DIAGNOSTIC CODE INDEX
| DTC | Description |
|---|---|
| B16A7-00 | HIGH BEAM CAMERA ALIGNMENT PERFORMANCE- LEFT |
| B16A8-00 | HIGH BEAM CAMERA ALIGNMENT PERFORMANCE- RIGHT |
| B16A9-00 | HIGH BEAM CAMERA ALIGNMENT PERFORMANCE- TOP |
| B16AA-00 | HIGH BEAM CAMERA ALIGNMENT PERFORMANCE- BOTTOM |
| B17F3-00 | AUTO HIGH BEAM SYSTEM AIM |
| B210A-84 | SYSTEM VOLTAGE LOW |
| B210B-85 | SYSTEM VOLTAGE HIGH |
| B210D-84 | BATTERY VOLTAGE LOW |
| B210E-85 | BATTERY VOLTAGE HIGH |
| B223A-00 | AUTO HIGH BEAM ECU INTERNAL |
| U0010-00 | CAN INTERIOR BUS |
| U0141-00 | LOST COMMUNICATION WITH IPM (FCM/TIPM) |
| U0155-00 | LOST COMMUNICATION WITH CLUSTER/CCN |
DIAGNOSTIC CODE INDEX
B16A7-00-HIGH BEAM CAMERA ALIGNMENT PERFORMANCE- LEFT
For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .
WHEN MONITORED
With the ignition on.
SET CONDITION
The DTC will be set if the target light source is not within the correctable limits of the mirror.
POSSIBLE CAUSES
| Possible Causes |
|---|
| SMART BEAM CALIBRATION |
DIAGNOSTIC TEST
- TEST FOR INTERMITTENT CONDITION Turn the ignition on. Using the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes Perform the Smart Beam Calibration in accordance with the Service Information. Refer to «SMART BEAM , STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/exterior-lights/#lampslighting-exterior-service-information) . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .
B16A8-00-HIGH BEAM CAMERA ALIGNMENT PERFORMANCE- RIGHT
For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .
With the ignition on.
The DTC will be set if the target light source is not within the correctable limits of the mirror.
| Possible Causes |
|---|
| SMART BEAM CALIBRATION |
- CHECK FOR AN ACTIVE DTC Turn the ignition on. Using the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes Perform the Smart Beam Calibration in accordance with the Service Information. Refer to «SMART BEAM , STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/exterior-lights/#lampslighting-exterior-service-information) . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .
B16A9-00-HIGH BEAM CAMERA ALIGNMENT PERFORMANCE- TOP
For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .
With the ignition on.
The DTC will be set if the target light source is not within the correctable limits of the mirror.
| Possible Causes |
|---|
| SMART BEAM CALIBRATION |
- CHECK FOR AN ACTIVE DTC Turn the ignition on. Using the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes Perform the Smart Beam Calibration in accordance with the Service Information. Refer to «SMART BEAM , STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/exterior-lights/#lampslighting-exterior-service-information) . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .
B16AA-00-HIGH BEAM CAMERA ALIGNMENT PERFORMANCE- BOTTOM
For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .
With the ignition on.
The DTC will be set if the target light source is not within the correctable limits of the mirror.
| Possible Causes |
|---|
| SMART BEAM CALIBRATION |
- CHECK FOR AN ACTIVE DTC Turn the ignition on. Using the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes Perform the Smart Beam Calibration in accordance with the Service Information. Refer to «SMART BEAM , STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/exterior-lights/#lampslighting-exterior-service-information) . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .
B17F3-00-AUTO HIGH BEAM SYSTEM AIM
For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .
With the ignition on.
The DTC will be set if the target light source is not within the correctable limits of the mirror.
| Possible Causes |
|---|
| SMART BEAM CALIBRATION |
- CHECK FOR AN ACTIVE DTC Turn the ignition on. Using the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes Perform the Smart Beam Calibration in accordance with the Service Information. Refer to «SMART BEAM , STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/exterior-lights/#lampslighting-exterior-service-information) . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .
Scheme 45
For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .
With the ignition on.
The Auto High Beam Module detects the supply circuit voltage below 10.0 volts.
| Possible Causes |
|---|
| (F943) FUSED IGNITION SWITCH OUTPUT (RUN-START) CIRCUIT SHORTED TO GROUND |
| OPEN FUSE |
| AUTO HIGH BEAM MODULE (AHBM) |
Scheme 46
- CHECK FOR AN ACTIVE DTC Turn the ignition on. With the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes Go To 2 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .
- (F943) FUSED IGNITION SWITCH OUTPUT (RUN-START) CIRCUIT SHORTED TO GROUND Turn the ignition off. NOTE: The AHBM is part of the Rearview Mirror. Disconnect the AHBM (Rearview Mirror) harness connector. Measure the resistance between ground and the (F943) Fused Ignition Switch Output (Run-Start) circuit. Is the resistance below 10K Ohms? Yes Repair the short to ground in the (F943) Fused Ignition Run/Start circuit. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) . No Inspect the wiring and connectors for damage or shorted circuits. If OK, replace and program the AHBM (Rearview Mirror) in accordance with the Service Information. Refer to «MIRROR, REARVIEW , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/gauges-instrument-panels/#body-interior-exterior) . Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .
B210B-85-SYSTEM VOLTAGE HIGH
For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .
With the ignition on.
The Auto High Beam Module detects the (F943) Fused Ignition Switch Output (Run-Start) circuit voltage is shorted high.
| Possible Causes |
|---|
| (F943) FUSED IGNITION SWITCH OUTPUT (RUN-START) CIRCUIT SHORTED TO VOLTAGE |
| TOTALLY INTEGRATED POWER MODULE (TIPM) |
Scheme 47
- CHECK FOR ACTIVE DTC Turn the ignition on. With the scan tool, read the active DTCs. Does the scan tool display this DTC as active? Yes Go To 2 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .
- (F943) FUSED IGNITION SWITCH OUTPUT (RUN-START) CIRCUIT SHORTED TO VOLTAGE Turn the ignition off. Remove Fuse M15 from the TIPM. Disconnect the AHBM (Rearview Mirror) harness connector. Turn the ignition on. Measure the voltage of the (F943) Fused Ignition Switch Output (Run-Start) circuit. Is there any voltage present? Yes Repair the short to voltage in the (F943) Fused Ignition Switch Output (Run-Start) circuit. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) . No Inspect the wiring and connectors for damage or shorted circuits. If OK, replace the TIPM in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .
B210D-84-BATTERY VOLTAGE LOW
For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .
With the ignition on.
Battery voltage less than 9 volts for more than 15 seconds.
| Possible Causes |
|---|
| RESISTANCE IN THE GENERATOR CASE GROUND |
| GENERATOR OPERATION |
| GENERATOR FIELD CONTROL CIRCUIT OPEN |
| GENERATOR FIELD CONTROL CIRCUIT SHORTED TO GROUND |
| GROUND CIRCUIT OPEN |
| POWERTRAIN CONTROL MODULE (PCM) |
- CHECK FOR ANY POWERTRAIN CONTROL MODULES DTCS NOTE: Make sure the Battery is in good condition. Using the Midtronics Battery Tester, test the Battery before continuing. NOTE: Inspect the vehicle for after market accessories that may exceed the Generator System output. NOTE: Make sure the generator drive belt is in good operating condition. NOTE: Inspect the fuses in the TIPM. If an open fuse is found, use the wire diagram/schematic as a guide, inspect the wiring and connectors for damage. Turn the ignition on. With the scan tool, read active PCM DTCs. Does the scan tool display any active PCM DTCs? Yes Refer to «DIAGNOSTIC CODE INDEX - 3.0L DIESEL»(/jeep/grand-cherokee/wk2-2010-2013/remont/testing-diagnostics/#30l-diesel-diagnostic-code-index) or «DIAGNOSTIC CODE INDEX - NGC»(/jeep/grand-cherokee/wk2-2010-2013/remont/testing-diagnostics/#36l-57l-diagnostic-code-index) and perform the appropriate diagnostic procedure . No Check the above conditions that can cause a low voltage condition. Repair as necessary. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .
B210E-85-BATTERY VOLTAGE HIGH
For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .
With the ignition on.
Battery voltage greater than 16 volts for more than 15 seconds.
| Possible Causes |
|---|
| GENERATOR FIELD CONTROL CIRCUIT SHORTED TO BATTERY VOLTAGE |
| GENERATOR |
| POWERTRAIN CONTROL MODULE (PCM) |
- CHECK FOR ANY POWERTRAIN CONTROL MODULES DTCS NOTE: Make sure the Battery is in good condition. Using the Midtronics Battery Tester, test the Battery before continuing. NOTE: Inspect the vehicle for after market accessories that may exceed the Generator System output. NOTE: Make sure the generator drive belt is in good operating condition. NOTE: Inspect the fuses in the TIPM. If an open fuse is found, use the wire diagram/schematic as a guide, inspect the wiring and connectors for damage. Turn the ignition on. With the scan tool, read active PCM DTCs. Does the scan tool display any active PCM DTCs? Yes Refer to «DIAGNOSTIC CODE INDEX - 3.0L DIESEL»(/jeep/grand-cherokee/wk2-2010-2013/remont/testing-diagnostics/#30l-diesel-diagnostic-code-index) or «DIAGNOSTIC CODE INDEX - NGC»(/jeep/grand-cherokee/wk2-2010-2013/remont/testing-diagnostics/#36l-57l-diagnostic-code-index) and perform the appropriate diagnostic procedure . No Check the above conditions that can cause a high voltage condition. Repair as necessary. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .
B223A-00-AUTO HIGH BEAM ECU INTERNAL
For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .
