SPECIFICATIONS
Note. O.D. = Outer Diameter I.D. = Inner Diameter O.S. = Oversize Diameter U.S. = Undersize Diameter
| Description | Specification | Limit | |
|---|---|---|---|
| General | |||
| Type | In-line, Double Overhead Camshaft | ||
| Number of cylinders | 4 | ||
| Bore | 86.5 mm (3.41 in.) | ||
| Stroke | 100 mm (3.94 in.) | ||
| Total displacement | 2351 cc (143.5 cu. in.) | ||
| Compression ratio | 10 | ||
| Firing order | 1-3-4-2 | ||
| Idle R.P.M | 800 ± 100 rpm | ||
| Ignition timing at idling speed | BTDC 5° ± 2° | ||
| Valve timing | |||
| Intake valve | |||
| Opens (BTDC) | 12° | ||
| Closes (ABDC) | 56° | ||
| Exhaust valve | |||
| Opens (BBDC) | 54° | ||
| Closes (ATDC) | 14° | ||
| Cylinder head | |||
| Flatness of gasket surface | Max. 0.03 mm (0.0012 in.) | 0.2 mm (0.008 in.) | |
| Flatness of manifold mounting surface | 0.15 mm (0.0059 in.) | 0.3 mm (0.012 in.) | |
| Dimensions for reworking oversize valve seat hole | |||
| Intake | 0.3 mm (0.012 in.) O.S. | 35.300-35.325 mm (1.3898-1.3907 in.) | |
| 0.6 mm (0.024 in.) O.S | 35.600-35.625 mm (1.4016-1.4026 in.) | ||
| Exhaust | 0.3 mm (0.012 in.) O.S. | 33.300-33.325 mm (1.3110-1.3120 in.) | |
| 0.6 mm (0.024 in.) O.S | 33.600-33.625 mm (1.3228-1.3238 in.) | ||
| Dimensions for reworking oversize valve se; at hole (both intake and exhaust) | |||
| 0.05 mm (0.002 in.) O.S. | 12.050-12.068 mm (0.4744-0.4751 in.) | ||
| 0.25 mm (0.010 in.) O.S. | 12.250-12.268 mm (0.4823-0.4830 in.) | ||
| 0.50 mm (0.020 in.) O.S. | 12.500-12.518 mm (0.4921-0.4928 in.) | ||
| Camshaft | |||
| Cam height | |||
| Intake | 35.493 mm (1.3974 in.) | 34.993 mm (1.3777 in.) | |
| Exhaust | 35.317 mm (1.3904 in.) | 34.817 mm (1.3707 in.) | |
| Journal O.D. | 26 mm (1.02 in.) | ||
| Bearing oil clearance | 0.040-0.076 mm (0.0020-0.0029 in.) | ||
| End play | 0.1-0.2 mm (0.004-0.008 in.) | ||
| Valve | |||
| Valve length | |||
| Intake | 109.5 mm (4.311 in.) | ||
| Exhaust | 109.7 mm (4.319 in.) | ||
| Stem O.D. | |||
| Intake | 6.565-6.580 mm (0.2585-0.2591 in.) | ||
| Exhaust | 6.530-6.550 mm (0.2571-0.2579 in.) | ||
| Face angle | 45-45.5° | ||
| Thickness of valve head (margin) | |||
| Intake | 1.0 mm (0.040 in.) | 0.7 mm (0.028 in.) | |
| Exhaust | 1.5 mm (0.059 in.) | 1.0 mm (0.040 in.) | |
| Valve stem to valve guide clearance | |||
| Intake | 0.020-0.047 mm (0.0008-0.0019 in.) | 0.10 mm (0.0040 in.) | |
| Exhaust | 0.050-0.085 mm (0.0020-0.0033 in.) | 0.15 mm (0.0059 in.) | |
| Valve guide | |||
| Length | |||
| Intake | 45.5 mm (1.791 in.) | ||
| Exhaust | 50.5 mm (1.988 in.) | ||
| Service size | 0.05, 0.25, 0.50 mm (0.002, 0.010, 0.020 in.) oversize | ||
| Valve seat | |||
| Width of seat contact | 0.9-1.3 mm (0.035-0.051 in.) | ||
| Seat angle | 44-44.5 | ||
| Service size | 0.3 mm (0.012 in.), 0.6 mm (0.024 in.) oversize | ||
| Valve spring | |||
| Free length | 45.82 mm (1.804 in.) | 44.82 mm (1.765 in.) | |
