Frame and Bumpers Jeep Grand Cherokee WK2

Frames, Subframes & Crossmembers 59 illustrations ~4741 words

TORQUE SPECIFICATIONS

DescriptionN.mFt. LbsIn. Lbs.
Brake caliper guide pins5541
Engine cradle crossmember support bolts175129
Engine cradle stiffener bracket bolts2015
Engine mount nuts7555
Front bumper support bolts2619
Front bumper outer bolts980
Front hub nuts310229
Front propeller shaft bolts3224
Front shock clevis bolt217160
Front skid plate bolts2821
Front suspension skid plate bolts2821
Front tow hook bolts4735
Front tow hook bracket bolts4735
Front tow hook nuts2518.5
Fuel tank skid plate bolts2821
Power steering pressure line nut2821
Rear bumper support bolts5440
Rear lower shock clevis bolt235173
Rear suspension crossmember support bolts180133
Rear tow hook bolts165122
Rear tow hook support bracket bolt10074
Steering shaft coupler bolt4936
Trailer hitch bolts165122
Transfer case skid plate bolts2821
Transmission crossmember reinforcement bracket bolts5541
Transmission crossmember to frame bolts6145
Transmission crossmember to transmission mount bolts6145
Transmission skid plate bolts2821
Upper ball joint nut9570

SPECIAL TOOLS

6602 - Remover/Installer, Bushing 6602-2 - Remover/Installer, Bushing 8173-3 - Remover/Installer (Originally Shipped In Kit Number(s) 8180CC, 8263CC.) 8244 - Puller, Extension Housing (Originally Shipped In Kit Number(s) 8295CC.) 8534B - Support Fixture, Engine (Originally Shipped In Kit Number(s) 8534, 8534B, 8849, 9565.) 8838-2 - Screw Assembly (Originally Shipped In Kit Number(s) 8696, 8696CC, 8710, 8710CC, 8715.) 9031-7A - Installer, Bushing (Originally Shipped In Kit Number(s) 9074, 9076, 9090, 9329-SUP, 9396, 9515-SUP, 9516-SUP, 9517-SUP, 9518, 9519, 9540-SUP, 9541-SUP.) 9520-1 - Installer Disc (Originally Shipped In Kit Number(s) 9329, 9329-SUP, 9515-SUP, 9516, 9516-SUP, 9517-SUP, 9518, 9519, 9540-SUP, 9541-SUP.) 9520-4 - Cup, Receiver (Originally Shipped In Kit Number(s) 9329, 9329-SUP, 9515-SUP, 9516, 9516-SUP, 9517-SUP, 9518, 9519, 9540-SUP, 9541-SUP.) C-4150A - Press, Ball Joint (Originally Shipped In Kit Number(s) 6672, 6745.) C-4212F - Press, Ball Joint (Originally Shipped In Kit Number(s) 6745, 6880, 6881, MLR-C03.)

Scheme 1

Scheme 1: SPECIAL TOOLS
Scheme 1: SPECIAL TOOLS

Scheme 2

Scheme 2
Scheme 2

Scheme 3

Scheme 3
Scheme 3

Scheme 4

Scheme 4
Scheme 4

Scheme 5

Scheme 5: REMOVAL
Scheme 5: REMOVAL

Scheme 6

Scheme 6
Scheme 6
  1. Disconnect and isolate the negative battery cable.
  2. Remove the radiator grille assembly. Refer to «GRILLE , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/gauges-instrument-panels/#body-interior-exterior) .
  3. Remove the fasteners (5) that secure the hood latch assembly and the upper radiator support cross bracing.
  4. Remove both the side plastic air deflectors (1).
  5. Release the clips and position aside the power steering cooler assembly, if equipped.
  6. Release the clips securing the headlamp electrical harness and position the harness aside.
  7. Remove the push-pin type retainers (2) and remove the front bumper isolator pad (1).
  8. Remove the four bolts (4) securing the bumper beam to the vehicle frame
  9. Remove the outer two fasteners (3) that secure the bumper beam to the radiator closure panel and remove the beam (2).
  10. Remove the cross bracing from the bumper beam and any miscellaneous parts as needed.

INSTALLATION

  1. Install the cross bracing on the bumper beam (2) and transfer any miscellaneous parts as needed.
  2. Position the bumper and install the four bolts (4) securing the beam to the vehicle frame.
  3. Install the outer two bolts (3) that secure the beam to the radiator closure panel.
  4. Tighten the four inner Bolts (4) to 26 N.m (19 ft. lbs.) and the two outer bolts (3) to 9 N.m (7 ft. lbs.).
  5. Position the isolator pad (1) and install the push-pin type retainers (2).
  6. Position the headlamp electrical harness and secure in place.
  7. Position back and secure the power steering cooler assembly, if equipped.
  8. Install both the side plastic air deflectors (1).
  9. Install the hood latch assembly and upper radiator support cross bracing. Refer to «LATCH, HOOD , INSTALLATION»(/jeep/grand-cherokee/wk2-2010-2013/remont/gauges-instrument-panels/#body-interior-exterior) .
  10. Install the radiator grille assembly. Refer to «GRILLE , INSTALLATION»(/jeep/grand-cherokee/wk2-2010-2013/remont/gauges-instrument-panels/#body-interior-exterior) .
  11. Connect the negative battery cable.

Scheme 7

Scheme 7: REMOVAL
Scheme 7: REMOVAL

Scheme 8

Scheme 8
Scheme 8

Scheme 9

Scheme 9
Scheme 9
  1. Remove the plastic rivets (5) at each wheel well that secure the flares (1) to the fascia (4).
  2. Release the clips and partially remove both front fender flares.
  3. Remove the fasteners (3) that secure the wheel liners (2) to the fascia (4).
  4. Remove the 1/4 turn fasteners (1) and separate the lower wheel liner from the fascia.
  5. Remove the four lower retainers (4).
  6. Release the integral latches at the wheel well openings (2) and the radiator grille assembly.
  7. Disconnect the fog lamp electrical connectors (3), if equipped.
  8. Remove the fascia assembly (1).
  1. Position the front fascia (1) and connect the fog lamp electrical connectors (3), if equipped.
  2. Install the fascia, locking the integral latches at the radiator grille assembly and at the wheel well openings (2).
  3. Install the four lower retainers (4).
  4. Install the fasteners (3) that secure the wheel liners (2) to the fascia (4).
  5. Position the front fender flares (1) and press in place, engaging the retaining clips.
  6. Install new plastic rivets (5) to secure the fender flares.
  7. Install the 1/4 turn fasteners (1) and secure the lower wheel liner to the fascia.

