Body Control Module (BCM): Other Kia Carnival III

Exterior Lighting Functions

The exterior lighting function has to provide the lighting and signalling of the vehicle; it monitors different available lights in front or at the back of the vehicle

1. Park and Tail lamps (with Side marker lamps)
2. License plate lamps
3. Head lamps Low Beam
4. Head lamps High Beam
5. Front and Rear fog lamps (with the Rear fog lamp switch indicator)
6. Stop lamps
7. Backup lamps
8. Turn signal and side repeater lamps.

Scheme 2

1. Necessary conditions to switch ON: By putting the Head lamp switch in position 'Park and Tail lamp' or 'Head lamp Low Beam' or Auto light activation or DRL activation
2. Necessary conditions to switch OFF: If they are released by the Head lamp switch (Auto light function deactivated) and if DRL function is deactivated If the Auto light function is active but the Auto light Sensor signal status is OFF or Battery Saver function is active.
3. Functional diagram

Scheme 3

1. Necessary conditions to switch ON: By putting the Head lamp switch in position 'Head lamp Low Beam' or Auto light activation or DRL activation.
2. Necessary conditions to switch OFF: If they are released by the Head lamp switch (Auto light function deactivated) and if the DRL function is deactivated If the Auto light function is active but the Auto light sensor signal status is not 'HL ON'.
3. Functional diagram

Scheme 4

1. Necessary conditions to switch ON: By pushing down the High Beam lever switch if the Head lamp switch is in position 'Head lamp Low Beam' or the Head lamps Low Beam have been turned ON by the Auto light function. By pulling the High Beam lever switch toward the driver (Flash to pass activation) By the DRL function activation for Canada.
2. Necessary conditions to switch OFF: By pulling back the High Beam lever switch (manual reset by the driver) or If the Head lamps Low Beam are turned OFF or if the Auto light function is active but the Auto light Sensor signal status is not 'HL ON') or By releasing the Flash To Pass activation and If the DRL function is deactivated for Canada.
3. Functional diagram

Scheme 5

1. Necessary conditions to switch ON (if they are standard): By activation of Crash Unlock During the opening / closing of the Tail gate by the PTG Flasher input With the Remote Keyless Entry to lock / unlock the vehicle By alarm activation By panic activation with the Remote Keyless Entry By activation of the Hazard Lamp by the hazard switch and ignition is position OFF, ACC or RUN By using the turn lever switch with the ignition switch in the ON position.
2. Necessary conditions to switch OFF (if they are standard): Ignition switch in OFF position for deactivation of crash unlock flashing Deactivation of the alarm or at the end of the alarm flashing sequence Deactivation of panic sequence with pushing any button of the Remote Keyless Entry or at the end of the panic flashing sequence Turn lever switch command in OFF position or ignition switch in OFF, ACC or START position to stop turn lever flashing. The hazard switch in OFF position or ignition switch in position START to stop the Hazard flashing. At the end of the Lock, Unlock and PTG flashing sequence.
3. During the start up of the vehicle (ignition key in position START): The Turn signal lamps activated by the turn lever switch are temporarily turned OFF. If the time duration in Start position is more than 10 seconds and engine running, the Turn signal lamps are managed again as if the ignition key was in ON position, The flashing sequence of the hazard lamps is immediately stopped if they have been activated by the hazard button. If the time duration in Start position is more than 10 seconds and engine running, the flashing sequence of the hazard lamps are managed again as if the ignition key was in RUN position, The flashing sequence of the hazard lamps is not stopped if they have been activated by a crash unlock.
4. Functional diagram

Scheme 6

Scheme 7

Scheme 8

1. Necessary conditions to switch ON: By using the stalk: Head lamp switch in position 'Head lamp Low Beam' and Front Fog lamp sw ON When Auto light function activated and Auto light Sensor signal status is 'HL ON' and Front Fog lamp sw ON
2. Necessary conditions to switch OFF: When Auto light function activated and Auto light Sensor signal status is not ON When Front fog lamp sw OFF.
3. Functional Diagram

Scheme 9

1. Necessary conditions to switch ON: When inhibit sw 'R' read by FAM is active and transmitted to RAM by CAN signal.
2. Necessary conditions to switch OFF: When inhibit sw 'R' read by FAM is not active and transmitted to RAM by CAN signal.
3. Functional diagram

Scheme 10

1. Necessary conditions to switch ON the stop lamps: Pushing on the brake pedal.
2. Necessary conditions to switch OFF the stop lamps: Releasing the brake pedal.
3. Functional diagram

