B1425-2A-REMOTE RADIO SWITCH INPUT-STUCK

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

THEORY OF OPERATION

The Remote Radio Switches are hardwired to the Right Steering Wheel Control Switch (Speed Control Switch). The Right Steering Wheel Control Switch (Speed Control Switch) communicates to the Steering Column Control Module (SCCM) via the LIN Bus. The SCCM is located near the top of the steering column below the steering wheel. The SCCM includes the steering column shroud, the Steering Angle Sensor (SAS), the Clockspring, the Multi-function Switch, a Steering Column Power Tilt and Telescope Switch (if equipped), and a trim cover. The SCCM is replaced as an entire assembly.

WHEN MONITORED

Continuously with the ignition on.

SET CONDITION

The Steering Column Control Module senses that the Remote Radio Switches are in the Set position for greater than 600 seconds.

POSSIBLE CAUSES

DIAGNOSTIC TEST

1. CHECK FOR AN ACTIVE DTC Turn the ignition on. Press each Remote Radio Switch twice. With the scan tool, read DTCs Does the scan tool display this DTC as active? Yes WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. WARNING: Do not place an intact non-deployed airbag face down on a hard surface, the airbag propels into the air if accidentally deployed. Failure to follow these instructions may result in possible serious or fatal injury. NOTE: Check for a stuck Remote Radio Switch. Repair as necessary. NOTE: Visually and physically inspect the wiring harness between the Remote Radio Switch harness connectors and the Right Steering Wheel Switch (Speed Control Switch) harness connector. Repair any damaged wires, connectors, and open/spread terminals. If harness is OK, proceed with test. Replace the Right Steering Wheel Control Switch (Speed Control Switch) in accordance with the Service Information. Refer to «SWITCH, SPEED CONTROL , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/cruise-control-systems/#speed-control-service-information__removal) . Once switch has been replaced, press it twice to initialize it. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .

B1504-2A-LEFT STEERING WHEEL CONTROL SWITCH-STUCK

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

The Left Steering Wheel Control Switch is hardwired to the Right Steering Wheel Control Switch (Speed Control Switch). The Right Steering Wheel Control Switch (Speed Control Switch) communicates to the Steering Column Control Module (SCCM) via the LIN Bus. The SCCM is located near the top of the steering column below the steering wheel. The SCCM includes the steering column shroud, the Steering Angle Sensor (SAS), the Clockspring, the Multi-function Switch, a Steering Column Power Tilt and Telescope Switch (if equipped), and a trim cover. The SCCM is replaced as an entire assembly.

Continuously with the ignition on.

The Steering Column Control Module (SCCM) senses that the Left Steering Wheel Control Switch is in the Set position for greater than 20 seconds. Phone related switches have a set time of 600 seconds.

1. CHECK FOR AN ACTIVE DTC Turn the ignition on. Press each switch on the Left Steering Wheel Switch assembly twice. With the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. WARNING: Do not place an intact non-deployed airbag face down on a hard surface, the airbag propels into the air if accidentally deployed. Failure to follow these instructions may result in possible serious or fatal injury. NOTE: Check for a stuck Left Steering Wheel Control Switch. NOTE: Visually and physically inspect the wiring harness between the Left Steering Wheel Control Switch harness connector and the Right Steering Wheel Control Switch (Speed Control Switch) harness connector. Repair any damaged wires, connectors, and open/spread terminals. If harness is OK, proceed with test. Replace the Left Steering Wheel Control Switch in accordance with the Service Information. Refer to «SWITCH, EVIC CONTROL , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#message-center-service-information) . Once switch has been replaced, press it twice to initialize it. If problem persists, replace the Right Steering Wheel Switch (Speed Control Switch) in accordance with the Service Information. Refer to «SWITCH, SPEED CONTROL , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/cruise-control-systems/#speed-control-service-information__removal) . Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .

B1D9C-00-STEERING COLUMN TILT SWITCH

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

The Steering Column Power Tilt and Telescope Switch for this vehicle is integral to the Steering Column Control Module (SCCM). The SCCM is located near the top of the steering column below the steering wheel. The SCCM includes the steering column shroud, the Steering Angle Sensor (SAS), the Clockspring, the Multi-function Switch, a Steering Column Power Tilt and Telescope Switch (if equipped), and a trim cover. The SCCM is replaced as an entire assembly.

With the ignition on.

The Steering Column Power Tilt and Telescope Switch has set an internal failure status.

