Steering Column/shaft: Removal & Installation Kia Optima I рестайлинг

REMOVAL

Scheme 12

Scheme 13

Scheme 14

Scheme 15

Scheme 16

Scheme 17

1. Loosen the tapping screws and lift up the horn pad and remove it.
2. Remove the lock nut and the washer. CAUTION: Before doing these procedures, see «AIR BAG RESTRAINT SYSTEMS»(ref-160402) .
3. Remove the steering wheel using the special tool. (09561-11001)
4. Remove the steering column lower and upper shrouds.
5. Remove the lower cover.
6. Disconnect the connectors and remove the multifunction switch.
7. Remove the bolts securing the coupling and universal joint. Pull out the coupling and universal joint from the gear box.
8. Remove the dust cover mounting bolts.
9. Remove the steering column mounting bolts (4 bolts).
10. Remove the steering column and shaft together with the universal joint and dust cover.

Scheme 18

Scheme 19

Scheme 20

1. Remove the coupling and universal joint from the steering column and shaft assembly.
2. If it is necessary to remove the steering and ignition lock assembly, use a hack saw to cut the torsion bolt at the key holder assembly side.
