Steering Column/shaft: Diagnosis Kia Optima I рестайлинг

INSPECTION

1. Check the steering shaft for damage, play and round movement.
2. Check the joints for excessive play, damage or rough movement.
3. Check the tilt bracket for cracks or damage.
4. Check the cover or boot for damage
5. Check that the steering lock mechanism operates properly. If necessary, replace.

Scheme 10

1. When installing the steering ignition lock and steering lock bracket to the column tube, temporarily install the steering lock in alignment with the column boss.
2. After checking that the lock works properly, tighten the special bolts until the head twists off.
3. Cover the inside lip of the inner cover with grease and pull the outside of the cover onto the joint.
4. Fill the inside of the bearing with multipurpose grease.
5. Install the bearings to the shaft on the joint assembly.

Scheme 11

1. Before installation, apply multipurpose grease to the groove on the inside of the bearing and mating surfaces of the boot and cover assembly.
2. Connect the steering lower shaft and joint assembly.
3. Install the dust cover with column shaft assembly.
4. Install the steering column assembly to the column member assembly (4 bolts).
5. Install the multi function switch and connect the connectors.
6. Install the lower cover and upper and lower shroud.
7. Install the steering wheel.
