A/c Compressor Controls (Full Auto): Specifications Kia Optima II

Automatic HVAC System 2 illustrations

SPECIFICATION

Temperature [°C(°F)]Resistance between terminals 2and 4 (kohms)
0 (32)97.71 +/- 3%
15 (59)47.13 +/- 3%
25 (77)30.00 +/- 3%
35 (95)19.59 +/- 3%
50 (122)10.81 +/- 3%

TEMPERATURE RESISTANCE SPECIFICATION

Note. In car sensor is negative type thermistor resistance will rise with lower temperature, and reduce with higher temperature.

Scheme 1

Scheme 1: REPLACEMENT
Scheme 1: REPLACEMENT
  1. Disconnect the negative (-) battery terminal.
  2. Remove the center fascia panel. (Refer to «CRASH PAD»(ref-266048-S40843902972007092700000) ).
  3. Disconnect the connector of in-car sensor (A). Loosen the mounting 2 screws and then remove the in-car sensor (B).
  4. Installation is the reverse order of removal.

Scheme 2

Scheme 2: COMPONENT LOCATION
Scheme 2: COMPONENT LOCATION
