Specification
| Piece | 3 pcs |
|---|---|
| Spool | 20 ea |
| Control | Full line pressure variable control Torque converter release control |
| Solenoid valve | VFS: 6 ea ON/OFF: 2 ea |
| Pressure adjusting | 7 ea Line pressure (1), Reducing pressure (2), PCV (4) |
| Terminal type | Module |
VALVE BODY SPECIFICATION
Scheme 28
Scheme 29
Scheme 30
Scheme 31
- Remove the battery and the battery tray. Refer to BATTERY .
- Remove the under cover (A). Under cover installation bolt: 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft)
- Replace new gasket and the plug after draining the automatic transaxle fluid by removing the drain plug. Refer to «AUTOMATIC TRANSAXLE SYSTEM»(ref-674584) .
- Remove the valve body cover (A) and eyebolt (B). Tightening torque: 12.8 ~ 14.7 N.m (1.3 ~ 1.5 kgf.m, 9.4 ~ 10.8 lb-ft) 34.3 ~ 44.1 N.m (3.5 ~ 4.5 kgf.m, 25.3 ~ 32.6 lb-ft) CAUTION: Use new eyebolt gasket. NOTE: Remove installation bolts in the engine room first and then remove others under the vehicle.
- Remove the plate and the detent spring (A) after removing the bolt. Tightening torque: 24.5 ~ 35.3 N.m (2.5 ~ 3.6 kgf.m, 18.1 ~ 26.0 lb-ft)
- Remove the bolt (3 ea) after disconnecting the solenoid valve (B) connector and the oil temperature sensor connector (A). Tightening torque: 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft)
- Remove the valve body assembly (A).
Tightening torque
9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft)
Scheme 32
| Item | Function | Piece | Specification |
|---|---|---|---|
| VFS | 26/B T/Con | 2 | Control pressure: 9.81 ~ 500.14 kPa (0.1~5.1 kgf/cm 2 , 1.42~72.54 psi) Current value: 50 ~ 850mA Low Type, 5.1ohms |
| Line pressure control | 1 | Control pressure: 500.14 ~ 9.81 kPa (5.1~0.1 kgf/cm 2 , 72.54~1.42 psi) Current value: 50 ~ 850mA High Type, 5.1ohms | |
| 35R UD OD | 3 | Control pressure: 500.14 ~ 9.81 kPa (5.1~0.1 kgf/cm 2 , 72.54 ~ 1.42 psi) Current value: 50 ~ 850mA High Type, 5.1ohms | |
| On/Off | SS-A SS-B 2 | 2 | Control pressure: 490.33 kPa (5.0 kgf/cm 2 , 71.12 psi) 10 ~ 11ohms Low Type |
SOLENOID VALVE SPECIFICATION