Scheme 10

Scheme 10: REMOVAL
Scheme 10: REMOVAL

Scheme 11

Scheme 11
Scheme 11

Scheme 12

Scheme 12
Scheme 12
  1. Remove the plastic rivets (3) that secure the fender flares (1) to the rear fascia.
  2. Release the clips (2) and remove both rear fender flares.
  3. Open the rear liftgate (1).
  4. Remove the two lower retainers (4) at the rear support beam.
  5. Remove the fasteners (5) at the back sides of the quarter panels, in the liftgate opening.
  6. Remove the fasteners (3) on both sides at the wheel well openings.
  7. Release the integral latch features (2) at the sides and along the back and separate the fascia from the vehicle.
  8. Disconnect the body harness electrical connector (3) and remove the fascia.
  9. Remove both the park assist (5) and blind spot sensors (2), if equipped.
  10. Remove the sensor electrical harness.
  1. Install the park assist and blind spot sensors (5 and 2), if equipped.
  2. Install the sensor electrical harness, if equipped.
  3. Position the fascia onto the vehicle and connect the body harness electrical connector (3), if equipped.
  4. Slightly spread the sides of the fascia to clear the painted surfaces.
  5. position the fascia and then press into place at the sides and along the liftgate opening to engage the integral latches (2).
  6. Install the two lower retainers (4) at the rear support beam.
  7. Install the fasteners (5) at the liftgate opening.
  8. Install the fasteners (3) on both sides at the wheel well openings
  9. Position the fender flares and press firmly and evenly to engage the clips (2) and install both fender flares.
  10. Install new rivets (1) at the wheel wells to secure the fender flares (1) to the rear fascia.

USE OF HEAT DURING REPAIR

WARNINGChrysler Group LLC engineering's position on the use of heat during collision repair is as follows: Any body panel or frame component damaged which is to be repaired and reused, must be repaired using the "cold straightening" method. No heat may be used during the straightening process. During rough straightening prior to panel replacement, damaged panels or frame components may be heated to assist in body/frame realignment. The application of heat must be constrained to the parts which will be replaced and not allowed to affect any other components. This "no heat" recommendation is due to the extensive use of high strength and advanced high strength steels in Chrysler Group LLC products. High-strength materials can be substantially and negatively affected from heat input which will not be obviously known to the repairer or consumer. Ignoring these recommendations may lead to serious compromises in the ability to protect occupants in a future collision event, reduce the engineered qualities and attributes, or decrease the durability and reliability of the vehicle. This statement supersedes any previously released information by the Chrysler Group LLC. Failure to follow these instructions may result in serious or fatal injury.

WARNINGS

WARNINGUse an Occupational Safety and Health Administration (OSHA) approved breathing filter, when spraying paint or solvents in a confined area. Failure to follow these instructions may result in possible serious or fatal injury. avoid prolonged skin contact with petroleum or alcohol based cleaning solvents. do not stand under a hoisted vehicle that is not properly supported on safety stands. Failure to follow these instructions may result in possible serious or fatal injury.
CAUTIONWhen holes are drilled or punched in an inner body panel, verify the depth of space to the outer body panel, electrical wiring or other components. Damage to the vehicle can result. do not weld exterior panels unless combustible material on the interior of vehicle is removed from the repair area. Fire or hazardous conditions, can result. always have a fire extinguisher ready for use when welding. disconnect the negative (-) cable clamp from the battery when servicing electrical components that are live when the ignition is off. Damage to electrical system can result. do not use abrasive chemicals or compounds on painted surfaces. Damage to finish can result. do not use harsh alkaline based cleaning solvents on painted or upholstered surfaces. Damage to finish or color can result. do not hammer or pound on plastic trim panel when servicing interior trim. Plastic panels can break.

