Srscm: Removal & Installation Kia Optima II рестайлинг

Airbag 10 illustrations ~644 words

Installation

  1. Disconnect the battery negative cable and wait for at least three minutes before beginning work.
  2. Remove the ignition key from the vehicle.
  3. Install the SRSCM with the SRSCM mounting nuts. Tightening torque : 1.0 ~ 1.4 kgf.m (10.2 ~ 13.8 Nm, 7.5 ~ 10.2 lb.ft) NOTE: Use new mounting nuts when replacing the SRSCM after a collision.
  4. Connect the SRSCM harness connector.
  5. Install the heater ducts and floor console. (Refer to «FLOOR CONSOLE REPLACEMENT»(ref-357465-S35635903022010032300000) )
  6. Connect the DAB, PAB, SAB, CAB and BPT connectors.
  7. Reconnect the battery negative cable.
  8. After installing the SRSCM, confirm proper system operation: Turn the ignition switch ON; the SRS indicator light should be turned on for about six seconds and then go off.

Removal

CAUTIONRemoval of the airbag must be performed according to the precautions/procedures described previously. Before disconnecting the front impact sensor connector, disconnect the front airbag connector(s). Do not turn the ignition switch ON and do not connect the battery cable while replacing the front impact sensor.

Scheme 30

Scheme 30
Scheme 30
  1. Disconnect the battery negative cable, and wait for at least three minutes before beginning work.
  2. Remove the front bumper. (Refer to «BUMPER»(ref-357475) )
  3. Disconnect the Front Impact Sensor connector.
  4. Remove the Front Impact Sensor mounting bolt and sensor bracket cover.
  5. Remove the Front Impact Sensor.

Scheme 31

Scheme 31
Scheme 31
CAUTIONDo not turn the ignition switch ON and do not contact the battery cable while replacing the front impact sensor.
  1. Install the new Front Impact Sensor and sensor bracket cover.
  2. Tighten the Front Impact Sensor mounting bolt. Tightening torque : 1.0 ~ 1.4 kgf.m (10.2 ~ 13.8 Nm, 7.5 ~ 10.2 lb.ft)
  3. Install the front bumper. (Refer to «BUMPER»(ref-357475) )
  4. Reconnect the battery negative cable.
  5. After installing the Front Impact Sensor, confirm proper system operation: Turn the ignition switch ON the SRS indicator light should be turned on for about six seconds and then go off.
  1. Disconnect the battery negative cable, and wait for at least three minutes before beginning work.
  2. Remove the front seat assembly. (Refer to «FRONT SEAT»(ref-357476-S25755551612010032300000) )
  3. Disconnect the STPS connector and loosen the two STPS screws.

Scheme 32

Scheme 32
Scheme 32
CAUTIONEnsure that the harness is installed and routed properly to prevent damage to the wiring.

Scheme 33

Scheme 33
Scheme 33
  1. Disconnect the battery negative cable, and wait for at least three minutes before beginning work.
  2. Remove the ignition key from the vehicle.
  3. Install the STPS with two screws.
  4. Install the front seat assembly. (Refer to «FRONT SEAT»(ref-357476-S25755551612010032300000) )
  5. Reconnect the battery negative cable.
  6. After installing the Seat Track Position Sensor, confirm proper system operation: Turn the ignition switch ON, the SRS indicator should be turned on for about six seconds and then go off.
  1. Disconnect the battery negative cable, and wait for at least three minutes before beginning work.
  2. Remove the front seat assembly. (Refer to «FRONT SEAT»(ref-357476-S25755551612010032300000) )
  3. Remove the seat recliner cover.
  4. Loosen the seat belt buckle mounting bolt and remove the seat belt buckle switch.

Scheme 34

Scheme 34
Scheme 34
CAUTIONEnsure that the harness is installed and routed properly to prevent damage to the wiring.
  1. Disconnect the battery negative cable, and wait for at least three minutes before beginning work.
  2. Remove the ignition key from the vehicle.
  3. Install the seat belt buckle switch. Tightening Torque : 4.0 ~ 5.5 kgf.m (28.9 ~ 39.8 lb.ft)
  4. Install the seat recliner cover with two screws.
  5. Install the front seat assembly. (Refer to «FRONT SEAT»(ref-357476-S25755551612010032300000) )
  6. Reconnect the battery negative cable.
  7. After installing the Seat Belt Buckle Switch, confirm proper system operation: Turn the ignition switch ON, the SRS indicator should be turned on for about six seconds and then go off.
  1. Disconnect the battery negative cable, and wait for at least three minutes before beginning work.
  2. Remove the front seat assembly. (Refer to «FRONT SEAT»(ref-357476-S25755551612010032300000) )
  3. Remove the seat cushion covering, cushion PAD and OCS.
  1. Install the OCS equipped seat cushion.(Refer to «SEAT & POWER SEAT»(ref-357476) )
  2. Install the front seat assembly.
  3. Reconnect the battery negative cable.
  4. After installing the OCS, confirm proper system operation : Turn the ignition switch ON, the SRS indicator should be turned on for about six seconds and then go off. Telltale lamp will turn on for 4 seconds and be turned off for 3 seconds. After the 7 seconds, it shall remain off if the OCS does not require suppression and the passenger airbag is enabled.

