Scheme 33
Solenoid Valve Operation Table
| SS-A | SS-B | UD-VFS | OD-VFS | 35R-VFS | 26-VFS | |
|---|---|---|---|---|---|---|
| N/H | N/H | N/H | N/L | |||
| N, P | ||||||
| 1 | Delta | Delta | ||||
| 2 | ||||||
| 3 | ||||||
| 4 | ||||||
| 5 | ||||||
| 6 | ||||||
| L | ||||||
| R |
SOLENOID VALVE OPERATION REFERENCE
Scheme 34
Scheme 35
Scheme 36
Scheme 37
- Remove the battery and the battery tray. Refer to BATTERY .
- Remove the under cover (A). Under cover installation bolt: 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft)
- Replace new gasket and the plug after draining the automatic transaxle fluid by removing the drain plug. Refer to «AUTOMATIC TRANSAXLE SYSTEM»(ref-674584) .
- Remove the valve body cover (A) and eyebolt (B). Tightening torque: 12.8 ~ 14.7 N.m (1.3 ~ 1.5 kgf.m, 9.4 ~ 10.8 lb-ft) 34.3 ~ 44.1 N.m (3.5 ~ 4.5 kgf.m, 25.3 ~ 32.6 lb-ft) CAUTION: Use new eyebolt gasket. NOTE: Remove installation bolts in the engine room first and then remove others under the vehicle.
- Remove the bolt (3 ea) after disconnecting the solenoid valve connector (B) and the oil temperature sensor connector (A). Tightening torque: 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft)
- Remove the solenoid valve (A) after removing the solenoid support. CAUTION: When installing, apply the ATF oil or White Vaseline to the O-ring not to be damaged.