RESTRAINT WARNINGS

WARNINGTo avoid potential physical injury, or damage to sensitive electronic circuits and systems, always disconnect and isolate the battery negative (ground) cable and the positive cable, then ground the positive cable to discharge the ORC capacitor before performing any welding operations on the vehicle. Failure to take the proper precautions could result in accidental airbag deployment, possible damage to the Supplemental Restraint System (SRS) circuits and components, and possible damage to other electronic circuits and components. Whenever a welding process is being performed within 30 cm (12 in) of an electronic module/harness, then that module/harness should be relocated out of the way, or disconnected. Always protect against component or vehicle damage from weld spatter by using weld blankets and screens. Failure to follow these instructions may result in serious or fatal injury.
WARNINGTo avoid serious or fatal injury on vehicles equipped with the Supplemental Restraint System (SRS), never attempt to repair the electrically conductive circuits or wiring components related to the SRS for which there is no MOPAR wiring repair kit. It is important to use ONLY the recommended splicing kit and procedure. For applicable and available MOPAR wiring repair kits, please visit the MOPAR Connector Web Site at the following address on the Internet: (http://dto.vftis.com/mopar/disclaimer.asp). Inappropriate repairs can compromise the conductivity and current carrying capacity of those critical electrical circuits, which may cause SRS components not to deploy when required, or to deploy when not required. Only minor cuts or abrasions of wire and terminal insulation where the conductive material has not been damaged, or connector insulators where the integrity of the latching and locking mechanisms have not been compromised may be repaired using appropriate methods.
WARNINGTo avoid serious or fatal injury during and following any seat belt or child restraint anchor service, carefully inspect all seat belts, buckles, mounting hardware, retractors, tether straps, and anchors for proper installation, operation, or damage. Replace any belt that is cut, frayed, or torn. Straighten any belt that is twisted. Tighten any loose fasteners. Replace any belt that has a damaged or ineffective buckle or retractor. Replace any belt that has a bent or damaged latch plate or anchor plate. Replace any child restraint anchor or the unit to which the anchor is integral that has been bent or damaged. Never attempt to repair a seat belt or child restraint component. Always replace damaged or ineffective seat belt and child restraint components with the correct, new and unused replacement parts listed in the Chrysler Mopar® Parts Catalog. Failure to follow these instructions may result in possible serious or fatal injury.
WARNINGTo avoid serious or fatal injury on vehicles equipped with side curtain airbags, disable the Supplemental Restraint System (SRS) before attempting any Occupant Restraint Controller (ORC) diagnosis or service. The ORC contains a rollover sensor, which enables the system to deploy the side curtain airbags in the event of a vehicle rollover event. If an ORC is accidentally rolled during service while still connected to battery power, the side curtain airbags will deploy. Disconnect and isolate the battery negative (ground) cable, then wait two minutes for the system capacitor to discharge before performing further diagnosis or service. This is the only sure way to disable the SRS. Failure to take the proper precautions could result in accidental airbag deployment.
WARNINGTo avoid serious or fatal injury on vehicles equipped with airbags, disable the Supplemental Restraint System (SRS) before attempting any steering wheel, steering column, airbag, Occupant Classification System (OCS), seat belt tensioner, impact sensor or instrument panel component diagnosis or service. Disconnect and isolate the battery negative (ground) cable, then wait two minutes for the system capacitor to discharge before performing further diagnosis or service. This is the only sure way to disable the SRS. Failure to follow these instructions may result in accidental airbag deployment.
WARNINGTo avoid potential physical injury or damage to sensitive electronic circuits and systems, always disconnect and isolate the battery negative (ground) cable and the positive cable, then ground the positive cable to discharge the Occupant Restraint Controller (ORC) capacitor before performing any welding operations on the vehicle. Failure to take the proper precautions could result in accidental airbag deployment, possible damage to the Supplemental Restraint System (SRS) circuits and components, and possible damage to other electronic circuits and components. Whenever a welding process is being performed within 12 inches (30 centimeters) of an electronic module or wiring harness, then that module or harness should be relocated out of the way, or disconnected. Always protect against component or vehicle damage from weld spatter by using weld blankets and screens.
WARNINGTo avoid serious or fatal injury, do not attempt to dismantle an airbag unit or tamper with its inflator. Do not puncture, incinerate or bring into contact with electricity. Do not store at temperatures exceeding 93° C (200° F). An airbag inflator unit may contain sodium azide and potassium nitrate. These materials are poisonous and extremely flammable. Contact with acid, water, or heavy metals may produce harmful and irritating gases (sodium hydroxide is formed in the presence of moisture) or combustible compounds. An airbag inflator unit may also contain a gas canister pressurized to over 17.24 kPa (2500 psi). Failure to follow these instructions may result in possible serious or fatal injury.
WARNINGTo avoid serious or fatal injury when handling a seat belt tensioner retractor. Exercise proper care to keep fingers out from under the retractor cover and away from the seat belt webbing where it exits from the retractor cover. Failure to follow these instructions may result in possible serious or fatal injury.
WARNINGTo avoid serious or fatal injury, replace all Supplemental Restraint System (SRS) components only with parts specified in the Chrysler Mopar® Parts Catalog. Substitute parts may appear interchangeable, but internal differences may result in inferior occupant protection.
WARNINGTo avoid serious or fatal injury, the fasteners, screws, and bolts originally used for the Supplemental Restraint System (SRS) components must never be replaced with any substitutes. These fasteners have special coatings and are specifically designed for the SRS. Anytime a new fastener is needed, replace it with the correct fasteners provided in the service package or specified in the Chrysler Mopar® Parts Catalog.
WARNINGTo avoid serious or fatal injury when a steering column has an airbag unit attached, never place the column on the floor or any other surface with the steering wheel or airbag unit face down. Failure to follow these instructions may result in possible serious or fatal injury.

FRAME DIMENSIONS

Frame dimensions are listed in metric scale. All dimensions are from center to center of Principal Locating Point (PLP), or from center to center of PLP and fastener location.

VEHICLE PREPARATION

Position the vehicle on a frame alignment rack, refer to instructions provided with equipment being used. Adjust the vehicle PLP heights to the specified dimension above the work surface (datum line). Vertical dimensions can be taken from the datum line to the locations indicated were applicable.