Auto Light Function

1. The Auto light function is active when the Head lamp switch is positioned to 'Auto' and the Key is in RUN position. The auto light sensor is powered on the status ACC, START and RUN of the key position. Based on the Auto light sensor values corresponding to the exterior brightness level, it controls automatically the lighting of the Park and tail lamps or / and the Head lamps Low Beam depending on the country.
2. Auto light Sensor detection table AUTO LIGHT SENSOR DETECTION Mode Tail Lamps Head Lamps Low Beam Lux (Lux) Voltage (V) Lux (Lux) Voltage (V) ON < 24 ± 5.2 <1.77 ± 0.08V Same as Tail lamps OFF > 48 ± 10.5 > 3.47 ± 0.1V Same as Tail lamps

Scheme 11

1. The Auto DRL function operates the Head lamps High Beam at 50% of full illumination. The park and tail are managed by the auto light sensor. The Auto DRL function is active if: The ignition switch is on RUN position. The engine is running. The Park brake switch is OFF.
2. The DRL function is inactive when one of above conditions is released. When the DRL function is active, the Head lamps High Beam can't be turned ON, except for the Flash To Pass activation.
3. Functional diagram

Scheme 12

Scheme 13

1. Necessary conditions to activate the Battery Saver function: Do not turn off the Park/Tail Lamp when intentionally turned on. If Key reminder switch is ON and Park/Tail Lamp switch is ON, Intentional "ON" should be reset. If the driver's door is open and if the key is not in the key hole whereas the Head lamp switch is still in position 'Park and tail lamp' or 'Head lamp Low Beam', the park and tail lamps (and the Front fog lamps if turned on) are immediately turned off.
2. Necessary conditions to cancel the Battery Saver function: As soon as the Key is input into the IGN Key Cylinder or the Head lamp switch is put to position OFF.
3. Functional diagram

Scheme 14

1. The room lamps are can be controlled manually using the 3-state (ON, DOOR, OFF) switch or by the Rear Area Module (RAM). A main switch, located to the left of the steering wheel, is used as a master control switch. The operating logic of the lamps will vary based on the position of the main switch ON, DOOR, or OFF).
2. Working conditions The functioning depends on the key position in the key cylinder (OFF, ACC, RUN or START) When the key goes in RUN or START position while the room lamps are decaying, then the room lamps are turned off immediately. When the Ignition key position is RUN or START and the last door is closed then the room lamps are OFF. If the room lamps have been activated using the RKE UNLOCK function, and the ignition switch is turned to the RUN or START position, the room lamps will be immediately turned OFF. If the Ignition sw status is in RUN or START and Unlock information occurs, then the room lamp status is not changed. When the system enters to ARM WAIT mode by Remote Key or Mechanical cylinder lock switches the Room lamp should be turned off immediately. If there is RKE Lock signal at any door open, all doors should be locked first and wait for the all door close. No action is taken while the Open Door status is OPEN and the doors are locked. Then when Open Door status changes from OPEN to CLOSE, Room lamps will be OFF immediately. The 30 sec timer does not depend on the key reminder status. If the main switch is changed to ON from DOOR after 20 minute lamp OFF, all the lamps are turned ON. If the Open Door status changes from OPEN to CLOSE (all doors close) when ignition switch is on RUN position, room lamps and door courtesy lamps should turn off immediately (Do not decay off). After 20 minute Room Lamp OFF at door open, Room lamps are turned ON again when: One of the door open switch's status changes. (Open to Close or Close to Open) Ignition key is in RUN or START Position. Receiving an UNLOCK event while a door is open and Main Room Lamp Switch is in the DOOR position. For the room lamps, when the 20m timer is running and any of the side doors is opened the timer is restarted.
3. Functional Diagram
4. Truth table TRUTH Main Room Lamp sw Open Door status (RAM) Luggage interior Lamp (CAN) Room Lamps LS (Door) Room Lamps LS (On) Room Lamp Switch Room Lamp Switch Room Lamp Switch ON DOOR OFF OFF Don't care Don't care OFF OFF OFF OFF OFF ON Don't care Don't care OFF ON ON ON ON DOOR OPEN OFF ( (1) ) ON during 20 min then directly OFF OFF ON ON during 20 min OFF OPEN -->LOCK ( (2) ) ON during 20 min then directly OFF OFF ON during 20 min OPEN -->UNLOCK ( (3) ) ON during 20 min then directly OFF OFF ON during 20 min CLOSE OFF OFF OFF OFF OPEN --> CLOSE Don't care Decayed OFF OFF Decayed OFF OPEN --> CLOSE Don't care ON during 20 min then directly OFF OFF ON during 20 min CLOSE -->LOCK OFF OFF OFF CLOSE -->UNLOCK ON during 30 min then directly OFF OFF ON during 30 min (1) OFF is transmitted when there is no action from Lock/Unlock. It has no impact on the 20mn timer (no restart). (2) LOCK transition is sent by IPM only when door status is CLOSE. Thus there is no action on the 20mn timer in this case. (3) When transition to UNLOCK is received, 20mn timer is restarted.