1. CHECK FOR AN ACTIVE DTC Turn the ignition on. Press the Steering Column Tilt Switch twice in all directions. With the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes Replace the Steering Column Control Module (SCCM) in accordance with the Service Information. Refer to «MODULE, STEERING COLUMN , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#electronic-control-modules-service-information) . Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .

B1D9C-2A-STEERING COLUMN TILT SWITCH- STUCK

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

The Steering Column Power Tilt and Telescope Switch for this vehicle is integral to the Steering Column Control Module (SCCM). The SCCM is located near the top of the steering column below the steering wheel. The SCCM includes the steering column shroud, the Steering Angle Sensor (SAS), the Clockspring, the Multi-function Switch, a Steering Column Power Tilt and Telescope Switch (if equipped), and a trim cover. The SCCM is replaced as an entire assembly.

With the ignition on.

The Steering Column Power Tilt and Telescope Switch has been pressed for greater than 50 seconds.

1. CHECK FOR AN ACTIVE DTC Turn the ignition on. Press the Steering Column Tilt Switch twice in all directions. With the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes Replace the Steering Column Control Module (SCCM) in accordance with the Service Information. Refer to «MODULE, STEERING COLUMN , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#electronic-control-modules-service-information) . Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .

Scheme 11

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

The Steering Control Module (SCM) for this vehicle is integral to the Steering Column Control Module (SCCM). The SCCM is located near the top of the steering column below the steering wheel. The SCCM includes the steering column shroud, the Steering Angle Sensor (SAS), the Clockspring, the Multi-function Switch, a Steering Column Power Tilt and Telescope Switch (if equipped), and a trim cover. The SCCM is replaced as an entire assembly.

With the ignition on.

The Steering Column Control Module (SCCM) has set an internal electronic failure status.

Scheme 12

1. CHECK FOR AN ACTIVE DTC Turn the ignition on. With the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes Go To 2 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .
2. LOW BATTERY VOLTAGE Turn the ignition off. Disconnect the Steering Control Module C1 harness connector. Turn the ignition on. Measure the voltage of the (A909) Fused B(+) circuit. Is battery voltage present? Yes Replace the Steering Column Control Module (SCCM) in accordance with the Service Information. Refer to «MODULE, STEERING COLUMN , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#electronic-control-modules-service-information) . Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) . No Repair the (A909) Fused B(+) circuit for an open, short to ground or high resistance. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .

B2306-2A-FRONT WASHER SWITCH-STUCK

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

The Washer Switch for this vehicle is integral to the Steering Column Control Module (SCCM). The SCCM is located near the top of the steering column below the steering wheel. The SCCM includes the steering column shroud, the Steering Angle Sensor (SAS), the Clockspring, the Multi-function Switch, a Steering Column Power Tilt and Telescope Switch (if equipped), and a trim cover. The SCCM is replaced as an entire assembly.

With the ignition on.

The SCCM detects the Washer Switch is active for greater than 20 seconds.

1. CHECK FOR AN ACTIVE DTC Turn the ignition on. Press the Front Washer Switch twice. With the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes Replace the Steering Column Control Module (SCCM) in accordance with the Service Information. Refer to «MODULE, STEERING COLUMN , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#electronic-control-modules-service-information) . Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .

B232E-00-REAR WASHER SWITCH STUCK

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

The Rear Washer Switch for this vehicle is integral to the Steering Column Control Module (SCCM). The SCCM is located near the top of the steering column below the steering wheel. The SCCM includes the steering column shroud, the Steering Angle Sensor (SAS), the Clockspring, the Multi-function Switch, a Steering Column Power Tilt and Telescope Switch (if equipped), and a trim cover. The SCCM is replaced as an entire assembly.

With the ignition on.

The SCCM detects the Rear Washer Switch is active for greater than 20 seconds.

1. CHECK FOR AN ACTIVE DTC Turn the ignition on. Press the Rear Washer Switch twice. With the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes Replace the Steering Column Control Module (SCCM) in accordance with the Service Information. Refer to «MODULE, STEERING COLUMN , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#electronic-control-modules-service-information) . Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .

B2332-2A-HORN SWITCH-STUCK

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

The Horn Switch is connected to the Right Steering Switch. The switching status is transferred to the Steering Column Control Module (SCCM) by way of the LIN bus, a serial sub-bus. The SCCM converts the data to a CAN Bus signal and sends the message to the corresponding module on the bus.

Continuously with the ignition on.

The Steering Column Control Module (SCCM) senses that the Horn Switch is pressed for greater than 45 seconds.