With the ignition on.
The Auto High Beam Module detects an internal fault.
| Possible Causes |
|---|
| AUTO HIGH BEAM MODULE (AHBM) (REARVIEW MIRROR) |
- CHECK FOR AN ACTIVE DTC Turn the ignition on. With the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes Replace and program the Auto High Beam Module (Rearview Mirror) in accordance with the Service Information. Refer to «MIRROR, REARVIEW , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/gauges-instrument-panels/#body-interior-exterior) . Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .
U0010-00-CAN INTERIOR BUS
For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .
Continuously when the ignition is on.
Battery voltage between 10 and 16 volts.
Ignition Off Draw (IOD) fuse installed.
The controller detects a short to ground on the CAN Interior Bus (125K) (+) circuit or a short to voltage on the CAN Interior Bus (125K) (-) circuit.
| Possible Causes |
|---|
| (D265) CAN INTERIOR BUS(+) (125k) CIRCUIT SHORTED TO VOLTAGE |
| (D264) CAN INTERIOR BUS(-) (125k) CIRCUIT SHORTED TO GROUND |
| (D264) CAN INTERIOR BUS(-) (125k) CIRCUIT SHORTED TO THE (D265) CAN INTERIOR BUS(+) (125k) CIRCUIT |
| TOTALLY INTEGRATED POWER MODULE (TIPM) |
| ANY CAN INTERIOR BUS MODULE |
- VERIFY DIAGNOSTIC TROUBLE CODE (DTC) IS ACTIVE NOTE: Make sure the IOD fuse is installed and battery voltage is between 10 and 16 volts before proceeding. Using the scan tool, read active DTCs. Is this DTC active? Yes Refer to «DIAGNOSIS AND TESTING»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-dtcs-b10b4-to-b25ae) and perform the U0010-CAN Interior Bus diagnostic procedure. No Refer to «DIAGNOSIS AND TESTING»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#communication-non-dtc-based-diagnostics) and perform the Stored Lost Communication DTCs diagnostic procedure.
U0141-00-LOST COMMUNICATION WITH IPM (FCM/TIPM)
For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .
Continuously when the ignition is on.
Battery voltage between 10 and 16 volts.
Ignition Off Draw (IOD) fuse installed.
Totally Integrated Power Module (TIPM) is configured correctly.
Bus messages not received from the Integrated Power Module (TIPM) for approximately two to five seconds.
| Possible Causes |
|---|
| (D65) CAN C BUS(+) CIRCUIT SHORTED TO VOLTAGE |
| (D64) CAN C BUS(-) CIRCUIT SHORTED TO GROUND |
| TOTALLY INTEGRATED POWER MODULE (TIPM) POWER AND GROUND |
| TIPM NOT CONFIGURED CORRECTLY |
| TOTALLY INTEGRATED POWER MODULE (TIPM) |
| MODULE THAT SET THIS DTC |
- VERIFY THE DTC IS ACTIVE NOTE: Make sure the IOD fuse is installed and the battery is fully charged before proceeding. Turn the ignition on. With the scan tool, read active DTCs. Is the DTC active at this time? Yes Perform the U0141-Lost Communication with IPM (FCM/TIPM) diagnostic procedure. Refer to «DIAGNOSIS AND TESTING»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-dtcs-b10b4-to-b25ae) . . No Perform the Stored Lost Communication DTCs diagnostic procedure. Refer to «DIAGNOSIS AND TESTING»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#communication-non-dtc-based-diagnostics) . .
U0155-00-LOST COMMUNICATION WITH CLUSTER/CCN
For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .
Continuously when the ignition is on.
Battery voltage between 10 and 16 volts.
Ignition Off Draw (IOD) fuse installed.
Totally Integrated Power Module (TIPM) is configured correctly.
Bus messages not received from the Instrument Cluster (CCN) for approximately two to five seconds.
| Possible Causes |
|---|
| (D265) CAN INTERIOR BUS(+) (125k) CIRCUIT SHORTED TO VOLTAGE |
| (D264) CAN INTERIOR BUS(-) (125k) CIRCUIT SHORTED TO GROUND |
| INSTRUMENT CLUSTER POWER AND GROUND |
| TIPM NOT CONFIGURED CORRECTLY |
| INSTRUMENT CLUSTER (CCN) |
| MODULE THAT SET THIS DTC |
- VERIFY DTC IS ACTIVE NOTE: Make sure the IOD fuse is installed and the battery is fully charged before proceeding. Turn the ignition on. With the scan tool, read active DTCs. Is this DTC active? Yes Refer to «DIAGNOSIS AND TESTING»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-dtcs-b10b4-to-b25ae) and perform the U0155-Lost Communication with Cluster/CCN diagnostic procedure. No Refer to «DIAGNOSIS AND TESTING»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#communication-non-dtc-based-diagnostics) and perform the Stored Lost Communication DTCs diagnostic procedure.