Scheme 15

1. The map lamps may be controlled manually or by the Rear Area Module (RAM).
2. Functional Diagram
3. Truth table TRUTH Main Room Lamp sw Open Door status (RAM) Luggage interior Lamp (CAN) Map Lamp LS Map Lamp Switch Map Lamp Switch ON OFF OFF Don't care Don't care OFF ON OFF ON Don't care Don't care ON ON ON DOOR OPEN OFF ( (1) ) ON during 20 min then directly OFF ON ON during 20 min OPEN --> LOCK ( (2) ) ON during 20 min then directly OFF ON ON during 20 min OPEN --> UNLOCK ( (3) ) ON during 20 min then directly OFF ON ON during 20 min CLOSE OFF OFF ON OFF CLOSE --> LOCK OFF ON OFF CLOSE -->UNLOCK ON during 30 min then directly OFF ON ON during 30 min OPEN --> CLOSE Don't care OFF (DECAY) ON OFF (DECAY) CLOSE --> OPEN Don't care ON during 20 min then directly OFF ON ON during 20 min (1) OFF is transmitted when there is no action from Lock/Unlock. It has no impact on the 20mn timer (no restart). (2) LOCK transition is sent by IPM only when door status is CLOSE. Thus there is no action on the 20mn timer in this case. (3) When transition to UNLOCK is received, 20mn timer is restarted.

Luggage Lamp

1. Working Conditions The 20 min timer does not depend on the key reminder status. After 20 minute Luggage Lamp OFF at tailgate open, luggage lamps are turned ON again when: Tailgate close and then tailgate is opened again Ignition key is in RUN or START position.
2. Truth table TRUTH Main Room Lamp sw Tail Gate status (RAM) Luggage Lamp LS Luggage Lamp Switch Luggage Lamp Switch DOOR OFF OFF OPEN ON ON OFF CLOSE OFF OFF OFF ON Don't care OFF ON ON DOOR OPEN ON during 20 min then directly OFF ON during 20 min OFF CLOSE OFF OFF OPEN --> CLOSE OFF OFF CLOSE --> OPEN ON during 20 min then directly OFF ON during 20 min

Scheme 16

1. Working Conditions The key cylinder is illuminated when the driver and / or the assist door are open.
2. Key hole extinguish conditions: The key cylinder is turned off 10s after the driver and assist doors are closed. The key cylinder is turned off immediately if the key is inserted in the hole and put to RUN or START position. For vehicles equipped with Burglar Alarm, the key cylinder is turned off immediately when the system goes to ARM WAIT mode during the 10s after the driver and assist doors are closed. For vehicles not equipped with Burglar Alarm, the key cylinder is turned off immediately when RKE lock signal is received from key fob during the 10s after the driver and assist doors are closed (4).
3. Functional Diagram

Scheme 17

1. Working Conditions The MF "high beam" and "flash to pass" switches do not influence the management of the Panel Lights and Trip Computer illumination, Rear Blower illumination and Rear Monitor illumination.
2. Functional Diagram

Dimmable Backlighting

1. Working Conditions The Dimmable backlighting is directly managed by the rheostat.

Scheme 18

1. Working Conditions The IPM sends a CAN message to the DDM so that this module illuminate the power seat switches.
2. Functional Diagram

Scheme 19

1. Front wiper working conditions These functions are active when IGN2 switch ON In the OFF and ACC states, the front wiper is not activated. If IGN2 turns OFF during wiper operation, the wiper stops at the current position and will move to the park position on the next IGN2 ON. In these states, the front washer is not active.
2. Front washer working condition The front washer functionality is directly available to the driver. It consists in activating the front washer pump, which is located under hood. As long as the driver activates the washer multifunction switch, the front washer is active.
3. Functional diagram

Scheme 20

Scheme 21

1. Rear wiper working conditions The rear wiper is available in RUN state. In the START state, all the wiper and washer outputs are halted and then activated again. In the OFF and ACC states, the rear wiper stops its movement at current position. The rear wiper will move to the park position at the next IGN ON. In these states, the rear washer is not activated.
2. Rear washer working condition If the washer signal is active less than 60ms, the signal is neglected. If the washer signal is active for T1 (between 60ms and 300ms), the rear wiper output is turned on for T2 (2.5 ~ 3.8 sec.), T3 (300ms) after the washer has been turned ON. Rear washer activated for T1: (60ms;300ms) T1: 0.06 ~ 0.3 sec. T2: 2.5 ~ 3.8 sec. T3: 0.3 sec.
3. Functional diagram

Defog

This function controls the heating defog grids on windshield, rear glass, and rear view mirrors.

