Specifications (With SIRIUS)
| Item | Specification | |
|---|---|---|
| Storage temperature | 40°F ~ 221°F (-40°C ~ 105°C) | |
| Operation temperature | 22°F ~ 185°F (-30°C ~ 85°C) | |
| Operation voltage | AM/FM | DC 10.5 ~ 16.0V |
| SIRIUS | DC 3.3 ~ 7.0V | |
| Consumption current | AM/FM | MAX 150mA |
| SIRIUS | MAX 160mA | |
| Input/output impedance | AM/FM | 75ohms |
| SIRIUS | 50ohms | |
ANTENNA SPECIFICATIONS (WITH SIRIUS)
Specifications (Without SIRIUS)
| Item | Specification |
|---|---|
| Storage temperature | 40°F ~ 176°F (-40°C ~ 80°C) |
| Operation temperature | 22°F ~ 140°F (-30°C ~ 60°C) |
| Operation voltage | DC 10.5 ~ 16.0V |
| RATED voltage | DC 12.0V (minus Ground) |
| Consumption current | MAX 150mA |
| Input/output impedance | 75ohms (FM) |
ANTENNA SPECIFICATIONS (WITHOUT SIRIUS)
Scheme 1
Scheme 2
Scheme 3
Scheme 4
Scheme 5
- Remove the antenna jack from the audio unit and antenna.
- Check for continuity between the center poles of antenna cable.
- If there is no continuity, replace the antenna cable.
- Check for continuity between the outer poles of antenna cable. There should be continuity.
- Check for continuity between the center pole (A) and outer pole (B) of antenna cable. There should be no continuity.
- If there is continuity, replace the antenna cable.
Scheme 6
Scheme 7
- Remove the rear roof trim. (For Coupe, refer to «ROOF TRIM»(ref-362224-S36803989212010060400000) . For Sedan, refer to «ROOF TRIM»(ref-362245-S09608232002010060400000) .)
- Disconnect the 1P power connector from the roof antenna.
- Disconnect the antenna connectors (2EA) from the feeder cable.
- Remove the SDARS roof antenna (A) from the roof panel hole after loosening a nut.