DESCRIPTIONFIGURE
FRAME DIMENSIONS - TOP VIEW(Scheme 12)
FRAME DIMENSIONS - SIDE VIEWSee scheme 20

Scheme 13

Scheme 13
Scheme 13

Scheme 14

Scheme 14
Scheme 14

Scheme 15

Scheme 15: REMOVAL
Scheme 15: REMOVAL

Scheme 16

Scheme 16
Scheme 16

Scheme 17

Scheme 17
Scheme 17

Scheme 18

Scheme 18
Scheme 18

Scheme 19

Scheme 19
Scheme 19

Scheme 20

Scheme 20
Scheme 20

Scheme 21

Scheme 21
Scheme 21

Scheme 22

Scheme 22
Scheme 22

Scheme 23

Scheme 23
Scheme 23
  1. Remove the intake manifold. Refer to «MANIFOLD, INTAKE , REMOVAL»(ref-466389-S01614605892012042500000) or «MANIFOLD, INTAKE , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/mechanical/#36l-engine-service-information) or «MANIFOLD, INTAKE , REMOVAL , 5.7L»(/jeep/grand-cherokee/wk2-2010-2013/remont/mechanical/#57l-engine-service-information) .
  2. Remove the oil control solenoid, if equipped. Refer to «CONTROL VALVE, OIL INTAKE , REMOVAL , 5.7L»(/jeep/grand-cherokee/wk2-2010-2013/remont/mechanical/#57l-engine-service-information) .
  3. Support engine using engine support fixture (special tool #8534B, Support Fixture, Engine) (1) or equivalent.
  4. Remove the front skid plate. Refer to «PLATE, SKID, FRONT , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/frames-subframes-crossmembers/#frame-and-bumpers) and «PLATE, SKID, FRONT SUSPENSION , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/frames-subframes-crossmembers/#frame-and-bumpers) .
  5. Remove both brake calipers and hang to the side. Refer to «CALIPER, DISC BRAKE , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/mechanical-hydraulic/#base-brakes-service-information) .
  6. Remove the motor mount nuts. CAUTION: Steering column module is centered to the vehicles steering system. Failure to keep the system and steering column module centered and locked/inhibited from rotating can result in steering column module damage. Refer to «CLOCKSPRING , STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/airbag/#restraints-service-information) .
  7. Place the front wheels in the straight ahead position with the steering wheel centered and locked with a steering wheel lock.
  8. Drain or siphon the power steering system.
  9. Remove the steering shaft coupler pinch bolt (2) and disconnect the coupler (1) from the steering shaft (3).
  10. Disconnect the pressure line (1), and the return line (2) at the gear (3).
  11. Support the outside of the lower control arms with a suitable holding fixture, and raise to normal ride height.
  12. Remove the upper ball joint nuts.
  13. Separate the upper ball joints (2) from the knuckles (3) using Ball Joint Press (special tool #C-4150A, Press, Ball Joint) (1).
  14. Remove the shock clevis bracket to lower control arm nut/bolts (1).
  15. Remove the wheel and tire assemblies.
  16. Mark front propeller shaft (1) and pinion flange (2) for installation reference. Remove propeller shaft from pinion flange.
  17. Remove hub nuts (1) from half shafts (2). NOTE: Right side shown in illustration, left side similar.
  18. Using a grease pencil or equivalent, mark the location of the engine support cradle on the underbody.
  19. Remove the six frame brace bolts (2).
  20. Support the cradle (1) with suitable lifting device.
  21. Remove the four cradle bolts (3) and separate the engine cradle crossmember from the vehicle.

As necessary

  1. Remove the lower control arms. Refer to «ARM, LOWER CONTROL , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/suspension-front/#front-suspension-wheel-alignment__removal) .
  2. Remove the front drive axle. Refer to «REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/differentials-drive-axles/#front-axle-195fia__removal) .
  3. Remove the steering gear. Refer to «GEAR , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/manual-power-steering/#steering-system) .
  4. Remove the sway bar. Refer to «STABILIZER BAR, FRONT , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/suspension-front/#front-suspension-wheel-alignment) .

As necessary

  1. Install the lower control arms. Refer to «ARM, LOWER CONTROL , INSTALLATION»(/jeep/grand-cherokee/wk2-2010-2013/remont/suspension-front/#front-suspension-wheel-alignment__installation) .
  2. Install the front drive axle. Refer to «INSTALLATION»(/jeep/grand-cherokee/wk2-2010-2013/remont/differentials-drive-axles/#front-axle-195fia__installation) .
  3. Install the steering gear. Refer to «GEAR , INSTALLATION»(/jeep/grand-cherokee/wk2-2010-2013/remont/manual-power-steering/#steering-system) .
  4. Install the sway bar. Refer to «STABILIZER BAR, FRONT , INSTALLATION»(/jeep/grand-cherokee/wk2-2010-2013/remont/suspension-front/#front-suspension-wheel-alignment) .

Note. Right side shown in illustration, left side similar.

Scheme 24

Scheme 24
Scheme 24
  1. Raise the engine cradle into position guiding the engine mount into the engine mount bracket.
  2. Align the engine cradle to the marks made during removal and install the four engine cradle support bolts (3)
  3. Tighten the four support bolts (3) to 175 N.m (129 ft. lbs.).
  4. Tighten the six cradle stiffener bracket bolts (2) to 20 N.m (15 ft. lbs.).
  5. Support the outside of the lower control arm with a suitable holding fixture, and raise to position the upper ball joint (2) into the knuckle (3).
  6. With the holding fixture holding the suspension at normal ride height, install the upper ball joint nut (4) and tighten to 95 N.m (70 ft. lbs.).
  7. Support the outside of the lower control arm with a suitable holding fixture, and raise to normal ride height.
  8. Tighten the shock clevis bracket to lower control arm nut/bolt (1) to 217 N.m (160 ft. lbs.).
  9. Install the half shaft (2) hub nuts (1) and tighten to 310 N.m (229 ft. lbs.).
  10. Install the propeller shaft (1) with reference marks (3) aligned. NOTE: Clean propeller shaft bolts and apply Mopar Lock and Seal Adhesive or equivalent to the threads before installation.
  11. Install the propeller shaft bolts and tighten to 32 N.m (24 ft. lbs.).
  12. Connect the pressure line (1), and the return line (2) at the gear (3) and tighten to 28 N.m (21 ft. lbs.). CAUTION: The steering gear must be centered prior to installing the coupler to prevent clockspring damage.
  13. Connect the steering shaft coupler (1) to the steering shaft (3), install a new coupler pinch bolt (2) and tighten to 49 N.m (36 ft. lbs.).
  14. Lower the engine fully onto the engine mounts.
  15. Tighten the engine mount nuts (2) to 75 N.m (55 ft. lbs.).
  16. Install the brake calipers. Refer to «CALIPER, DISC BRAKE , INSTALLATION»(/jeep/grand-cherokee/wk2-2010-2013/remont/mechanical-hydraulic/#base-brakes-service-information) .
  17. Install the front skid plate. Refer to «PLATE, SKID, FRONT , INSTALLATION»(/jeep/grand-cherokee/wk2-2010-2013/remont/frames-subframes-crossmembers/#frame-and-bumpers) and «PLATE, SKID, FRONT SUSPENSION , INSTALLATION»(/jeep/grand-cherokee/wk2-2010-2013/remont/frames-subframes-crossmembers/#frame-and-bumpers) .
  18. Install the oil control solenoid, if equipped. Refer to «CONTROL VALVE, OIL INTAKE , INSTALLATION , 5.7L»(/jeep/grand-cherokee/wk2-2010-2013/remont/mechanical/#57l-engine-service-information) .
  19. Install the intake manifold. Refer to «MANIFOLD, INTAKE , INSTALLATION»(ref-466389-S06539073812012042500000) or «MANIFOLD, INTAKE , INSTALLATION»(/jeep/grand-cherokee/wk2-2010-2013/remont/mechanical/#36l-engine-service-information) or «MANIFOLD, INTAKE , INSTALLATION , 5.7L»(/jeep/grand-cherokee/wk2-2010-2013/remont/mechanical/#57l-engine-service-information) .
  20. Perform wheel alignment, paying special attention to thrust angle. If engine cradle crossmember needs to be shifted to align thrust angle. Refer to «WHEEL ALIGNMENT , STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/suspension-front/#front-suspension-wheel-alignment) .