Scheme 22

Scheme 23

1. Working Conditions The defog function can be activated only when engine is running and ignition key is in RUN position. When windshield defog switch is pushed, windshield defog is activated for 20 minutes. While windshield defog is on, the windshield defog button is illuminated If the switch is pushed again while defog is already active, defog stops. If the engine stops while defog is on, defog stops and it is NOT automatically turned on when the engine is started again Rear defog works exactly in the same way as windshield defog using the rear defog switch button as input. When rear defog is active, rear defog switch indicator is ON. Rear defog ctrl output controls rear glass defog as well as rear view mirrors defog.
2. Rear defog pause When IPM receives Tailgate Flasher CAN message, rear defog is inhibited for 30s The 20 min rear defog timer is frozen during this pause. If the user turns on rear defog function while this pause is going on, Rear defog ctrl is set to ON only at the end of the pause. This pause has no impact on rear defog switch illumination. When IPM receives Tailgate open CAN message transition to OPEN value, this 30 s rear defog pause is also started, it works the same way as described above.
3. Functional Diagram

Power Windows

1. The purpose of the power window function is to manage the driver and assist power window motors. This function is entirely implemented in the DDM and ADM (door modules) and DMS role for this function is limited to providing signals through the CAN bus.

Power Seat With Memory Interface

This function manages the power seat and the associated memorized positions. This function is entirely implemented in the IMS (seat module) and DMS role for this function is limited to providing signals through the CAN bus.

Scheme 24

1. This function is implemented by the IMS. This function adjusts the pedal position when the pedal backward/forward switch is pressed.
2. Functional Diagram

Scheme 25

1. Adjust Pedal allows to activate Adjustable Pedal feature for the non-IMS equipped vehicle, IPM needs to control the power source (by relay coil control) of the adjustable Pedal switch unit. There is no Adjustable Pedal switch for Non-IMS version.
2. Functional Diagram

Reverse Drive Exterior Side Mirror

This function is implemented by the DDM. This function turns the 2 external reverse mirrors down when gear box in reverse position.

Replacing The Outside Mirror Action By The Memory Switch

1. In IGN On (IGN State = On) or Driver door opened or during 30 seconds after Driver door open to close when IGN Off Condition (It used IMS Main signal), if user press the position button, Outside Mirror is play to memorized position.
2. The position switch (position 1 and position 2) that has not been saved yet cannot perform replacing.
3. If the user presses a position switch (position 1 or position 2) during replacing operation, the recently pressed switch will be prior to the other.
4. Replacing Prohibition Conditions If the mirror switch on the LH side is pressed If "position switch states" of the CAN communication data sent by the IMS is not "ON" If "Vehicle Speed" of the CAN communication data sent by the cluster is "3 Km/h" or more

Auto Reverse Function

AUTO REVERSE FUNCTION REFERENCE

Scheme 26

1. Working Conditions This Function is available when Ignition key is in RUN position and for 30 sec after end of RUN. Quarter glasses can be controlled by switches situated near driver or switches situated near rear passengers seat (3rd row of seats). When the switch is pressed the motor output is ON until the switch is released or after 5+/- 1 sec. The switch has to be released and pressed again to command the motor output ON again. If power window lock is activated only driver window is enable by driver side switch and no switches are enable to open quarter glass. There is no interaction with the sliding doors. It is not forbidden to open the quarter glasses when the sliding door on the same side is open. No switch information (driver or rear passenger) prevails on the other. If the main switch and the passenger side switch are pressed in opposite direction at the same time, window stops moving.
2. Functional Diagram

Scheme 27

1. Functional Diagram

Sun Roof Relay Coil

This function defines the condition for switching on or off power feed to sun roof relay coil. This function is available in RUN position and during after run timer ON.

Power Window Timer

This function defines the conditions for allowing use of power windows, quarter glass, and feed to sunroof relay coil.

Scheme 28

1. Working Conditions This function is available when ignition key is in RUN position and for 30 sec after end of RUN. Window operation will be canceled if the driver or assist door is opened during the 30 sec period after the key is turned from RUN to ACC or OFF position.
2. Functional Diagram

Scheme 29

1. Description There are two sliding doors and one tailgate in the vehicle. A switch is fitted at each B-pillar to permit Power Sliding Door activation. For the tailgate, there is also one push button switch. These switches are used to send an signal of 200 ms minimum to the PSD module (or PTG module).
2. Functional Diagram

Scheme 30

1. Description The easy access function permits automatic rearward movement of the driver seat when the key is removed from the cylinder. Automatic forward movement of the driver seat will take place when the key is inserted into the cylinder. This function will be enabled on IMS equipped vehicles when the AUTO button is pressed. Inhibit Switch should be in P-Position for the Easy Access operation.
2. Functional Diagram

Scheme 31

1. The instrument cluster indicators listed below are controlled by the In-Panel Module (IPM), Front Area Module (FAM), or Rear Area Module (RAM) as applicable. These indicators are: Gearbox status Oil pressure Sediment fuel filter Vacuum Brake fluid Washer fluid Seat belt Park brake Charging voltage Turn indicators High beam Front fog Doors open Tailgate open Stop lamp failure front and rear
2. Functional Diagram

Gearbox Status

The status of the gearbox is sent on the CAN network when the CAN network is available.

