Electronic Stability Control (Esc) System - Except Hev: Specifications Kia Optima III

Anti-Lock/traction Control 2 illustrations

Specifications

DescriptionSpecificationRemarks
Operating voltage10 ~ 16V
Output signalCAN Interface
Operating temperature40 ~ 85°C (-40 ~ 185°F)
Yaw-rate sensorMeasurement range75 ~ 75°/sec
Frequency response15 ~ 45Hz
Lateral G sensorMeasurement range14.715 ~ +14.715g
Frequency response50Hz ± 60%

YAW-RATE AND LATERAL G SENSOR SPECIFICATIONS

Scheme 1

Scheme 1: External Diagram
Scheme 1: External Diagram

Scheme 2

Scheme 2: Removal
Scheme 2: Removal
  1. Turn ignition switch OFF and disconnect the negative (-) battery cable.
  2. Remove the floor console. Refer to «CONSOLE»(ref-429563-S42679254862011101500000) .
  3. Disconnect the yaw rate & lateral G sensor connector (A).
  4. Remove the mounting bolts (B). Tightening torque: 3.9 ~ 5.9 N.m (0.4 ~ 0.6 kgf.m, 2.9 ~ 4.3 lb-ft)
  5. Installation is the reverse of removal.