1. CHECK FOR AN ACTIVE DTC Turn the ignition on. With the scan tool, read DTCs Does the scan tool display this DTC as active? Yes WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. WARNING: Do not place an intact non-deployed airbag face down on a hard surface, the airbag propels into the air if accidentally deployed. Failure to follow these instructions may result in possible serious or fatal injury. NOTE: Visually and physically inspect the wiring harness between the Horn Switch harness connector and the Right Steering Wheel Switch (Speed Control Switch) harness connector. Repair any damaged wires, connectors, and open/spread terminals. If harness is OK, proceed with test. Replace the Horn Switch in accordance with the Service Information. Refer to «SWITCH, HORN , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/horns/#horn-system-service-information) . Once the switch has been replaced, press it twice to initialize it. If problem still persists, replace the Right Steering Wheel Switch (Speed Control Switch) in accordance with the Service Information. Refer to «SWITCH, SPEED CONTROL , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/cruise-control-systems/#speed-control-service-information__removal) . Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .

B23A1-2A-FLASH TO PASS/OPTICAL HORN SWITCH-STUCK

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

The Flash to Pass/Optical Horn Switch for this vehicle is integral to the Steering Column Control Module (SCCM). The SCCM is located near the top of the steering column below the steering wheel. The SCCM includes the steering column shroud, the Steering Angle Sensor (SAS), the Clockspring, the Multi-function Switch, a Steering Column Power Tilt and Telescope Switch (if equipped), and a trim cover. The SCCM is replaced as an entire assembly.

With the ignition on.

The SCCM detects the Flash to Pass/Optical Horn Switch is active for greater than 20 seconds.

1. CHECK FOR AN ACTIVE DTC Turn the ignition on. Actuate the Flash To Pass/Optical Horn Switch twice. With the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes Replace the Steering Column Control Module (SCCM) in accordance with the Service Information. Refer to «MODULE, STEERING COLUMN , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#electronic-control-modules-service-information) . Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .

C1240-76-STEERING ANGLE SENSOR ANGLE OVERTRAVEL PERFORMANCE- WRONG MOUNTING POSITION

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

The Steering Angle Sensor (SAS) for this vehicle is integral to the Steering Column Control Module (SCCM). The SCCM is located near the top of the steering column below the steering wheel. The SCCM includes the steering column shroud, the Steering Angle Sensor (SAS), the Clockspring, the Multi-function Switch, a Steering Column Power Tilt and Telescope Switch (if equipped), and a trim cover. The SCCM is replaced as an entire assembly.

With the ignition on.

The Steering Angle Sensor (SAS) sets this DTC if the SAS is overwound steering system service or incorrect installation.

1. CHECK FOR AN ACTIVE DTC NOTE: If steering system service has been performed and the Steering Angle Sensor (SAS) has been installed incorrectly, this DTC may set. Refer to the appropriate Service Information to verify repairs have been performed correctly. Turn the ignition on. With the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes Replace the Steering Column Control Module (SCCM) in accordance with the Service Information. Refer to «MODULE, STEERING COLUMN , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#electronic-control-modules-service-information) . Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .

C2129-16-BATTERY VOLTAGE-CIRCUIT VOLTAGE BELOW THRESHOLD

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

The Steering Control Module (SCM) for this vehicle is integral to the Steering Column Control Module (SCCM). The SCCM is located near the top of the steering column below the steering wheel. The SCCM includes the steering column shroud, the Steering Angle Sensor (SAS), the Clockspring, the Multi-function Switch, a Steering Column Power Tilt and Telescope Switch (if equipped), and a trim cover. The SCCM is replaced as an entire assembly.

Continuously with the ignition on.

If the voltage to the Steering Column Control Module (SCCM) is below 10 volts for more than 15 seconds.

