSOR SPECIFICATIONS

Scheme 66

Scheme 66: Diagnostic Circuit Diagram
Scheme 66: Diagnostic Circuit Diagram

Scheme 67

Scheme 67: Signal Waveform
Scheme 67: Signal Waveform
Sensor TypeOutput VoltageAir Gap
HIGHLOW
Active Type1.4V0.7V0.4~1.5 mm

WHEEL SPEED SENSOR SPECIFICATIONS

Scheme 68

Scheme 68: Diagnostic Circuit Diagram
Scheme 68: Diagnostic Circuit Diagram

Scheme 69

Scheme 69: Signal Waveform
Scheme 69: Signal Waveform
Sensor TypeOutput VoltageAir Gap
HIGHLOW
Active Type1.4V0.7V0.4~1.5 mm

WHEEL SPEED SENSOR SPECIFICATIONS

Scheme 70

Scheme 70: Diagnostic Circuit Diagram
Scheme 70: Diagnostic Circuit Diagram

Scheme 71

Scheme 71: Signal Waveform
Scheme 71: Signal Waveform
Sensor TypeOutput VoltageAir Gap
HIGHLOW
Active Type1.4V0.7V0.4~1.5 mm

WHEEL SPEED SENSOR SPECIFICATIONS

Scheme 72

Scheme 72: Diagnostic Circuit Diagram
Scheme 72: Diagnostic Circuit Diagram

Scheme 73

Scheme 73: Signal Waveform
Scheme 73: Signal Waveform
Sensor TypeOutput VoltageAir Gap
HIGHLOW
Active Type1.4V0.7V0.4~1.5 mm

WHEEL SPEED SENSOR SPECIFICATIONS

Scheme 74

Scheme 74: Diagnostic Circuit Diagram
Scheme 74: Diagnostic Circuit Diagram

Scheme 75

Scheme 75: Signal Waveform
Scheme 75: Signal Waveform
Sensor TypeOutput VoltageAir Gap
HIGHLOW
Active Type1.4V0.7V0.4~1.5 mm

WHEEL SPEED SENSOR SPECIFICATIONS

Scheme 76

Scheme 76: Diagnostic Circuit Diagram
Scheme 76: Diagnostic Circuit Diagram

Scheme 77

Scheme 77: Signal Waveform
Scheme 77: Signal Waveform
Engine ONESC switch HIGHESC switch LOW
7.0V ~ 16.0V0V ~ 3.0V

ESC SWITCH SPECIFICATIONS

Scheme 78

Scheme 78: Diagnostic Circuit Diagram
Scheme 78: Diagnostic Circuit Diagram

Scheme 79

Scheme 79: Monitor GDS Data
Scheme 79: Monitor GDS Data
  1. Connect GDS to Data Link Connector (DLC).
  2. IG "ON".
  3. Press the ESC (ESP) SWITCH.
  4. Monitor the "ESC (ESP) Off Switch" parameter on the GDS. Specification : ESC (ESP) switch parameter changed ON / OFF starts.
  5. Whenever the switch is pushed up/down, is the ESC (ESP) off switch's GDS data changed ON/OFF? YES Fault is intermittent caused by poor connection in ESC (ESP) switch line or was repaired and HECU memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair or replace as necessary and then go to «VERIFICATION OF VEHICLE REPAIR»(ref-429651-S22084209472011101500000) procedure. NO Go to «TERMINAL AND CONNECTOR INSPECTION»(ref-429651-S06733214262011101500000) procedure.
Brake Light SwitchVoltage Range of "High"Voltage Range of "Low"
7.0V ~ 16.0V0V ~ 3V

BRAKE LIGHT SWITCH SPECIFICATIONS

Scheme 80

Scheme 80: Diagnostic Circuit Diagram
Scheme 80: Diagnostic Circuit Diagram

Scheme 81

Scheme 81: Monitor GDS Data
Scheme 81: Monitor GDS Data
  1. Connect scantool to Data Link Connector (DLC)
  2. IG "ON".
  3. Press the brake pedal.
  4. Monitor the "Brake Light Switch" parameter on the GDS.
  5. Whenever Brake pedal is pushed down, is the brake lamp switch's GDS data changed ON/OFF? YES Fault is intermittent caused by poor connection in brake light switch line and/or HECU's connector or was repaired and HECU memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair or replace as necessary and then go to «VERIFICATION OF VEHICLE REPAIR»(ref-429651-S35734884402011101500000) procedure. NO Go to «TERMINAL AND CONNECTOR INSPECTION»(ref-429651-S39095684032011101500000) procedure.