Scheme 25

Scheme 25: REMOVAL
Scheme 25: REMOVAL

Scheme 26

Scheme 26
Scheme 26

Scheme 27

Scheme 27
Scheme 27

Scheme 28

Scheme 28
Scheme 28

Scheme 29

Scheme 29
Scheme 29

Scheme 30

Scheme 30
Scheme 30

Scheme 31

Scheme 31
Scheme 31

Scheme 32

Scheme 32
Scheme 32
  1. Raise and support the vehicle. Refer to «JACKING AND HOISTING LIFT POINTS»(/jeep/grand-cherokee/wk2-2010-2013/remont/fuses-circuit-breakers/#vehicle-quick-reference) .
  2. On each side of vehicle rear, remove wheels. Refer to «WHEELS , STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/wheel-tire-system/#tires-wheels-service-information) .
  3. Remove the rear drive shaft. Refer to «SHAFT, DRIVE, REAR , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/driveshaft-universal-joints/#propeller-shaft) . NOTE: Front rotor shown in illustration, rear rotor similar.
  4. Bottom caliper pistons into the caliper.
  5. Remove the brake caliper tension clip (1) by pressing rearward on the front of the clip (2) while pulling the clip out (3) from the caliper.
  6. Remove the caliper slide dust bolt shields and loosen the brake caliper slide bolts (guide pins) (1). CAUTION: Never allow the disc brake caliper to hang from the brake hose. Damage to the brake hose will result. Provide a suitable support to hang the caliper securely.
  7. Remove the brake caliper (2) from the caliper adapter (3) and hang the brake caliper (2).
  8. Disconnect the brake cable end from the equalizer (3).
  9. Disconnect both wheel speed sensor wiring connectors (1) from the wiring harness connectors (2).
  10. Support the outboard end of the lower control arm with a suitable holding fixture.
  11. Remove the lower shock bolt and nut (3).
  12. Lower the support on the outboard end of the lower control arm just enough to tilt the shock (1) into position for removal between the front and rear arms of the lower control arm. 1 - BODY 2 - MARKER (OR CRAYON) 3 - CROSSMEMBER BUSHING FLANGE
  13. Carefully mark location of rear crossmember on body at all four mount (bushing) locations using a marker or crayon. Do not use a scratch awl to mark location.
  14. Position an extra pair of jack stands under and support forward end of engine cradle to help stabilize vehicle during rear suspension removal/installation.
  15. Position under-hoist utility jack or transmission jack (2) under center of rear crossmember (1). Raise jack head to contact crossmember and secure in place. When securing crossmember to jack, be sure not to secure stabilizer bar.
  16. Remove the four crossmember bolts (2) and remove the crossmember (1).