Scheme 13

1. RELATED DTC(S) PRESENT IN PCM Turn the ignition on. With the scan tool, select View DTCs in the Powertrain Control Module (PCM). Are there any charging system or related battery voltage DTCs present in the PCM? Yes Perform the appropriate diagnostic procedure. Refer to «DIAGNOSTIC CODE INDEX - 3.0L DIESEL»(/jeep/grand-cherokee/wk2-2010-2013/remont/testing-diagnostics/#30l-diesel-diagnostic-code-index) or «DIAGNOSTIC CODE INDEX - NGC»(/jeep/grand-cherokee/wk2-2010-2013/remont/testing-diagnostics/#36l-57l-diagnostic-code-index) . No Go To 2 .
2. CHECK FOR AN ACTIVE DTC With the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes Go To 3 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .
3. (A909) FUSED B(+) CIRCUIT OPEN OR SHORTED TO GROUND Turn the ignition off. Disconnect the Steering Control Module C1 harness connector. Turn the ignition on. Measure the voltage of the (A909) Fused B(+) circuit. Is battery voltage present? Yes Go To 4 . No Repair the (A909) Fused B(+) circuit for an open, short to ground or high resistance. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .
4. (Z912) GROUND CIRCUIT OPEN OR HIGH RESISTANCE Turn the ignition off. Measure the resistance between ground and the (Z912) Ground circuit. Is the resistance below 5.0 Ohms? Yes Replace the Steering Column Control Module (SCCM) in accordance with the Service Information. Refer to «MODULE, STEERING COLUMN , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#electronic-control-modules-service-information) . Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) . No Repair the (Z912) Ground circuit for an open or high resistance. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .

C2129-17-BATTERY VOLTAGE-CIRCUIT VOLTAGE ABOVE THRESHOLD

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

Continuously.

If the voltage to the Steering Column Control Module (SCCM) is above 16 volts for more than 15 seconds.

1. RELATED DTC(S) PRESENT IN THE PCM Ignition on, engine not running. With the scan tool, select View DTCs in the Powertrain Control Module (PCM). Are there any charging system or related battery voltage DTCs present in the PCM? Yes Perform the appropriate diagnostic procedure. Refer to «DIAGNOSTIC CODE INDEX - 3.0L DIESEL»(/jeep/grand-cherokee/wk2-2010-2013/remont/testing-diagnostics/#30l-diesel-diagnostic-code-index) or «DIAGNOSTIC CODE INDEX - NGC»(/jeep/grand-cherokee/wk2-2010-2013/remont/testing-diagnostics/#36l-57l-diagnostic-code-index) . Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) . No Go To 2 .
2. CHECK FOR AN ACTIVE DTC Ignition on, engine not running. With the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes Replace the Steering Column Control Module (SCCM) in accordance with the Service information. Refer to «MODULE, STEERING COLUMN , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#electronic-control-modules-service-information) . Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .

C212A-16-SYSTEM VOLTAGE-CIRCUIT VOLTAGE BELOW THRESHOLD

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

The Steering Control Module (SCM) for this vehicle is integral to the Steering Column Control Module (SCCM). The SCCM is located near the top of the steering column below the steering wheel. The SCCM includes the steering column shroud, the Steering Angle Sensor (SAS), the Clockspring, the Multi-function Switch, a Steering Column Power Tilt and Telescope Switch (if equipped), and a trim cover. The SCCM is replaced as an entire assembly.

Continuously with the ignition on.

If the voltage in the Steering Column Control Module (SCCM) internal power supply is below 10 volts for more than 15 seconds.

1. RELATED DTC(S) PRESENT IN PCM Turn the ignition on. With the scan tool, select View DTCs in the Powertrain Control Module (PCM). Are there any charging system or related battery voltage DTCs present in the PCM? Yes Perform the appropriate diagnostic procedure. Refer to «DIAGNOSTIC CODE INDEX - 3.0L DIESEL»(/jeep/grand-cherokee/wk2-2010-2013/remont/testing-diagnostics/#30l-diesel-diagnostic-code-index) or «DIAGNOSTIC CODE INDEX - NGC»(/jeep/grand-cherokee/wk2-2010-2013/remont/testing-diagnostics/#36l-57l-diagnostic-code-index) . No Go To 2 .
2. CHECK FOR AN ACTIVE DTC With the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes Go To 3 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .
3. (A909) FUSED B(+) CIRCUIT OPEN OR SHORTED TO GROUND Turn the ignition off. Disconnect the Steering Control Module C1 harness connector. Turn the ignition on. Measure the voltage of the (A909) Fused B(+) circuit. Is battery voltage present? Yes Go To 4 . No Repair the (A909) Fused B(+) circuit for an open or short to ground. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .
4. (Z912) GROUND CIRCUIT OPEN OR HIGH RESISTANCE Turn the ignition off. Measure the resistance between ground and the (Z912) Ground circuit. Is the resistance below 5.0 Ohms? Yes Replace the Steering Column Control Module (SCCM) in accordance with the Service Information. Refer to «MODULE, STEERING COLUMN , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#electronic-control-modules-service-information) . Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) . No Repair the (Z912) Ground circuit for an open or high resistance. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .

C212A-17-SYSTEM VOLTAGE-CIRCUIT VOLTAGE ABOVE THRESHOLD

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

Continuously.