Oil Pressure Switch Status

The status of the oil pressure switch is sent on the CAN network when the CAN network is available.

Fuel Filter Status

The FAM receives on digital input the status of the fuel filter (Fuel Filter Input) and sends it (Fuel filter switch) on the CAN network.

Seat Belt Warning Status

The IPM receives on digital input the status of the seat belt switch and sends the seat belt warning on the CAN network.

If the Ignition switch status is in RUN or START when the Seat Belt Sw Input is FASTENED, the seat belt warning indicator is blinking for 6 seconds.

When Seat Belt switch Input is NOT FASTENED, the seat belt warning indicator is blinking for 6 seconds.

If the Seat Belt switch Input is FASTENED during the 6 seconds, the seat belt warning indicator is blinking till the end of the 6 seconds.

In North America

the seat belt warning indicator is blinking when Ignition switch is on the status RUN or START and Seat Belt Sw Input is NOT FASTENED.

Parking Brake Indicator

The indicator manages 3 functions: brake fluid sensor, parking brake warning and vacuum switch.

The vacuum function is available for diesel engine only.

The FAM receives on digital input the status of the vacuum switch and the ABS EBD warning and sends them on the CAN network.

The status of the vacuum switch and the ABS EBD warning are sent on the CAN network when the CAN network is available.

The FAM receives on digital input the status of the brake fluid sensor and sends it on the CAN network.

The status of the brake fluid sensor is sent on the CAN network when the CAN network is available.

The IPM receives on digital input the status of the parking brake switch and by CAN network the status of the vacuum switch, the status of the ABS EBD warning, the status of the brake fluid sensor and the speed of the vehicle.

The IPM sends the park brake indicator control on the CAN network.

The indicator is lighted if the vacuum switch or ABS EBD warning are on or brake fluid sensor is low or park brake switch is on.

If the speed of the vehicle is over 10 km/h and ignition switch is on the status RUN the park brake indicator control is blinking at 50% duty in 0.6 second if Parking Brake switch Input is active. In this case Vacuum switch, ABS EBD warning and Brake Fluid sensor are ignored.

The park brake indicator is blinking on the same time that the chime is ringing. If a CAN signal among Vacuum switch, EBD warning or Brake Fluid Sens switch is INVALID, out of range or not received this CAN signal is considered to be OFF.

If Vehicle Speed CAN signal is INVALID or not received, it is considered to be 0 kph.

Charging Voltage Control

The IPM receives on analog input the voltage of generator and sends a warning.

When the voltage of generator L pass strictly above 10V, the state of the CAN variable.

Turn Indicators Status

The status of the turn indicators are sent on the CAN network when the CAN network is available.

High Beam Status

The status of the high beam is sent on the CAN network when the CAN network is available.

Front Fog Lamp Status

The status of the front fog lamp (lightning and state of the bulbs) is sent on the CAN network when the CAN network is available.

Doors Open Warning

The RAM receives on digital input the status of the driver door open switch and sends it on the CAN network.

The RAM receives on digital input the status of the passenger door open switch and sends it on the CAN network.

The RAM receives on digital input the status of the left sliding door open switch and sends it on the CAN network.

The RAM receives on digital input the status of the right sliding door open switch and sends it on the CAN network.

When vehicle speed is under 10 kph, with ignition key not inserted and any door OPEN, Doors Open Wng Ctrl stays ON for 20 min and then is turned OFF.

Tailgate Open Switch Status

When vehicle speed is under 10 kph, ignition key is inserted and Tailgate open switch is OPEN, Tailgate Open warning stays ON forever (IPM can enter sleep mode).

When vehicle speed is under 10 kph, with ignition key not inserted and gate open switch is OPEN, Tailgate Open warning stays ON for 20 min and then is turned OFF.

Scheme 32

1. The chime warns the driver that a problem is occurred. These warning are: Seat belt Parking on Over speed Key reminder Light Warning Doors Open Tailgate open warning
2. Chime sound priority: 1st: Seatbelt warning 2nd: Overspeed warning 3rd: Door open warning 4th: T/Gate open warning 5th: Key operated warning 6th: Parking Brake warning 7th: Light ON warning 8th: Key learning sound
3. If two different warning condition happen at the same time, chime should work only for the highest warning condition.
4. Cluster indicators should work for two warning behavior.
5. Behavior Description

Seat Belt Warning

The IPM receives on digital input the status of the seat belt switch.

The chime is activated during 6 second when the seat belt is not fastened.

The chime will stop immediately if the seat belt is fastened during the 6 seconds of the chime.

Park Brake Warning

The IPM receives on digital input the status of the parking brake switch.

