Airbag Module: Removal & Installation Kia Optima II рестайлинг

Removal

1. Disconnect the battery negative cable and wait for at least three minutes before beginning work.
2. Remove the glove box. (Refer to «CRASH PAD»(ref-357465-S42759464242010032300000) )
3. Disconnect the PAB connector and remove the PAB mounting bolts (2EA).
4. Remove the crash pad. (Refer to «CRASH PAD»(ref-357465-S42759464242010032300000) ) NOTE: Replace the damaged crash pad with PAB when the PAB is deployed.
5. Remove the heater duct from the crash pad.
6. Remove the mounting nuts(6EA) from the crash pad. Then remove the passenger airbag.

Scheme 56

Installation

1. Disconnect the battery negative cable from battery and wait for at least three minutes before beginning work.
2. Remove the ignition key from the vehicle.
3. Place a Passenger Airbag(PAB) on the crash pad and tighten the Passenger Airbag(PAB) mounting nuts. Tightening torque : 0.9 ~ 1.4 kgf.m (8.8 ~ 13.7 N.m, 6.5 ~ 10.1 lb.ft)
4. Install the heater duct to the crash pad.
5. Install the crash pad. (Refer to «CRASH PAD»(ref-357465-S42759464242010032300000) )
6. Tighten the PAB mounting bolt. Tightening torque : 1.9 ~ 2.7 kgf.m (18.6 ~ 26.5 N.m, 13.7 ~ 19.5 lb.ft)
7. Connect the Passenger Airbag(PAB) harness connector to the SRS main harness connector.
8. Reinstall the glove box. (Refer to «CRASH PAD»(ref-357465-S42759464242010032300000) )
9. Reconnect the battery negative cable.
10. After installing the Passenger Airbag(PAB), confirm proper system operation: Turn the ignition switch ON; the SRS indicator light should be turned on for about six seconds and then go off.

1. Disconnect the battery negative cable and wait at least 3 minutes before beginning work.
2. Remove the front seat assembly. (Refer to «SEAT & POWER SEAT»(ref-357476) )
3. Remove the seatback cover. (Refer to «SEAT & POWER SEAT»(ref-357476) ) NOTE: When the side airbag deployed after a collision, replace the seatback as an assembly.
4. Loosen the SAB mounting nuts and remove the SAB module.

Scheme 57

Note. Do not open the lid of the side airbag cover. Use a new mounting nuts when you replace a side airbag. Make sure that the seatback cover is installed properly. Improper installation may prevent the proper deployment.

Scheme 58

1. Disconnect the battery negative cable and wait for at least three minutes.
2. Remove ignition key from the vehicle.
3. Place a Side Airbag(SAB) on the seatback frame and tighten the side airbag mounting nuts. Tightening torque : 0.5 ~ 0.7 kgf.m (4.9 ~ 6.9 Nm, 3.6 ~ 5.1 lb.ft)
4. Install the new seatback cover. (Refer to «SEAT & POWER SEAT»(ref-357476) )
5. Install the seat assembly, then connect the Side Airbag(SAB) harness connector.
6. Recline and slide the front seat forward fully, make sure the harness wires are not pinched or interfering with other parts.
7. Reconnect the battery negative cable.
8. After installing the Side Airbag(SAB), confirm proper system operation: Turn the ignition switch ON; the SRS indicator light should be turned on for about six seconds and then go off.

1. Disconnect the battery negative cable and wait for at least three minutes.
2. Remove the ignition key from the vehicle.
3. Install a Curtain Airbag(CAB) on the mounting bracket.
4. Tighten the CAB mounting bolts (6EA) and nuts (2EA). Tightening torque : 1.1 ~ 1.5 kgf.m(10.9 ~ 14.7 Nm, 8.0 ~ 10.8 lb.ft) CAUTION: Never twist the airbag module when installing it. If the module is twisted, airbag module may operate abnormally.
5. Connect the CAB connector.
6. Install the following parts. (Refer to «ROOF TRIM»(ref-357465-S20532722222010032300000) ) Side trim, Roof trim
7. Reconnect the battery negative cable.
8. After installing the Curtain Airbag(CAB), confirm proper system operation: Turn the ignition switch ON; the SRS indicator light should be turned on for about six seconds and then go off.