If the voltage in the Steering Column Control Module (SCCM) internal power supply is above 16 volts for more than 15 seconds.

1. RELATED DTC(S) PRESENT IN THE PCM Ignition on, engine not running. With the scan tool, select View DTCs in the Powertrain Control Module (PCM). Are there any charging system or related battery voltage DTCs present in the PCM? Yes Perform the appropriate diagnostic procedure. Refer to «DIAGNOSTIC CODE INDEX - 3.0L DIESEL»(/jeep/grand-cherokee/wk2-2010-2013/remont/testing-diagnostics/#30l-diesel-diagnostic-code-index) or «DIAGNOSTIC CODE INDEX - NGC»(/jeep/grand-cherokee/wk2-2010-2013/remont/testing-diagnostics/#36l-57l-diagnostic-code-index) . Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) . No Go To 2 .
2. CHECK FOR AN ACTIVE DTC Ignition on, engine not running. With the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes Replace the Steering Column Control Module (SCCM) in accordance with the Service information. Refer to «MODULE, STEERING COLUMN , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#electronic-control-modules-service-information) . Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .

C2205-00-STEERING ANGLE SENSOR INTERNAL

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

The Steering Angle Sensor (SAS) for this vehicle is integral to the Steering Column Control Module (SCCM). The SCCM is located near the top of the steering column below the steering wheel. The SCCM includes the steering column shroud, the Steering Angle Sensor (SAS), the Clockspring, the Multi-function Switch, a Steering Column Power Tilt and Telescope Switch (if equipped), and a trim cover. The SCCM is replaced as an entire assembly.

With the ignition on.

The Steering Angle Sensor (SAS) has set an internal failure status.

1. CHECK FOR AN ACTIVE DTC Turn the ignition on. With the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes Replace the Steering Column Control Module (SCCM) in accordance with the Service Information. Refer to «MODULE, STEERING COLUMN , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#electronic-control-modules-service-information) . Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .

C2205-29-STEERING ANGLE SENSOR INTERNAL-SIGNAL INVALID

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

The Steering Angle Sensor (SAS) for this vehicle is integral to the Steering Column Control Module (SCCM). The SCCM is located near the top of the steering column below the steering wheel. The SCCM includes the steering column shroud, the Steering Angle Sensor (SAS), the Clockspring, the Multi-function Switch, a Steering Column Power Tilt and Telescope Switch (if equipped), and a trim cover. The SCCM is replaced as an entire assembly.

With the ignition on.

The Steering Angle Sensor (SAS) has set an internal failure status.

1. CHECK FOR AN ACTIVE DTC Turn the ignition on. With the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes Replace the Steering Column Control Module (SCCM) in accordance with the Service Information. Refer to «MODULE, STEERING COLUMN , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#electronic-control-modules-service-information) . Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .

C2205-2F-STEERING ANGLE SENSOR INTERNAL-SIGNAL ERRATIC

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

The Steering Angle Sensor (SAS) for this vehicle is integral to the Steering Column Control Module (SCCM). The SCCM is located near the top of the steering column below the steering wheel. The SCCM includes the steering column shroud, the Steering Angle Sensor (SAS), the Clockspring, the Multi-function Switch, a Steering Column Power Tilt and Telescope Switch (if equipped), and a trim cover. The SCCM is replaced as an entire assembly.

With the ignition on.

The Steering Angle Sensor (SAS) has set an internal failure status.

1. CHECK FOR AN ACTIVE DTC Turn the ignition on. With the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes Replace the Steering Column Control Module (SCCM) in accordance with the Service Information. Refer to «MODULE, STEERING COLUMN , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#electronic-control-modules-service-information) . Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .

C2205-41-STEERING ANGLE SENSOR INTERNAL-GENERAL CHECKSUM FAILURE

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

The Steering Angle Sensor (SAS) for this vehicle is integral to the Steering Column Control Module (SCCM). The SCCM is located near the top of the steering column below the steering wheel. The SCCM includes the steering column shroud, the Steering Angle Sensor (SAS), the Clockspring, the Multi-function Switch, a Steering Column Power Tilt and Telescope Switch (if equipped), and a trim cover. The SCCM is replaced as an entire assembly.

With the ignition on.

The Steering Angle Sensor (SAS) has set an internal failure status.

1. CHECK FOR AN ACTIVE DTC Turn the ignition on. With the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes Replace the Steering Column Control Module (SCCM) in accordance with the Service Information. Refer to «MODULE, STEERING COLUMN , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#electronic-control-modules-service-information) . Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .

C2205-96-STEERING ANGLE SENSOR INTERNAL-COMPONENT INTERNAL FAILURE

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

The Steering Angle Sensor (SAS) for this vehicle is integral to the Steering Column Control Module (SCCM). The SCCM is located near the top of the steering column below the steering wheel. The SCCM includes the steering column shroud, the Steering Angle Sensor (SAS), the Clockspring, the Multi-function Switch, a Steering Column Power Tilt and Telescope Switch (if equipped), and a trim cover. The SCCM is replaced as an entire assembly.

With the ignition on.

The Steering Angle Sensor (SAS) has set an internal failure status.

1. CHECK FOR AN ACTIVE DTC Turn the ignition on. With the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes Replace the Steering Column Control Module (SCCM) in accordance with the Service Information. Refer to «MODULE, STEERING COLUMN , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#electronic-control-modules-service-information) . Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .

P0579-00-SPEED CONTROL SWITCH 1 PERFORMANCE

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

The Speed Control Switch is hardwired to the Steering Column Control Module (SCCM). The SCCM is located near the top of the steering column below the steering wheel. The SCCM includes the steering column shroud, the Steering Angle Sensor (SAS), the Clockspring, the Multi-function Switch, a Steering Column Power Tilt and Telescope Switch (if equipped), and a trim cover. The SCCM is replaced as an entire assembly.

Continuously with the ignition on.

The Steering Column Control Module (SCCM) has detected that a non-permissable combination has occurred in the Right Steering Wheel Switch (Speed Control Switch).

1. CHECK FOR AN ACTIVE DTC Turn the ignition on. With the scan tool, read DTCs Does the scan tool display this DTC as active? Yes WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. WARNING: Do not place an intact non-deployed airbag face down on a hard surface, the airbag propels into the air if accidentally deployed. Failure to follow these instructions may result in possible serious or fatal injury. NOTE: Visually and physically inspect the wiring harness between the Right Steering Wheel Switch (Speed Control Switch) harness connector and the SCCM harness connector. Repair any damaged wires, connectors, and open/spread terminals. If harness is OK, proceed with test. Replace the Right Steering Wheel Switch (Speed Control Switch) in accordance with the Service Information. Refer to «SWITCH, SPEED CONTROL , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/cruise-control-systems/#speed-control-service-information__removal) . Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .

P0580-00-SPEED CONTROL SWITCH 1 CIRCUIT LOW

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

The Speed Control Switch is hardwired to the Steering Column Control Module (SCCM). The SCCM is located near the top of the steering column below the steering wheel. The SCCM includes the steering column shroud, the Steering Angle Sensor (SAS), the Clockspring, the Multi-function Switch, a Steering Column Power Tilt and Telescope Switch (if equipped), and a trim cover. The SCCM is replaced as an entire assembly.

Continuously with the ignition on.

Fault signifies when the switch voltage is shorted low.

1. CHECK FOR AN ACTIVE DTC Turn the ignition on. With the scan tool, read DTCs Does the scan tool display this DTC as active? Yes WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. WARNING: Do not place an intact non-deployed airbag face down on a hard surface, the airbag propels into the air if accidentally deployed. Failure to follow these instructions may result in possible serious or fatal injury. NOTE: Visually and physically inspect the wiring harness between the Right Steering Wheel Switch (Speed Control Switch) harness connector and the SCCM harness connector. Repair any damaged wires, connectors, and open/spread terminals. If harness is OK, proceed with test. Replace the Right Steering Wheel Switch (Speed Control Switch) in accordance with the Service Information. Refer to «SWITCH, SPEED CONTROL , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/cruise-control-systems/#speed-control-service-information__removal) . Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .

P0581-00-SPEED CONTROL SWITCH 1 CIRCUIT HIGH

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

The Speed Control Switch is hardwired to the Steering Column Control Module (SCCM). The SCCM is located near the top of the steering column below the steering wheel. The SCCM includes the steering column shroud, the Steering Angle Sensor (SAS), the Clockspring, the Multi-function Switch, a Steering Column Power Tilt and Telescope Switch (if equipped), and a trim cover. The SCCM is replaced as an entire assembly.

Continuously with the ignition on.

Fault signifies when the switch voltage is shorted high.