| Load | 248 N (55 lb) at installed height | ||
| Out of squareness | Less than 1.5° | 4° | |
| Cylinder block | |||
| Cylinder bore | 86.5-86.53 mm (3.4055-3.4067 in.) | ||
| Out-of-roundness and taper of cylinder bore | Less than 0.01 mm (0.0004 in.) | ||
| Flatness of gasket surface | Less than 0.05 mm (0.0020 in.) | 0.1 mm (0.0040 in.) | |
| Piston | |||
| O.D. | 84.97-85.00 mm (3.3453-3.3465 in.) | ||
| Piston-to-cylinder clearance | 0.02-0.04 mm (0.0008-0.0012 in.) | ||
| Ring groove width | |||
| No. 1 | 1.21-1.23 mm (0.0476-0.0484 in.) | ||
| No. 2 | 1.51-1.53 mm (0.0595-0.0602 in.) | ||
| Oil | 2.81-2.83 mm (0.1106-0.1114 in.) | ||
| Piston ring Side clearance | |||
| No. 1 | 0.03-0.07 mm (0.0012-0.0028 in.) | 0.1 mm (0.004 in.) | |
| No. 2 | 0.02-0.06 mm (0.0008-0.0024 in.) | 0.1 mm (0.004 in.) | |
| End gap | |||
| No. 1 | 0.25-0.35 mm (0.0098-0.0138 in.) | 0.8 mm (0.031 in.) | |
| No. 2 | 0.40-0.55 mm (0.0157-0.0216 in.) | 0.8 mm (0.031 in.) | |
| Oil ring side rail | 0.10-0.40 mm (0.0039-0.0157 in.) | 1.0 mm (0.040 in.) | |
| Connecting rod | |||
| Bend | 0.05 mm (0.0020 in.) or less per 100 mm (3.937 in.) | ||
| Twist | 0.1 mm (0.004 in.) or less per 100 mm (3.937 in.) | ||
| Connecting rod big end to crankshaft side clearance | 0.10-0.25 mm (0.0040-0.0098 in.) | 0.4 mm (0.0157 in.) | |
| Piston pin press-in load | 7,500-17,500 N (1,653-3,858 lb) | ||
| Connecting rod bearing | |||
| Oil clearance | 0.015-0.048 mm (0.0008-0.0020 in.) | 0.1 mm (0.004 in.) | |
| Crankshaft main bearing | |||
| Oil clearance | No. 1, 2, 4, 5:0.018-0.036 mm (0.0007-0.0014 in.) No. 3 :0.024-0.042 mm (0.0009-0.0016 in.) | 0.1 mm (0.004 in.) | |
| Crankshaft | |||
| Pin O.D. | 44.980-45.000 mm (1.7709-1.7717 in.) | ||
| Journal O.D. | 56.982-57.000 mm (2.2434-2.2442 in.) | ||
| Out-of-roundness of journal and pin | Less than 0.015 mm (0.0006 in.) | ||
| Taper of journal and pin | Less than 0.005 mm (0.0002 in.) | ||
| End play | 0.05-0.25 mm (0.0020-0.0098 in.) | 0.25 mm (0.0098 in.) | |
| Flywheel | |||
| Runout | 0.13 mm (0.0051 in.) | ||
| Oil pressure at curb idle speed | 80 kPa (11.4 psi) or more | ||
| [Oil tempreature is 75 to 90°C 167 to 194°F)] | |||
| Oil pump Tip clearance | |||
| Drive gear | 0.160-0.205 mm (0.0063-0.0081 in.) | 0.25 mm (0.0098 in.) | |
| Driven gear | 0.180-0.205 mm (0.0071-0.0081 in.) | 0.25 mm (0.0098 in.) | |
| Side clearance | |||
| Drive gear | 0.08-0.14 mm (0.0031-0.0055 in.) | 0.25 mm (0.0098 in.) | |
| Driven gear | 0.06-0.12 mm (0.0024-0.0047 in.) | 0.25 mm (0.0098 in.) | |
| Relief spring | |||
| Free length | 46.6 mm (1.835 in.) | ||
| Load [61 N (13.5 lb)] | 40.1 mm (1.579 in.) | ||
| Right silent shaft | |||
| Front journal diameter | 41.959-41.975 mm (1.6519-1.6526 in.) | ||
| Rear journal diameter | 40.951-40.967 mm (1.6122-1.6129 in.) | ||
| Oil clearance | |||