Scheme 35

Scheme 35: Circuit Diagram (1)
Scheme 35: Circuit Diagram (1)

Scheme 36

Scheme 36
Scheme 36

Scheme 37

Scheme 37: Circuit Diagram (2)
Scheme 37: Circuit Diagram (2)

SRSCM Harness Connector [Advanced]

Scheme 38

Scheme 38: SRSCM Connector Terminal
Scheme 38: SRSCM Connector Terminal
PinFunction (Connector A)PinFunction (Connector B)
1Driver Airbag High (1st stage)1Side Airbag [Driver] High
2Driver Airbag Low (1st stage)2Side Airbag [Driver] Low
3Passenger Airbag High (1st stage)3Curtain Airbag [Driver] High
4Passenger Airbag Low (1st stage)4Curtain Airbag [Driver] Low
5Driver Airbag High (2nd stage)5Curtain Airbag [Passenger] High
6Driver Airbag Low (2nd stage)6Curtain Airbag [Passenger] Low
77
88
99
1010
11K-Line Diagnostic11
12Ignition12
13Passenger Airbag High (2nd stage)13Side Impact Sensor [Rear-Driver] High
14Passenger Airbag Low (2nd stage)14Side Impact Sensor [Rear-Driver] Low
15Airbag Warning Lamp15Side Impact Sensor [Rear-Passenger] High
16Ground16Side Impact Sensor [Rear-Passenger] Low
17Crash Output17Occupant Classification
1818
19Telltale Lamp19Front Impact Sensor High
2020Front Impact Sensor Low
2121Side Airbag [Passenger] High
2222Side Airbag [Passenger] Low
2323Seat Track Position Sensor [Driver]
2424
25Seat Belt Buckle Switch [Driver]
26Seat Belt Buckle Switch [Passenger]
27Side Impact Sensor [Front-Driver] High
28Side Impact Sensor [Front-Driver] Low
29Side Impact Sensor [Front-Passenger] High
30Side Impact Sensor [Front-Passenger] Low
31Seat Belt Pretensioner [Driver] High
32Seat Belt Pretensioner [Driver] Low
33Seat Belt Pretensioner [Passenger] High
34Seat Belt Pretensioner [Passenger] Low
35
36
37
38
39
40

CONNECTOR PIN REFERENCE CHART

Scheme 39

Scheme 39: SRSCM Harness Connector [Depowered]
Scheme 39: SRSCM Harness Connector [Depowered]
PinFunction (Connector A)PinFunction (Connector B)
1Driver Airbag High1Side Airbag [Driver] High
2Driver Airbag Low2Side Airbag [Driver] Low
3Passenger Airbag High3Curtain Airbag [Driver] High
4Passenger Airbag Low4Curtain Airbag [Driver] Low
55Curtain Airbag [Passenger] High
66Curtain Airbag [Passenger] Low
77~12
813Side Impact Sensor [Rear-Driver] High
914Side Impact Sensor [Rear-Driver] Low
1015Side Impact Sensor [Rear-Passenger] High
11K-Line Diagnostic16Side Impact Sensor [Rear-Passenger] Low
12Ignition17
1318
1419Front Impact Sensor High
15Airbag Warning Lamp20Front Impact Sensor Low
16Ground21Side Airbag [Passenger] High
17CrashOutput22 Side Airbag [Passenger] Low
1823~26
1927Side Impact Sensor [Front-Driver] High
2028Side Impact Sensor [Front-Driver] Low
2129Side Impact Sensor [Front-Passenger] High
2230Side Impact Sensor [Front-Passenger] Low
2331Seat Belt Pretensioner [Driver] High
2432Seat Belt Pretensioner [Driver] Low
33Seat Belt Pretensioner [Passenger] High
34Seat Belt Pretensioner [Passenger] Low
35~40

CONNECTOR PIN REFERENCE CHART
