Esc (Electronic Stability Control): Specifications Kia Optima II

Anti-Lock/traction Control 8 illustrations

SPECIFICATIONS

DescriptionSpecification
Operating voltage4.75 - 5.25 V
Current consumptionMax. 65 mA
Output voltage range0.5 - 4.5 V
Operating temperature40 - 85°C (-40 - 185°F)
Yaw-rate sensorMeasurement range75 - 75 °/sec
Output voltage range0.5 - 4.5 V
Sensitivity26.67 mV (°/sec.)
Zero rate output2.5 V
Frequency response10 Hz
Lateral G sensorMeasurement range1.5 - 1.5 g
Output voltage range0.5 - 4.5 V
Sensitivity1.33 V/g
Zero rate output2.5 V
Frequency response50 Hz

VOLTAGE SPECIFICATIONS CHART

Scheme 77

Scheme 77: OUTPUT CHARACTERISTIC
Scheme 77: OUTPUT CHARACTERISTIC

Scheme 78

Scheme 78
Scheme 78

Scheme 79

Scheme 79: EXTERNAL DIAGRAM
Scheme 79: EXTERNAL DIAGRAM

Scheme 80

Scheme 80: REPLACEMENT
Scheme 80: REPLACEMENT
  1. Remove the floor console. (refer to " «CONSOLE»(ref-266048-S13692866602007092700000) ")
  2. Remove the mounting bolts (A).
  3. Disconnect the yaw-rate & lateral G sensor connector.
ItemSpecification
Supply voltage4.75 V - 5.25 V
Supply currentLess than 15 mA
Operating temperature40 °C - 125 °C (-40 °F - 257 °F)
Measurement pressure range0 - 200 bar
Max. pressure limit350 bar
Zero rate output0.5 V
Output range0.5 - 4.4 V

VOLTAGE SPECIFICATIONS CHART

Scheme 81

Scheme 81: CIRCUIT DIAGRAM
Scheme 81: CIRCUIT DIAGRAM

Scheme 82

Scheme 82: OUTPUT CHARACTERISTIC
Scheme 82: OUTPUT CHARACTERISTIC

SPECIFICATION

DescriptionSpecification
Operating voltage9 - 16 V
Operating temperature30 - 75 °C (-22 - 167 °F)
Current consumptionMax. 100 mA
Steering angle velocityMax. ± 1500 °/sec
Voltage (high)3.0 V - 4.1 V
Voltage (low)1.3 V - 2.0 V
Pulse duty40 - 60 %

VOLTAGE SPECIFICATIONS CHART

Scheme 83

Scheme 83: CIRCUIT DIAGRAM (STEERING WHEEL SPEED ANGLE SENSOR)
Scheme 83: CIRCUIT DIAGRAM (STEERING WHEEL SPEED ANGLE SENSOR)

Scheme 84

Scheme 84: OUTPUT CHARACTERISTIC
Scheme 84: OUTPUT CHARACTERISTIC
No.INPUTOUTPUTSteering direction
1ST1LLRight
ST2LH
ST1LHLeft
ST2LL
2ST1LLLeft
ST1HL
ST1LHRight
ST2HH
3ST1HHLeft
ST2LH
ST1HLRight
ST2LL
4ST1HHRight
ST2HL
ST1HLLeft
ST2HH

STEERING DIRECTION