| Front | 0.020-0.0061 mm (0.0008-0.0024 in.) | ||
| Rear | 0.050-0.091 mm (0.0020-0.0036 in.) | ||
| Left silent shaft | |||
| Front journal diameter | 18.467-18.480 mm (0.7270-0.7276 in.) | ||
| Rear journal diameter | 40.959-40.975 mm (1.6126-1.6132 in.) | ||
| Oil clearance | |||
| Front | 0.020-0.054 mm (0.0008-0.0021 in.) | ||
| Rear | 0.042-0.083 mm (0.0017-0.0033 in.) | ||
| Cooling method | Engine coolant cooling, forced circulation with water pump (Driven belt) | ||
| Cooling system | |||
| Quantity | 6.5 lit (6.9 U.S.qts., 5.7 lmp.qts.) [For DOHC]] | ||
| Thermostat | |||
| Type | Wax pellet type with jiggle valve | ||
| Normal opening temperature | 82°C (179.6°F) | ||
| Opening temperature range | 80.5°C -83.5°C (176.9-182.3°F) | ||
| Wide open temperature | 95°C (203°F) | ||
| Radiator cap | |||
| Main valve opening pressure | 86.1-124.5 kPa (0.98-1.27 kg/cm 2 , 13.94-18.06 psi) | ||
| Main valve closing pressure | 83.4 kPa (0.85 kg/cm 2 , 12.1 psi) | ||
| Vacuum valve opening pressure | 6.86 kPa (-0.07 kg/cm 2 -1.00 psi) | ||
| Air cleaner | |||
| Type | Dry type | ||
| Element | Unwoven cloth type | ||
| Exhaust pipe | |||
| Muffler | Expansion resonance type | ||
| Suspension system | Rubber hangers | ||
Engine Specifications
Scheme 1
Scheme 2
Scheme 3
TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) | ||
|---|---|---|---|
| Air Conditioner Compressor-To-Bracket Bolt | 17-20 (23-27) | ||
| Auto Tensioner Bolt | 14-20 (19-27) | ||
| Camshaft Bearing Cap Bolt (1) | 14-15 (19-21) | ||
| Camshaft Position Sensing Cylinder Bolt | 11-16 (15-22) | ||
| Camshaft Sprocket Bolt | 59-74 (80-100) | ||
| Center Exhaust Pipe-To-Catalytic Converter Nuts | 22-30 (30-40) | ||
| Center Exhaust Pipe-To-Main Muffler Bolts | 22-30 (30-40) | ||
| Connecting Rod Cap Nut | |||
| Step 1 | 13-16 (18-22) | ||
| Step 2 | (2) | ||
| Crankshaft Main Bearing Cap Bolt (3) | |||
| Step 1 | 18 (25) | ||
| Step 2 | (2) | ||
| Crankshaft Pulley-To-Crankshaft Sprocket Bolt | 14-22 (19-30) | ||
| Crankshaft Sprocket Bolt | 81-96 (110-130) | ||
| Cylinder Head Bolts (4) | |||
| Step 1 | 15 (20) | ||
| Step 2 | (5) | ||
| Drive Plate\Flywheel Bolt | 96-103 (130-140) | ||
| Driven Gear Bolt | 25-30 (34-40) | ||
| EGR Valve Bolts | 13-19 (17-26) | ||
| Engine Coolant Pump-To-Cylinder Block Bolt | 11-15 (15-20) | ||
| Engine Coolant Temperature Sensor | 15-30 (20-40) | ||
| Engine Hanger Bolt | |||
| M8 | 18-22 (25-30) | ||
| M10 | 25-41 (34-55) | ||
| Engine Mounting Bracket Bolts | 44-59 (60-80) | ||
| Engine Mounting Bracket Nuts | 44-59 (60-80) | ||
| Engine Mounting Insulator Bolt | 66-81 (90-110) | ||
| Exhaust Manifold-To-Engine Nuts | |||
| M8 | 18-22 (25-30) | ||
| M10 | 25-41 (34-55) | ||
| Front Exhaust Pipe Clamp Bolt | 14-22 (19-30) | ||
| Front Exhaust Pipe-To-Manifold Nut | 22-30 (30-40) | ||
| Front Roll Stopper Bracket-To-Sub Frame Bolts | 37-48 (50-65) | ||