The IPM receives the speed of the vehicle by the CAN network.

The chime is activated when the parking brake is on, ignition switch is on RUN and speed vehicle is over 10 km/h.

The park brake indicator is blinking at the same time that the chime is ringing.

Over Speed Warning

The IPM receives the overspeed warning by the CAN network.

The chime is activated when the overspeed speed warning is on the state Overspeed.

Key Reminder Warning

The IPM receives the status of the key on digital input.

The IPM receives the status of the driver door open switch by the CAN network.

The chime is activated when key is inserted and the driver door is open.

Light Warning

The IPM receives the status of the driver door open switch by the CAN network.

The light chime warning is activated when the driver door is open and the park and tail lamps are turned on.

The RAM receives on digital input the status of the driver / passenger / left sliding / right sliding door open switch and sends it on the CAN network.

The IPM receives by CAN network the speed of the vehicle.

The doors open warning chime is activated when one or several of the 4 doors is opened and the speed of vehicle is over 10 km/h.

Tailgate Open Warning

The RAM receives on digital input the status of the tailgate open switch and sends it on the CAN network.

The IPM receives by CAN network the speed of the vehicle.

The tailgate open warning chime is activated when the tailgate is opened and the speed of vehicle is over 10 km/h.

Scheme 33

1. The aim of this function is to receive the key fob signal and decode it. There are 8 different data included in the radio frequency frame sent by the RKE to the IPM module: Central door lock Central door unlock Panic function Driver door window close (long press on RKE lock button) Driver door window open (long press on RKE unlock button) Left sliding door open/close Right sliding door open/close Power tailgate open/close
2. Each vehicle can have at most 2 associated key fobs. The key fob is physically separated from the key itself (separate device).
3. Input/Output Definition and Characteristics

Scheme 34

1. Central locking/unlocking logic is controlled by IPM. Locking/Unlocking inputs are located in ADM, DDM (Lock/Unlock switch, door knobs, door key cylinder) and in IPM (RKE receiver).
2. Locking/Unlocking actuators are located in ADM for passenger door, DDM for driver door and RAM for sliding doors and tailgate. There are 5 ways of operating central lock/unlock: With Key RKE With Door Lock/Unlock switches located on ADM/DDM With Door Lock Monitoring switches located on the passenger/driver door With Door/Tailgate Key Cylinder Lock/Unlock switches located on the tailgate or passenger/driver door.
3. Functional Diagram

Scheme 35

1. Key reminder door unlock does not take into account the lock/unlock commands from RKE, key cylinder or door lock switches. It only takes into account the state of the door lock monitoring switch, key reminder switch and door open status in order to proceed with the unlock sequence or not.
2. Functional Diagram

Scheme 36

1. Working Conditions RKE panic function is only active when the key is out of key cylinder. Once started, panic operation is not stopped when ignition key is inserted, ignition is ACC, RUN or START, or door is opened or closed.
2. Functional Diagram

Scheme 37

1. Working Conditions Required key positions: At any position of the key in the cylinder for the horn stalk activation, At Key out from the key cylinder for the horn lock activation or for panic activation.
2. Functional Diagram

Scheme 38

1. Basic Concept The following functions are related to the RKE and burglar alarm systems. Door locking Door unlocking PSD open/close (both for left and right) PTG open/close Panic If IGN key is inserted into the key cylinder, the RKE transmitter functions are inoperative. Door locking by RKE signal: Whenever this signal is received, door LOCK pulse is always issued. Hazard lamp flashes one time for 1 second depending on the burglar alarm state. This signal will make the system possible to enter into the ARM state (or PREARM state depending on the vehicle condition). Door unlocking by RKE signal. Whenever this signal is received, door UNLOCK pulse is always issued. Hazard lamp flashes two times whenever the key fob unlock signal is received. This signal will make the system possible to enter into the DISARM or 30 sec DELAY state depending on Condition A is true or not. LH or RH PSD open/close by RKE signal. Only with the information received by RKE, the burglar alarm system cannot distinguish the OPEN signal from CLOSE signal. RAM will pass this signal to LH PSD and RH PSD then the burglar alarm state is decided depending on the vehicle condition. PTG open/close Only with the information received by RKE, the burglar alarm system cannot distinguish the OPEN signal from CLOSE signal. RAM will pass this signal to PTG module then the burglar alarm state is decided depending on the vehicle condition. Panic by key fob Whenever this signal is received, the PANIC function is activated (unless the system is already in an ALARM state). Mechanical key on the driver door, assist door and tail gate door It is possible to ARM or DISARM the system.
2. Functional Diagram

Arm Mode

1. If 30 second timer is elapsed without any changes from the ARM WAIT mode, then system goes to ARM mode.
2. Whenever RKE lock signal is received in the ARM state, then the system makes a hazard flash (1 second) and sends a door lock pulse.