1. CHECK FOR AN ACTIVE DTC Turn the ignition on. With the scan tool, read DTCs Does the scan tool display this DTC as active? Yes WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. WARNING: Do not place an intact non-deployed airbag face down on a hard surface, the airbag propels into the air if accidentally deployed. Failure to follow these instructions may result in possible serious or fatal injury. NOTE: Visually and physically inspect the wiring harness between the Right Steering Wheel Switch (Speed Control Switch) harness connector and the SCCM harness connector. Repair any damaged wires, connectors, and open/spread terminals. If harness is OK, proceed with test. Replace the Right Steering Wheel Switch (Speed Control Switch) in accordance with the Service Information. Refer to «SWITCH, SPEED CONTROL , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/cruise-control-systems/#speed-control-service-information__removal) . Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .

P0585-00-SPEED CONTROL SWITCH 1/2 CORRELATION

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

The Speed Control Switch is hardwired to the Steering Column Control Module (SCCM). The SCCM is located near the top of the steering column below the steering wheel. The SCCM includes the steering column shroud, the Steering Angle Sensor (SAS), the Clockspring, the Multi-function Switch, a Steering Column Power Tilt and Telescope Switch (if equipped), and a trim cover. The SCCM is replaced as an entire assembly.

Continuously with the ignition on.

The Steering Column Control Module (SCCM) has detected that a non-permissable combination has occurred in the Speed Control Switch.

1. CHECK FOR AN ACTIVE DTC Turn the ignition on. With the scan tool, read DTCs Does the scan tool display this DTC as active? Yes Go To 2 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .
2. SPEED CONTROL SWITCH Turn the ignition off. WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. WARNING: Do not place an intact non-deployed airbag face down on a hard surface, the airbag propels into the air if accidentally deployed. Failure to follow these instructions may result in possible serious or fatal injury. NOTE: Visually and physically inspect the wiring harness between the Right Steering Wheel Switch (Speed Control Switch) harness connector and the SCCM harness connector. Repair any damaged wires, connectors, and open/spread terminals. If harness is OK, proceed with test. Replace the Right Steering Wheel Switch (Speed Control Switch) in accordance with the Service Information. Refer to «SWITCH, SPEED CONTROL , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/cruise-control-systems/#speed-control-service-information__removal) . Turn the ignition on. Move the Speed Control Switch to each position several times. With the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes Replace the Steering Column Control Module (SCCM) in accordance with the Service Information. Refer to «MODULE, STEERING COLUMN , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#electronic-control-modules-service-information) . Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) . No Test Complete. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .

P0591-00-SPEED CONTROL SWITCH 2 PERFORMANCE

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

The Speed Control Switch is hardwired to the Steering Column Control Module (SCCM). The SCCM is located near the top of the steering column below the steering wheel. The SCCM includes the steering column shroud, the Steering Angle Sensor (SAS), the Clockspring, the Multi-function Switch, a Steering Column Power Tilt and Telescope Switch (if equipped), and a trim cover. The SCCM is replaced as an entire assembly.

Continuously with the ignition on.

The Steering Column Control Module (SCCM) has detected that a non-permissable combination has occurred in the Speed Control Switch.

1. CHECK FOR AN ACTIVE DTC Turn the ignition on. With the scan tool, read DTCs Does the scan tool display this DTC as active? Yes WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. WARNING: Do not place an intact non-deployed airbag face down on a hard surface, the airbag propels into the air if accidentally deployed. Failure to follow these instructions may result in possible serious or fatal injury. NOTE: Visually and physically inspect the wiring harness between the Right Steering Wheel Switch (Speed Control Switch) harness connector and the SCCM harness connector. Repair any damaged wires, connectors, and open/spread terminals. If harness is OK, proceed with test. Replace the Right Steering Wheel Switch (Speed Control Switch) in accordance with the Service Information. Refer to «SWITCH, SPEED CONTROL , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/cruise-control-systems/#speed-control-service-information__removal) . Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .

P0592-00-SPEED CONTROL SWITCH 2 CIRCUIT LOW

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

The Speed Control Switch is hardwired to the Steering Column Control Module (SCCM). The SCCM is located near the top of the steering column below the steering wheel. The SCCM includes the steering column shroud, the Steering Angle Sensor (SAS), the Clockspring, the Multi-function Switch, a Steering Column Power Tilt and Telescope Switch (if equipped), and a trim cover. The SCCM is replaced as an entire assembly.

Continuously with the ignition on.

Fault signifies when the switch voltage is shorted low.