| Front Roll Stopper Bracket-To-Transaxle Bolts | 44-59 (60-80) | ||
| Front Roll Stopper Insulator Bolt & Nut | 37-48 (50-65) | ||
| Generator Brace Bolt | |||
| 4T | 9-11 (12-15) | ||
| 5T | 14-20 (19-27) | ||
| Generator Support Bolt | 14-18 (19-25) | ||
| Hanger-To-Body Bolt | |||
| M8 | 18-22 (25-30) | ||
| M10 | 26-41 (35-55) | ||
| Idler Pulley Bolt | 33-41 (45-55) | ||
| Intake Manifold Mounting Bolt | |||
| M8 | 11-14 (15-19) | ||
| M10 | 13-18 (18-25) | ||
| Intake Manifold Mounting Nut | 22-31 (30-42) | ||
| Intake Manifold Stay Bolts | 13-16 (18-22) | ||
| Oil Filter Bracket Bolt | 14-20 (19-27) | ||
| Oil Pan Drain Plug | 26-33 (35-45) | ||
| Oil Pump Case Bolt (M8) | 14-20 (19-27) | ||
| Oil Pump Cover Bolt | 11-13 (15-18) | ||
| Oil Pump Sprocket Nut | 37-44 (50-60) | ||
| Oil Screen Bolt | 11-16 (15-22) | ||
| Oxygen Sensor | 30-37 (40-50) | ||
| Plug Cap | 14-20 (19-27) | ||
| Power Steering Oil Pump-To-Bracket Bolt | 26-33 (35-45) | ||
| Rear Roll Stopper Bracket-To-Sub Frame Bolts | 37-48 (50-65) | ||
| Rear Roll Stopper Bracket-To-Transaxle Bolts | 44-59 (60-80) | ||
| Rear Roll Stopper Insulator Bolt & Nut | 37-48 (50-65) | ||
| Relief Plug | 30-37 (40-50) | ||
| Tensioner Pulley Bolt | 32-41 (43-55) | ||
| Tensioner Pulley Bracket Bolt | 17-20 (23-27) | ||
| Tension Rod Bracket Bolt-To-Tension Rod | 26-41 (35-55) | ||
| Throttle Body Stay Bolt | 11-16 (15-22) | ||
| Throttle Body-To-Intake Manifold Bolt | 11-16 (15-22) | ||
| Timing Belt Left Rear Cover (Lower) Bolt | 22-31 (30-42) | ||
| Transaxle Mounting Bracket Bolts | 44-59 (60-80) | ||
| Transaxle Mounting Insulator Bolt | 66-81 (90-110) | ||
| Transaxle Mounting Sub Bracket Nut | 44-59 (60-80) | ||
| INCH Lbs. (N.m) | |||
| Accelerator Cable-To-Intake Manifold Bolts | 35-53 (4-6) | ||
| Air Cleaner Body Installation Bolt | 71-89 (8-10) | ||
| Air Cleaner Mounting Bolts | 71-89 (8-10) | ||
| Center Cover Bolt | 35-44 (4-5) | ||
| Center Exhaust Pipe-To-Bracket Bolt | 89-133 (10-15) | ||
| Crankshaft Position Sensor Bolt | 89-115 (10-13) | ||
| EGR Temperature Sensor (California) | 89-106 (10-12) | ||
| Engine Coolant Outlet Fitting Attaching Bolt | 89-133 (10-15) | ||
| Engine Coolant Pump Pulley Bolt | 71-89 (8-10) | ||
| Engine Coolant Temperature Gauge Unit | 89-106 (10-12) | ||
| Hanger-To-Muffler Bolt | 89-133 (10-15) | ||
| Heat Protector-To-Exhaust Manifold Bolt | 106-133 (12-15) | ||
| Ignition Coil Bolts | 71-106 (8-12) | ||
| Oil Pan Bolt | 89-106 (10-12) | ||
| Oil Pressure Switch | 71-106 (8-12) | ||
| Oil Seal Case Bolt | 89-106 (10-12) | ||
| Power Transistor Bolts | 89-106 (10-12) | ||
| Resonator Mounting Bolt | 71-89 (8-10) | ||
| Resonator Mounting Nut | 35-53 (4-6) | ||
| Rocker Cover Bolt | 71-89 (8-10) | ||
| Timing Belt Lower Cover Bolt (6) | 71-89 (8-10) | ||
| Timing Belt Left Rear Cover (Upper) Bolt | 89-106 (10-12) | ||
