Blower System: Overview Kia Carnival III

Scheme 50

Scheme 51

Scheme 52

1. Disconnect the negative (-) battery terminal.
2. Remove the crash pad. Refer to CRASH PAD REPLACEMENT .
3. Disconnect the connectors from the intake actuator, the blower motor and power MOSFET.
4. Remove the cowl cross bar assembly. Refer to COWL CROSS BAR ASSEMBLY REPLACEMENT .
5. Remove the blower unit (A) from the heater unit after loosening a mounting bolt and 2 screws. NOTE: Make sure that there is no air leaking out of the blower and duct joints.
6. Installation is the reverse order of removal.

Scheme 53

Scheme 54

1. Connect the battery voltage and check the blower motor rotation.
2. If the blower motor voltage is not operated well, substitute with a known-good blower motor and check for proper operation.
3. If the problem is corrected, replace the blower motor.

Scheme 55

Scheme 56

1. Disconnect the negative (-) battery terminal.
2. Disconnect the connector (A) of the blower motor.
3. Remove the blower motor (A) after loosening the mounting screws.
4. Installation is the reverse order of removal.

Scheme 57

Description

This has particle filter which eliminates foreign materials and odor. The particle filter includes odor filter as well as conventional dust filter to ensure comfortable interior environment.

Scheme 58

1. Open the glove box (B). Lower the glove box down completely by removing the glove box stopper (A) to the glove box.
2. Remove the filter cover (A) with pushing the knob.
3. Replace the air filter (B), install it after making sure of the direction of air filter.

Scheme 59

Note. In case of driving in an air-polluted area or rugged terrain, check and replace the air filter as frequently as possible.

Replacement period: 15, 000 km (9320 miles)

1. The intake actuator is located at the blower unit.
2. It regulates the intake door by signal from control unit.
3. Pressing the intake selection switch will shift between recirculation and fresh air modes.

Scheme 60

Scheme 61

1. Ignition "OFF"
2. Disconnect the intake actuator connector.
3. Verify that the actuator operates to the recirculation position when connecting 12V to the terminal 3 and grounding terminal 4.
4. Verify that the intake actuator operates to the fresh position when connecting in the reverse.
5. If the intake actuator is not operated well, substitute with a known-good intake actuator and check for proper operation.
6. If the problem is corrected, replace the intake actuator.

Scheme 62

1. Disconnect the negative (-) battery terminal.
2. Disconnect the intake actuator connector.
3. Loosen the mounting screw and then remove the intake actuator (A) from the blower unit. NOTE: Remove the intake actuator through the lower part of the passenger side crash pad.
4. Installation is the reverse order of removal.
