Starters: Overhaul Kia Optima I рестайлинг

OVERHAUL

To assist in overhaul use illustration. (Scheme 5)

Scheme 5

Disassembly (Snap Ring & Stop Ring)

1. Press the stop ring to the snap ring side using a socket wrench, to the snap ring side. (Scheme 6)
2. After removing the snap ring (using snap-ring pliers), remove the stop ring and the overrunning clutch. (Scheme 7)

Scheme 6

Scheme 7

Reassembly (Snap Ring & Stop Ring)

Note. To assist in reassembly (Scheme 8)

Scheme 8