PREARM Mode

1. If the vehicle is locked using the RKE transmitter or the door lock cylinder, and one or more doors are in an OPEN state, the system issues a LOCK pulse and enters a PREARM state. In the "PREARM state, the hazard lamps do not flash".
2. If all doors are closed in the PREARM state, the system enters ARM WAIT mode, and the hazard lamps will flash once.
3. During PREARM state, if f key reminder switch is ON & IGN 1 & IGN 2 are turned on in this state, the system immediately goes to DISARM state.

Scheme 39

1. The ARM WAIT mode is active for 30 seconds. If any entrance (hood, doors, tailgate) is opened, any lock knob is moved to an UNLOCK state, or the ignition switch is turned ON, the system will immediately enter DISARM mode. The system will enter ARM state if none of the previously mention conditions occur during the 30-second ARM WAIT mode. T1: 0.5 sec T2: 1.0 ± 0.1 sec

Disarm Mode

1. If RKE unlock signal is received, then UNLOCK output is issued together with the flashing of hazard lamp (two times) and the system enters into the DISARM condition.
2. If mechanical key switch unlock signal is received, then UNLOCK output is issued for 500ms and the system enters into the DISARM condition.
3. When entering into DISARM from ALARM state, current alarm will be cancelled and burglar alarm relay drive output is turned off.
4. When RKE unlock signal is received again in the DISARM state, UNLOCK output is issued again and hazard lamp is flashed also (two times).

Scheme 40

1. If one or more of entrances are opened in the ARM or REARM state, then Burglar alarm relay drive output is turned ON in order to inhibit the start condition, and hazard lamp and siren are activated for 3 consecutive cycle of 27 seconds duration.
2. Siren output and hazard lamp should be synchronized to get the same output period.
3. Even though all the doors are closed during alarm, alarm continues to operate it for the remaining time.
4. When there is a new attack (with one of the entrance is still open) in the vehicle after completing the alarm output, alarm should not be started again. T1: 27 sec (-0, +3 sec) T2: 10 sec (-0, +3 sec) T3: 0.5 ± 0.1 sec

After Alarm State

1. If ALARM cycle is elapsed, the system goes into AFTER ALARM state.
2. During this state, Burglar alarm relay drive output maintains ON. Siren and hazard lamp output are stopped.
3. If another entry is opened during the AFTER ALARM state, the burglar alarm relay drive output remains ON, but the siren will not be re-activated.

Rearm State

1. If all entrances are is closed during AFTER ALARM state, the system goes into REARM state.

Panic

1. If RKE PANIC signal is received, Siren output and hazard lamp operate for 27 seconds and the system return to the previous state as soon as the PANIC function finishes.
2. The PANIC function will be stopped if any RKE signal is received during PANIC activation.
3. If Key reminder switch is ON during PANIC function is operating, PANIC is stopped immediately.
4. If the system goes to ALARM mode during PANIC function is operating, PANIC is stopped immediately and then ALARM function should be activated.
5. During ALARM state; If RKE PANIC signal is received, ALARM mode is maintained and PANIC function should be ignored. ALARM has higher priority than PANIC function.
6. During AFTER_ALARM state; If RKE PANIC signal is received, AFTER_ALARM mode is maintained and PANIC function should be activated.

Safe & Rescue Mode

The goal of those modes is to be able to cope with failures that may happen on some of the most critical functionalities (for the driver security) of the system.

Safe Mode

The safe mode is entered in case of system problems such as

1. Incoherent inputs on monitored signals. In this case, safe mode is the debouncing time before the inputs are considered INVALID. Note that today, we have no way to detect if the rain/light sensor is in working operation or not. It means that a driver action will be required in case of failure of this sensor
2. Loss of the CAN frame containing the monitored signal
3. Loss of the CAN network: CAN goes to BUS OFF state, safe mode is the time necessary for detecting the BUS OFF state.

In all cases, the action in safe mode is to maintain the previous state of the system (for lighting and wiping). The list of monitored signals is the same as in rescue mode

Exiting Safe Mode

The software safe mode is exited and the module goes back to the normal mode when

1. On IPM, hardware inputs return to a coherent state
2. The lost CAN signal comes back while timeout has not elapsed
3. The CAN network returns to a normal state without reaching BUS OFF state.

Software safe mode is also exited when the software rescue mode is entered (problem does not disappear).

Hardware safe mode is exited and the module goes back to normal mode if the internal problem disappears (watchdog is properly triggered again). If the problem stays, hardware safe mode is exited to enter hardware rescue mode.