Scheme 33

Scheme 33: INSTALLATION
Scheme 33: INSTALLATION

Scheme 34

Scheme 34
Scheme 34
  1. Install rear crossmember (1) on jack (2) head in same position in which it was removed and secure in place.
  2. Raise crossmember to body mounting points. As crossmember is raised, align shocks (3) with pockets in spring links. Do not install bolts at this time.
  3. Continue to raise crossmember (1) with jack until crossmember mounting bolts (2) can be installed. Install left side crossmember mounting bolts, but not the right side bolts. It is not necessary to tighten bolts at this point. 1 - BODY 2 - MARKER (OR CRAYON) 3 - CROSSMEMBER BUSHING FLANGE
  4. Shift crossmember as necessary to line up mounts (3) with location marks drawn on body (1) before removal.
  5. Continue to raise crossmember (1) with jack until crossmember mounting bolts (2) can be installed. Install left side crossmember mounting bolts, but not the right side bolts. It is not necessary to tighten bolts at this point. CAUTION: To avoid damaging other components of vehicle, do not lower crossmember any further than necessary to install coil spring (2).
  6. Slowly lower jack allowing right side of crossmember to drop. Do not lower jack at a fast rate. Lower jack just enough to allow spring (2) Installation. Do not lower jack any further than necessary. NOTE: Before installing coil spring, make sure isolators (1 and 5) are completely installed on ends of spring.
  7. Install coil spring (2) with isolators into spring pocket of spring link fitting the lower isolator to the shape of the pocket, then align top of spring with body mount.
  8. Carefully raise jack, guiding coil spring and lower end of shock absorber (1) into mounted positions. Once shock absorber (1) lower mounting hole lines up with hole in control arm, stop jacking.
  9. Install the lower shock bolt/nut (3). Raise the support on the lower control arm to normal ride height and tighten the bolt/nut to 235 N.m (173 ft. lbs.).
  10. Raise right side of crossmember (1) into mounted position. Install right side crossmember mounting bolts (2). Snug, but do not fully tighten bolts at this time.
  11. Remove both front and rear crossmember mounting bolts (2) on left side of vehicle. CAUTION: To avoid damaging other components of vehicle, do not lower crossmember any further than necessary to install coil spring (2).
  12. Slowly lower jack allowing left side of crossmember to drop. Do not lower jack at a fast rate. Lower jack just enough to allow spring (2) Installation. Do not lower jack any further than necessary. NOTE: Before installing coil spring, make sure isolators (1 and 5) are completely installed on ends of spring.
  13. Install coil spring (2) with isolators into spring pocket of spring link fitting the lower isolator to the shape of the pocket, then align top of spring with body mount.
  14. Carefully raise jack, guiding coil spring and lower end of shock absorber (1) into mounted positions. Once shock absorber (1) lower mounting hole lines up with hole in the control arm, stop jacking.
  15. Install the lower shock bolt/nut (3). Raise the support on the lower control arm to normal ride height and tighten the bolt/nut to 235 N.m (173 ft. lbs.).
  16. Raise left side of crossmember (1) into mounted position. Install left side crossmember mounting bolts (2 and 3). Snug, but do not fully tighten bolts at this time.
  17. Once mounts are lined up with location marks, on both sides of vehicle, tighten all four crossmember mounting bolts (2) to 180 N.m (133 ft. lbs.)
  18. Route the wheel speed sensor and connect the wheel speed sensor wiring connector (1) to the wiring harness connector (2).
  19. Attach the wheel speed sensor (1) wiring routing clip (not shown in illustration) to the top of the cradle (3).
  20. Connect the brake cable end to the equalizer (3). NOTE: Front rotor shown in illustration, rear rotor similar. NOTE: Caliper slide pins should be free from debris.
  21. Position the brake caliper/pads and tighten the brake caliper slide bolts (guide pins) (1) to 55 N.m (41 ft. lbs.).
  22. Install the caliper slide bolt dust shields.
  23. Install the brake caliper tension clip (1).
  24. Install the tire and wheel assembly. Refer to «WHEELS , STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/wheel-tire-system/#tires-wheels-service-information) .
  25. Install the rear drive shaft. Refer to «SHAFT, DRIVE, REAR , INSTALLATION»(/jeep/grand-cherokee/wk2-2010-2013/remont/driveshaft-universal-joints/#propeller-shaft) .
  26. Pump brake pedal several times to ensure vehicle has a firm brake pedal before moving vehicle.
  27. Perform wheel alignment, paying special attention to thrust angle. If rear crossmember needs to be shifted to align thrust angle. Refer to «WHEEL ALIGNMENT , STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/suspension-front/#front-suspension-wheel-alignment) .

Scheme 35

Scheme 35: REMOVAL
Scheme 35: REMOVAL
  1. Remove the skid plate. Refer to «PLATE, SKID, TRANSMISSION , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/frames-subframes-crossmembers/#frame-and-bumpers) and «PLATE, SKID, TRANSFER CASE , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/frames-subframes-crossmembers/#frame-and-bumpers) .
  2. Remove the reinforcement brackets.
  3. Support the transmission with a suitable lifting device.
  4. Remove the transmission mount bolts (3).
  5. Remove the six crossmember bolts (2) and remove the crossmember (1).
  1. Install the crossmember (1) and install the six crossmember bolts (2).
  2. Tighten the six crossmember bolts (2) to 61 N.m (45 ft. lbs.).
  3. Remove the lifting device.
  4. Install the transmission mount bolts (3) and tighten to 61 N.m (45 ft. lbs.).
  5. Install the crossmember reinforcement brackets and tighten the bolts to 55 N.m (41 ft. lbs.).
  6. Install the skid plate. Refer to «PLATE, SKID, TRANSMISSION , INSTALLATION»(/jeep/grand-cherokee/wk2-2010-2013/remont/frames-subframes-crossmembers/#frame-and-bumpers) and «PLATE, SKID, TRANSFER CASE , INSTALLATION»(/jeep/grand-cherokee/wk2-2010-2013/remont/frames-subframes-crossmembers/#frame-and-bumpers) .

Scheme 36

Scheme 36: REMOVAL
Scheme 36: REMOVAL

Scheme 37

Scheme 37
Scheme 37

Scheme 38

Scheme 38
Scheme 38
  1. Remove the rear fascia. Refer to «FASCIA, REAR , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/frames-subframes-crossmembers/#frame-and-bumpers) .
  2. Disconnect the trailer wiring connector (2) harness. NOTE: 7-way connector shown in illustration, 4 way similar.
  3. Remove the six horizontal bolts (1) and two vertical bolts (2).
  4. Remove the trailer hitch (1).
  1. Install the hitch (1).
  2. Install the bolts (1 and 2)
  3. Tighten the six horizontal bolts (1) to 165 N.m (122 ft. lbs.).
  4. Tighten the two vertical bolts (2) to 165 N.m (122 ft. lbs.).
  5. Connect the trailer connector wire harness (2). NOTE: 7-way connector shown in illustration, 4 way similar.
  6. Install the rear fascia. Refer to «FASCIA, REAR , INSTALLATION»(/jeep/grand-cherokee/wk2-2010-2013/remont/frames-subframes-crossmembers/#frame-and-bumpers) .

Scheme 39

Scheme 39: REMOVAL
Scheme 39: REMOVAL
  1. Remove the nut (5) and remove the tow hook (2).
  2. Remove the two front bolts (3) and remove the tow hook (2).
  3. If necessary, remove the two bolts (4) and remove the support bracket (1).
  1. If removed previously, install the tow hook support bracket (1) and install the two bolts (4).
  2. Tighten the bolts (4) to 47 N.m (35 ft. lbs.).
  3. Install the tow hook (2) and install the bolts (3).
  4. Tighten the bolts (3) to 47 N.m (35 ft. lbs.).
  5. Install the nut (5) and tighten to 25 N.m (18.5 ft. lbs.).

Scheme 40

Scheme 40: REMOVAL
Scheme 40: REMOVAL
  1. Loosen the rear tow hook bolt (1).
  2. Remove the reinforcement bracket bolt (2).
  3. Remove the side bracket bolts (3).
  4. Remove the lower frame bolt (4) and remove the tow hook assembly (5).
  1. Install the rear notch (5) of the tow hook onto the rear frame bolt (1).
  2. Install the front lower frame bolt (4).
  3. Install the side frame bolts (3) and tighten to 165 N.m (122 ft. lbs.).
  4. Tighten the front vertical bolt (4) to 165 N.m (122 ft. lbs.).
  5. Tighten the rear vertical bolt (1) to 165 N.m (122 ft. lbs.).
  6. Install the support bracket bolt (2) to 100 N.m (74 ft. lbs.).

