Input Speed Sensor
Type: Hall effect sensor
| Operation condition (°C) °F | (-) 40 ~ 150) -40 ~ 302 | |
|---|---|---|
| Air gap (mm) in. | (0.95 ~ 1.55) 0.0374 ~ 0.0610 | |
| Output voltage (V) | High | 1.18 ~ 1.68 |
| Low | 0.59 ~ 0.84 | |
SPECIFICATIONS
Output Speed Sensor
Type: Hall effect sensor
| Operation condition (°C) °F | (-) 40 ~ 150) -40 ~ 302 | |
|---|---|---|
| Air gap (mm) in. | (0.95 ~ 1.55) 0.0374 ~ 0.0610 | |
| Output voltage (V) | High | (0.55 ~ 1) 0.0217 ~ 0.0394 |
| Low | 0.59 ~ 0.84 | |
SPECIFICATIONS
Oil Temperature Sensor
Type: Negative thermal coefficient type
| Item | Specification |
|---|---|
| Type | Negative Thermal Coefficient Type |
| Operation temperature | 40 ~ 165°C (-40 ~ 329°F) |
| Resistance | 4.68kohms ~ 43ohms |
| Fail-safe | Oil temperature set to default value [80°C (176°F)] |
SPECIFICATIONS
Inhibitor Switch
Type: Combination of output signals from 4 terminals
| Power supply (V) | 12 |
|---|---|
| Output type | Pin to Pin |
SPECIFICATIONS
Direct control VFS [26/B, T/CON]
Control type: Normal low type
| Control Pressure kPa (kgf/cm, psi) | 9.81 ~ 500.14 (0.1 ~ 5.1, 1.42 ~ 72.54) |
|---|---|
| Current value (mA) | 50 ~ 850 |
| Internal resistance (ohms) | 5.1 |
Direct control VFS [UD/B, OD/C, 35R/C]
Control type: Normal high type
| Control Pressure kPa (kgf/cm, psi) | 500.14 ~ 9.81 (5.1 ~ 0.1, 72.54 ~ 1.42) |
|---|---|
| Current value (mA) | 50 ~ 850 |
| Internal resistance (ohms) | 5.1 |
Line Pressure Control VFS
Control type: Normal high type
| Control Pressure kPa (kgf/cm, psi) | 500.14 ~ 9.81 (5.1 ~ 0.1, 72.54 ~ 1.42) |
|---|---|
| Current value (mA) | 50 ~ 850 |
| Internal resistance (ohms) | 5.1 |
ON/OFF Solenoid Valve (SS-A, SS-B)
Control type: Normal low type
| Control Pressure kPa (kgf/cm, psi) | 490.33 (5.0, 71.12) |
|---|---|
| Internal resistance (ohms) | 10 ~ 11 |
Lubricants
| Item | Specified lubricant | Quantity |
|---|---|---|
| Transaxle fluid | ATF SP-IV or equivalent | 7.8L (2.06 U.S.gal., 8.24 U.S.qt., 6.86 Imp.qt.) |
LUBRICANTS SPECIFICATION
Sealant
| Item | Specified sealant |
|---|---|
| Valve body cover | LOCTITE FMD-546, THREE-BOND TB1281B or equivalent |
SEALANT SPECIFICATION
Special Service Tools