Rescue Modes

The rescue mode consists in activating some safety functions when IGN2 = ON

1. Switch on the low beams (FAM), park lamps (FAM), tail lamps (RAM) and cluster backlighting (IPM)
2. Unlock of all the doors when the rescue mode is entered with IGN2 = ON
3. Front wipers do not need to be turned on by software in rescue mode because wipers can be turned on by manually setting the MF switch to low speed. The FAM software must keep the same state as before entering the rescue mode.
4. When IGN2 = OFF, low beams, park/tail lamps and cluster backlighting are turned off.

Entering Rescue Modes

Rescue mode is entered when some important CAN signal or hardware input are not available. Rescue mode is entered when one of the following conditions is true

IPM

1. Timeout on CAN signal Inhibit Sw Sts, to detect loss of CAN connection with FAM.
2. Timeout on CAN signal Stop Lp Error Sts, to detect loss of CAN connection with RAM.
3. MF Light Switch information is invalid: when the signals coming from MF Light Switch are not coherent for more than 2 s, CAN signal Park Tail Head Lp Ctrl is sent with INVALID value and rescue mode is entered.
4. Front Wiper MF Switch information is invalid: when the signals coming from Front Wiper MF Switch are not coherent for more than 2 s, CAN signal F Wiper Ctrl is sent with INVALID value and rescue mode is entered.
5. CAN is in Bus Off state

RAM

1. Timeout on CAN signal Inhibit Sw Sts, to detect loss of CAN connection with FAM.
2. Timeout on CAN signal Park Tail Head Lp Ctrl or F Wiper Ctrl, to detect loss of CAN connection with IPM.
3. Park Tail Head Lp Ctrl = INVALID or unknown value
4. F Wiper Ctrl = INVALID or unknown value
5. CAN is in Bus Off state

FAM

1. Timeout on CAN signal Stop Lp Error Sts, to detect loss of CAN connection with RAM
2. Timeout on CAN signal Park Tail Head Lp Ctrl or F Wiper Ctrl, to detect loss of CAN connection with IPM
3. Park Tail Head Lp Ctrl = INVALID or unknown value
4. F Wiper Ctrl = INVALID or unknown value
5. CAN is in Bus Off state

For all CAN signals, timeout duration is 2.5 times signal periodicity.

Scheme 41

Scheme 42

Scheme 43

Scheme 44

Scheme 45

Scheme 46

Scheme 47

1. The diagnosis tool supports quick diagnosis of supported body electrical systems through input/output monitoring. and actuation testing.
2. To diagnose the BCM function, select the menu of model and body control module.
3. Select the module menu to diagnose.
4. The CURRENT DATA function is used to monitor input/output conditions.
5. Use the ACTUATION TEST mode to force output devices to operate for testing purposes.
6. Use the "DIAGNOSTIC TROUBLE CODES" mode.

Scheme 48

1. The body network system consists of several ECUs that communicates via a CAN bus. The diagnostic tester is not directly connected to the CAN bus, but utilizes a one-wire communication line (K-line) that connects to a gateway in the IPM ECU.
2. The IPM communicates with the diagnostic tester directly. But other units operate self diagnostic, input/output monitoring and actuator operation via the IPM using the CAN communication.

In-Panel Module (IPM)

IPM REFERENCE

Front Area Module (FAM)

FRONT AREA MODULE REFERENCE

Rear Area Module (RAM)

REAR AREA MODULE REFERENCE

Driver Door Module (DDM)

DRIVER DOOR MODULE REFERENCE

Assist Door Module (ADM)

ASSIST DOOR MODULE REFERENCE

IMS Module

IMS MODULE REFERENCE

IPM Actuator List

IPM ACTUATOR LIST

FAM Actuator List

FAM ACTUATOR LIST

RAM Actuator List

RAM ACTUATOR LIST

DDM Actuator List

DDM ACTUATOR LIST

ADM Actuator List

ADM ACTUATOR LIST

IMS Actuator List

IMS ACTUATOR LIST

Scheme 49

Scheme 50

1. Disconnect the negative (-) battery terminal.
2. Remove the crash pad lower panel (A). Refer to CRASH PAD .
3. Remove the keyless antenna cable and Instrument Panel Module (IPM) (A) after loosening 3 nuts and disconnecting 5 connectors.
4. Installation is the reverse of removal.

Front Area Module (FAM)

Scheme 51

Scheme 52

1. Disconnect the negative (-) battery terminal.
2. Remove the FAM cover from the engine room.
3. Remove the 2 FAM connectors (A) and battery terminal nut (B).
4. Remove the IPM (B) from the splash shield (C) after loosening the 3 IPM mounting bolts (A) and the IPM mounting clip.
5. Disconnect the connector from the splash shield.
6. Installation is the reverse of removal.

Scheme 53

1. Disconnect the negative (-) battery terminal.
2. Remove the left luggage side trim Refer to LUGGAGE SIDE TRIM REPLACEMENT .
3. Remove the RAM (A) after loosening the 7 connectors and the 3 RAM mounting bolts (A).
4. Installation is the reverse of removal.
