Audio: Removal & Installation Kia Forte I

Antenna Systems 13 illustrations ~321 words

Installation

  1. Connect the audio unit connectors and cable.
  2. Install the audio unit, and mounting bolts (4EA)
  3. Install the crash pad center fascia panel.
  4. Check the audio system. NOTE: Make sure the audio head unit connectors are plugged in properly, and the antenna cable is connected properly.

Scheme 13

Scheme 13: Disassembly

Scheme 14

Scheme 14

Scheme 15

Scheme 15
  1. Disassemble the front panel (A) then disconnect the connector (B) between the unit and front panel.
  2. Disassemble the top cover (A) after loosening 4 screws.
  3. Disassemble the deck (A) from the unit after removing the connector and screws.
  1. Connect the roof antenna cables and connectors.
  2. Install the rear roof trim.

Scheme 16

Scheme 16: Circuit Diagram

Scheme 17

Scheme 17

Scheme 18

Scheme 18: Removal

Scheme 19

Scheme 19

Scheme 20

Scheme 20

Scheme 21

Scheme 21

Scheme 22

Scheme 22

Scheme 23

Scheme 23
  1. Disconnect the negative (-) battery terminal.
  2. Remove the driver airbag module (A) after removing mounting bolts (B). (Refer to «AIRBAG MODULE (RESTRAINTS - ADVANCED)»(ref-362244) or «AIRBAG MODULE (RESTRAINTS - DEPOWERED)»(ref-362249) )
  3. Remove the steering wheel after loosening the nut and disconnecting the connector (A). (Refer to «STEERING COLUMN AND SHAFT»(ref-362239-S17782797232010060400000) ).
  4. Loosen the screws (4EA) on the opposite side of the steering wheel.
  5. Disconnect the audio remote control switch connector (A).
  6. Remove the audio remote control switch (A).
  1. Install the audio remote control switch on the steering wheel.
  2. Connect the audio remote control switch connector.
  3. Install the steering wheel.
  4. Install the driver airbag module.

Scheme 24

Scheme 24: Inspection
  1. Check for resistance between No. 6 and No. 7 terminals in each switch position. [Audio System] RESISTANCE CHART Switch Connector terminal Resistance (±5%) VOLUME DOWN 6-7 6.81 kohms VOLUME UP 6-7 4.61 kohms MUTE 6-7 3.11 kohms MODE 6-7 2.11 kohms SEEK DOWN 6-7 1.11 kohms SEEK UP 6-7 430 ohms [Audio system + Auto Cruise] RESISTANCE CHART Switch Connector terminal Resistance (±5%) VOLUME DOWN 6-7 6.81 kohms VOLUME UP 6-7 4.61 kohms MUTE 6-7 3.11 kohms MODE 6-7 2.11 kohms SEEK DOWN 6-7 1.11 kohms SEEK UP 6-7 430 ohms

Scheme 25

Scheme 25: Circuit Diagram