| Timing Belt Right Rear Cover Bolt | 89-106 (10-12) | ||
| Timing Belt Upper Cover Bolt | 71-89 (8-10) | ||
| (1) Tighten in sequence. (Scheme 4) (2) Tighten an additional 90-94 degrees. (3) Tighten in sequence. (Scheme 5) (4) With new bolts tighten to 47 ft. lbs. (64 N.m) in sequence. Loosen bolts and follow standard tightening procedure. Tighten in sequence. (Scheme 6) (5) Tighten an additional 90 degrees. (6) Tighten in sequence. (Scheme 7) | |||
| (1) | Tighten in sequence. (Scheme 4) |
| (2) | Tighten an additional 90-94 degrees. |
| (3) | Tighten in sequence. (Scheme 5) |
| (4) | With new bolts tighten to 47 ft. lbs. (64 N.m) in sequence. Loosen bolts and follow standard tightening procedure. Tighten in sequence. (Scheme 6) |
| (5) | Tighten an additional 90 degrees. |
| (6) | Tighten in sequence. (Scheme 7) |
TORQUE SPECIFICATIONS
Scheme 4
Scheme 5
Scheme 6
Scheme 7
Scheme 8
Scheme 9
Scheme 10
Scheme 11
Scheme 12
Scheme 13
- Before checking compression pressure, check the engine oil level. Make sure that the starter motor and battery are in normal operating condition.
- Start the engine and wait until engine coolant temperature reaches 80-95°C (176-205°F).
- Stop the engine and disconnect the spark plug cables.
- Remove the spark plugs.
- Crank the engine to remove any foreign material in the cylinders.
- Attach the compression gauge to the spark plug hole.
- Depress the accelerator pedal to fully open the throttle.
- Crank the engine and read the gauge. Limit : 12.5 kg/cm 2 (1.23 MPa, 178 psi) [250-400 RPM]
- Repeat steps from 6 to 8 over all cylinders, making sure that the pressure differential for each of the cylinders is within the specified limit. Limit: Max : 1.0 kg/cm 2 (100 kPa, 14 psi) between cylinders
- If a cylinder's compression or pressure differential is below the specification, add a small amount of oil through the spark plug hole and repeat steps from 6 to 9. If the addition of oil brings the compression up, it is possible that there is wear between the piston ring and cylinder wall. If compression remains the same, valve seizure, poor valve seating or a compression leak from the cylinder head gasket are all possible causes. Tightening torque Spark plug : 20-30 Nm (200-300 kg.cm, 15-21 lb.ft)
Scheme 14
- Position a vehicle on a level surface.
- Stop the engine. NOTE: In the case of a vehicle that has been out of service for a prolonged period, run the engine for several minutes. Stop the engine and wait 5 minutes at least, and then check the oil level.
- Check that the engine oil level is within the level range indicated on the oil dipstick. If the oil level is found to have fallen to the lower limit (the "MIN" mark), refill to the "MAX" mark. NOTE: When refilling, use the same type of engine oil as the one currently being used.
- Check that the oil is not dirty or mixed with coolant or gasoline and it has the proper viscosity.
