Description

All modules are linked on a low speed CAN network.

The input information for the modules is coming from both the CAN network and the hardware components (actuators and sensors).

  1. Front Area Module (FAM) Headlamp low/high beam control (with DRL) Park lamp control Front fog lamp control Front turn signal lamp control Windshield wiper control Windshield deicer Diagnostics
  2. In-Panel Module (IPM) Remote Keyless Control (RKE) Voice Alarm System (VAS) Ignition key hole illumination Switch indicators control Panel light control Seat belt warning Auto light/DRL control (Logic) Windshield/Rear wiper control (Logic) Turn and Hazard lamp control (Logic) Central door lock (Logic) Windshield deicer timer Rear glass defog timer Gateway for ISO-9141 (K-Line)
  3. Rear Area Module (RAM) Tail lamp control Turn and Hazard lamp control Back up lamp control Rear fog lamp control Stop lamp outage detection Sliding door power window/Quarter glass control Room lamp control Rear wiper control Rear glass defog Fuel filler door open solenoid control
  4. Assist Drive Module (ADM)
  5. Driver Drive Module (DDM)

Module Introduction

FAM/IPM/RAM consists of a power board and an electronic board. The power board contains circuit protection devices and switching devices. The electronic board uses Intelligent Power Switching (IPS) for HS/LS load control, logic functions and CAN/K-Line communication.

The power board and electronic board are connected with pin blocks for the Front Area Module (FAM) and Variable Connection Displacement (VCD) for the In-Panel Module (IPM) and the Rear Area Module (RAM).

Scheme 1

Scheme 1: Module Introduction
