RELAYS
Note. Relay terminal identification number is printed on relay body.
- Remove high or low headlight relay. Using ohmmeter, check for continuity between relay terminals No. 85 and 86. Continuity should exist. Also check continuity between relay terminals No. 30 and 87. Continuity should not exist. If continuity is as specified, go to next step. If continuity is not as specified, replace relay.
- Using jumper wire, apply battery voltage to relay terminal No. 86. Using another jumper wire, connect relay terminal No. 85 to ground. Recheck continuity between relay terminals No. 30 and 87. If continuity exists, relay is okay. If continuity does not exist, replace relay.
HEADLIGHT SWITCH
Disconnect combination switch 18-pin connector. Check for continuity between specified combination switch connector terminals. See HEADLIGHT SWITCH TEST table. (Scheme 1) If continuity is not as specified, replace headlight switch.
| Application & Switch Position | Continuity Between Terminals No. | |
|---|---|---|
| Headlight Switch | ||
| Off | No Continuity | |
| Parking | 11 & 14 | |
| Lo Beam | 11, 12, 13 & 14; 17 & 18 | |
| Hi Beam | 8 & 17; 11, 12, 13 & 14 | |
| Flash-To-Pass Switch | ||
| On | 8, 9 & 17 | |
HEADLIGHT SWITCH TEST
Scheme 1
TURN SIGNAL SWITCH
Disconnect combination switch 18-pin connector. Check for continuity between specified switch terminals. See TURN SIGNAL SWITCH TEST table. (Scheme 1) If continuity is not as specified, replace combination switch.
| Switch Position | Continuity Between Terminals No. | |
|---|---|---|
| Left | 1 & 2 | |
| Right | 2 & 3 | |
TURN SIGNAL SWITCH TEST
WIPER/WASHER SWITCH
For wiper/washer switch testing, see WIPER/WASHER SYSTEM article.