Scheme 41

Scheme 41: REMOVAL
Scheme 41: REMOVAL

Scheme 42

Scheme 42
Scheme 42

Scheme 43

Scheme 43
Scheme 43
  1. Remove the engine cradle crossmember (2). Refer to «CROSSMEMBER, CRADLE, ENGINE AND SUSPENSION , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/frames-subframes-crossmembers/#frame-and-bumpers) .
  2. Remove the spacer (1).
  3. As an installation reference, carefully mark location of isolator (3) requiring removal on crossmember (1) (around isolator can flange) using a marker or crayon. Do not use a scratch awl to mark location. 1 - OTC puller 1182 or equivalent 2 - Remover/Installer, Bushing 6602-2 3 - Front Engine Cradle Crossmember 4 - Isolator NOTE: Prior to using special tools, lubricate OTC puller 1182 or equivalent (1) threads to provide ease of use and promote tool longevity.
  4. Assemble tools over isolator as shown in illustration.
  5. Using OTC puller 1182 or equivalent and Remover/Installer, Bushing (special tool #6602-2, Remover/Installer, Bushing) remover, remove the isolator (4).
CAUTIONIt is very important that isolator be installed in same position as original to maintain vehicle ride quality and isolator longevity. That is why isolator, once installed, needs to closely match reference marks applied upon removal of original isolator.

Scheme 44

Scheme 44
Scheme 44

Scheme 45

Scheme 45
Scheme 45
  1. Position isolator (3) on crossmember (1) isolator bore aligning isolator can flange with reference marks applied during removal. 1 - Press, Ball Joint C-4212F 2 - Remover/Installer, Bushing 9031-5A 3 - Remover/Installer, Bushing 9031-7A 4 - Front Engine Cradle Crossmember 5 - Isolator NOTE: Prior to using special tools, lubricate Press, Ball Joint (special tool #C-4212F, Press, Ball Joint) (1) threads to provide ease of use and promote tool longevity. NOTE: A mixture of soap and water may be used to aid installation of the isolator.
  2. Assemble tools over isolator as shown in illustration.
  3. Tighten Press, Ball Joint (special tool #C-4212F, Press, Ball Joint) (1) screw-drive, pressing isolator (5) into crossmember (4). Install isolator until isolator can flange contacts surface of crossmember.
  4. Remove tools.
  5. Install the spacer (1).
  6. Install the engine cradle crossmember (2). Refer to «CROSSMEMBER, CRADLE, ENGINE AND SUSPENSION , INSTALLATION»(/jeep/grand-cherokee/wk2-2010-2013/remont/frames-subframes-crossmembers/#frame-and-bumpers) .

Scheme 46

Scheme 46: REMOVAL
Scheme 46: REMOVAL

Scheme 47

Scheme 47
Scheme 47

Scheme 48

Scheme 48
Scheme 48

Scheme 49

Scheme 49
Scheme 49

Scheme 50

Scheme 50
Scheme 50
  1. Remove the exhaust as necessary to obtain clearance while lowering the rear differential. Refer to «TAILPIPE, EXHAUST , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/exhaust/#exhaust-system) .
  2. Remove the rear differential as necessary to gain enough access to the differential support isolators. Refer to «REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/differentials-drive-axles/#rear-axle-195ria__removal) .
  3. Position transmission jack (1) to rear axle assembly.
  4. Remove rear axle forward mount isolator bolt/nut (1).
  5. Remove the bolts (1) and lower the stabilizer bar (2).
  6. Remove two rear axle-to-crossmember bolts (1).
  7. Lower axle just enough to gain access to the differential isolator being serviced. 1 - Remover/Installer, Bushing 9520-2 2 - Remover/Installer, Bushing 9520-4 3 - Screw Assembly 8838-2 4 - Rear Suspension Crossmember 5 - Remover/Installer 8173-3 NOTE: Prior to using special tools, lubricate Screw Assembly (special tool #8838-2, Screw Assembly) (3) threads to provide ease of use and promote tool longevity. NOTE: When installing thrust bearing, be sure to place hardened side toward bolt head.
  8. Assemble tools over isolator as shown in illustration.
  9. While holding Nut from rotating, using hand tools , tighten Screw Assembly (special tool #8838-2, Screw Assembly) (3) until Remover/Installer (special tool #8173-3, Remover/Installer) (5) comes in contact with isolator and Remover/Installer, Bushing (special tool #9520-4, Cup, Receiver) (2) sets squarely against crossmember (4).
  10. Continue to tighten Screw Assembly (special tool #8838-2, Screw Assembly) (3), pressing isolator out of crossmember (4).
  11. Remove tools with isolator.

Scheme 51

Scheme 51: INSTALLATION
Scheme 51: INSTALLATION
1 - Screw Assembly 8838
2 - Isolator
3 - Remover/Installer, Bushing 9520-2
4 - Remover/Installer 8173-3
5 - Rear Suspension Crossmember
6 - Remover/Installer, Bushing 9031-7A

Note. Prior to using special tools, lubricate Screw Assembly (special tool #8838-2, Screw Assembly) (1) threads to provide ease of use and promote tool longevity.

Note. When installing thrust bearing, be sure to place hardened side toward bolt head.

Note. A mixture of soap and water may be used to aid installation of the isolator.

