SPECIAL TOOLS

SPECIAL TOOLS SPECIFICATION Tool (Number and Name) Illustration Use 09222-32100 Valve stem oil seal installer Installation of the oil pump oil seal 09555-21000 Bar Removal and installation of the oil seal (Use with 09573-33100, 09573-33000,09573- 21000) 09561-11001 Steering wheel puller Removal of steering wheel 09568-34000 Ball joint puller Separation of the tie rod end bail joint 09572-21000 Oil pressure gauge Measurement of the oil pressure (Use with 09572-22100, 09572-21200) 09572-21200 Oil pressure gauge adapter Measurement of the oil pressure (Use with 09572-21000, 09572-22100) 09572-22100 Oil pressure gauge adapter Measurement of the oil pressure (Use with 09572-21000, 09572-21200) 09573-21100 Oil seal installer Installation of the back up washer and oil seal (Use with 09753-21000,09573-33100, 09555-21000) 09573-33100 Oil seal guide Removal and installation of the oil seal (Use with 09573-21000, 09573-33000,09555- 21000) 09432-21600 Bearing installer Installing the pinion gear bearing 09434-14200 Counter shaft bearing installer Installing the gear box oil seal 09565-11100 Preload socket Measuring the pinion shaft preload

Scheme 4

Scheme 5

Scheme 6

Scheme 7

1. Start the engine and with the steering wheel in the straight ahead position.
2. Measure the play while turning the steering wheel to the left and right. Standard value : Steering wheel free play : 30 mm (1.2 in)
3. If the play exceeds the standard value, inspect the connection between the steering shaft and tie rod ends.