  1. Assemble tools over isolator as shown in illustration.
  2. While holding Nut (4) from rotating, tighten Screw Assembly (special tool #8838-2, Screw Assembly) (1) using hand tools , pressing isolator (2) into crossmember (4). Stop when the isolator (2) bottoms against Remover/Installer, Bushing (special tool #9031-7A, Installer, Bushing).
  3. Remove tools.
  4. Carefully raise rear axle.
  5. Install two rear axle-to-crossmember bolts (1) and torque to 135 N.m (100 ft. lbs.).
  6. Install rear axle forward mount isolator bolt/nut (1) and torque to 135 N.m (100 ft. lbs.).
  7. Position the stabilizer bar (2) and install the upper and lower stabilizer bar to cradle bolts (1) and tighten to 110 N.m (81 ft. lbs.).
  8. Install the exhaust if necessary. Refer to «TAILPIPE, EXHAUST , INSTALLATION»(/jeep/grand-cherokee/wk2-2010-2013/remont/exhaust/#exhaust-system) .

Scheme 52

Scheme 52: REMOVAL
Scheme 52: REMOVAL

Scheme 53

Scheme 53
Scheme 53
  1. Remove the rear suspension crossmember. Refer to «CROSSMEMBER, REAR , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/frames-subframes-crossmembers/#frame-and-bumpers) «CROSSMEMBER, TRANSMISSION , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/frames-subframes-crossmembers/#frame-and-bumpers) .
  2. As an installation reference, carefully mark location of isolator (1) requiring removal on crossmember (2) (around isolator can flange) using a marker or crayon. Do not use a scratch awl to mark location. 1 - Remover/Installer, Bushing 6602 2 - Support Bolts 3 - Rear Suspension Crossmember 4 - Remover/Installer, Bushing 9520-1 5 - Isolator 6 - Puller, Extension Housing 8244 NOTE: Prior to using special tools, lubricate Remover/Installer, Bushing (special tool #6602, Remover/Installer, Bushing) Screw Assembly (1) threads to provide ease of use and promote tool longevity. NOTE: When installing thrust bearing, be sure to place hardened side toward bolt head.
  3. Assemble tools over isolator as shown in illustration.
  4. Install two bolts (2) as shown in illustration to stabilize Puller, Extension Housing (special tool #8244, Puller, Extension Housing) (6) legs during the removal procedure.
  5. While holding screw assembly from rotating, using hand tools , tighten Remover/Installer, Bushing (special tool #6602, Remover/Installer, Bushing) nut (1) until Remover/Installer, Bushing (special tool #9520-1, Installer Disc) (4) comes in contact with isolator (5) and Puller, Extension Housing (special tool #8244, Puller, Extension Housing) (6) sets squarely against crossmember (3).
  6. Continue to tighten Remover/Installer, Bushing (special tool #6602, Remover/Installer, Bushing) nut (1), pressing isolator (5) out of crossmember (3).
  7. Remove tools with isolator.
CAUTIONIt is very important that isolator be installed in same position as original to maintain vehicle ride quality and isolator longevity. That is why isolator, once installed, needs to closely match reference marks applied upon removal of original isolator.

Scheme 54

Scheme 54
Scheme 54
  1. Position isolator (1) on crossmember (2) isolator bore aligning isolator can flange with reference marks applied during removal. 1 - Press, Ball Joint C-4212F 2 - Remover/Installer, Bushing 9031-5A 3 - Remover/Installer, Bushing 9031-1 4 - Rear Suspension Crossmember 5 - Bushing NOTE: Prior to using special tools, lubricate Press, Ball Joint (special tool #C-4212F, Press, Ball Joint) (1) threads to provide ease of use and promote tool longevity. NOTE: A mixture of soap and water may be used to aid installation of the isolator.
  2. Assemble tools over isolator as shown in illustration.
  3. Tighten Press, Ball Joint (special tool #C-4212F, Press, Ball Joint) (1) screw-drive, pressing isolator (5) into crossmember (4). Install isolator until isolator can flange contacts surface of crossmember.
  4. Remove tools.
  5. Install the rear suspension crossmember (4). Refer to «CROSSMEMBER, REAR , INSTALLATION»(/jeep/grand-cherokee/wk2-2010-2013/remont/frames-subframes-crossmembers/#frame-and-bumpers) «CROSSMEMBER, TRANSMISSION , INSTALLATION»(/jeep/grand-cherokee/wk2-2010-2013/remont/frames-subframes-crossmembers/#frame-and-bumpers) .

Scheme 55

Scheme 55: REMOVAL
Scheme 55: REMOVAL
  1. Raise and support the vehicle.
  2. Remove the six fasteners (2) and remove the skid plate (1).
  1. Raise and support the vehicle.
  2. Install the skid plate (1) and install the six fasteners (2).
  3. Tighten the fasteners to 28 N.m (21 ft. lbs.).

Scheme 56

Scheme 56: REMOVAL
Scheme 56: REMOVAL
  1. Raise and support the vehicle.
  2. Remove the four fasteners (2) and remove the skid plate (1).
  1. Raise and support the vehicle.
  2. Install the skid plate (1) and install the four bolts (2).
  3. Tighten the bolts to 28 N.m (21 ft. lbs.).

REMOVAL

Note. Right side shown in illustration, left side similar.

Scheme 57

Scheme 57: REMOVAL
Scheme 57: REMOVAL
  1. Raise and support the vehicle.
  2. Remove the three fasteners (3) and remove the skid plate (2).

Note. Right side shown in illustration, left side similar.

  1. Raise and support the vehicle.
  2. Install the skid plate (2) and install the three fasteners (3).
  3. Tighten the bolts to 28 N.m (21 ft. lbs.).

Scheme 58

Scheme 58: REMOVAL
Scheme 58: REMOVAL
  1. Raise and support the vehicle.
  2. Remove the five fasteners (2) and remove the skid plate (1).
  1. Raise and support the vehicle.
  2. Install the skid plate (1) and install the five fasteners (2).
  3. Tighten the fasteners to 28 N.m (21 ft. lbs.).

Scheme 59

Scheme 59: REMOVAL
Scheme 59: REMOVAL
  1. Remove the two nuts (2) and four bolts (3) and remove the skid plate.
  1. Install the skid plate and install the four fasteners (3) and nuts (2).
  2. Tighten the bolts to 28 N.m (21 ft. lbs.).