1. CHECK FOR AN ACTIVE DTC Turn the ignition on. With the scan tool, read DTCs Does the scan tool display this DTC as active? Yes WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. WARNING: Do not place an intact non-deployed airbag face down on a hard surface, the airbag propels into the air if accidentally deployed. Failure to follow these instructions may result in possible serious or fatal injury. NOTE: Visually and physically inspect the wiring harness between the Right Steering Wheel Switch (Speed Control Switch) harness connector and the SCCM harness connector. Repair any damaged wires, connectors, and open/spread terminals. If harness is OK, proceed with test. Replace the Right Steering Wheel Switch (Speed Control Switch) in accordance with the Service Information. Refer to «SWITCH, SPEED CONTROL , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/cruise-control-systems/#speed-control-service-information__removal) . Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .

P0593-00-SPEED CONTROL SWITCH 2 CIRCUIT HIGH

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

The Speed Control Switch is hardwired to the Steering Column Control Module (SCCM). The SCCM is located near the top of the steering column below the steering wheel. The SCCM includes the steering column shroud, the Steering Angle Sensor (SAS), the Clockspring, the Multi-function Switch, a Steering Column Power Tilt and Telescope Switch (if equipped), and a trim cover. The SCCM is replaced as an entire assembly.

Continuously with the ignition on.

Fault signifies when the switch voltage is shorted high.

1. CHECK FOR AN ACTIVE DTC Turn the ignition on. With the scan tool, read DTCs Does the scan tool display this DTC as active? Yes WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. WARNING: Do not place an intact non-deployed airbag face down on a hard surface, the airbag propels into the air if accidentally deployed. Failure to follow these instructions may result in possible serious or fatal injury. NOTE: Visually and physically inspect the wiring harness between the Right Steering Wheel Switch (Speed Control Switch) harness connector and the SCCM harness connector. Repair any damaged wires, connectors, and open/spread terminals. If harness is OK, proceed with test. Replace the Right Steering Wheel Switch (Speed Control Switch) in accordance with the Service Information. Refer to «SWITCH, SPEED CONTROL , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/cruise-control-systems/#speed-control-service-information__removal) . Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .

P1593-2A-SPEED CONTROL SWITCH 1/2 STUCK

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

The Speed Control Switch is hardwired to the Steering Column Control Module (SCCM). The SCCM is located near the top of the steering column below the steering wheel. The SCCM includes the steering column shroud, the Steering Angle Sensor (SAS), the Clockspring, the Multi-function Switch, a Steering Column Power Tilt and Telescope Switch (if equipped), and a trim cover. The SCCM is replaced as an entire assembly.

Continuously with the ignition on.

Fault signifies any Speed Control Switch is held/stuck for greater than 120 seconds.

1. CHECK FOR AN ACTIVE DTC Turn the ignition on. With the scan tool, read DTCs Does the scan tool display this DTC as active? Yes WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. WARNING: Do not place an intact non-deployed airbag face down on a hard surface, the airbag propels into the air if accidentally deployed. Failure to follow these instructions may result in possible serious or fatal injury. NOTE: Visually and physically inspect the wiring harness between the Right Steering Wheel Switch (Speed Control Switch) harness connector and the SCCM harness connector. Repair any damaged wires, connectors, and open/spread terminals. If harness is OK, proceed with test. Replace the Right Steering Wheel Switch (Speed Control Switch) in accordance with the Service Information. Refer to «SWITCH, SPEED CONTROL , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/cruise-control-systems/#speed-control-service-information__removal) . Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .

U0002-00-CAN C BUS OFF PERFORMANCE

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

Ignition run time is greater than one second.

Battery voltage between 9 and 16 volts.

Engine run time greater than three seconds.

Bus messages not received from the Totally Integrated Power Module (TIPM) for approximately two to five seconds.

1. ACTIVE DTC Ignition on, engine not running. With the scan tool, select view DTCs. Is the DTC Active at this time? Yes Diagnose the U0002-00-CAN C BUS OFF PERFORMANCE as the U0001-CAN C BUS CIRCUIT test. Refer to «DIAGNOSIS AND TESTING»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-dtcs-b10b4-to-b25ae) and perform the U0001-CAN C Bus diagnostic procedure. No Refer to «DIAGNOSIS AND TESTING»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#communication-non-dtc-based-diagnostics) and perform the Stored Lost Communication DTCs diagnostic procedure.

U0100-00-LOST COMMUNICATION WITH PCM

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

Continuously when the ignition is on.

The battery voltage between 10 and 16 Volts.

Ignition Off Draw (IOD) fuse installed.

Totally Integrated Power Module (TIPM) is configured correctly.

Bus messages not received from the Powertrain Control Module (PCM) for approximately two to five seconds.

1. VERIFY THE DTC IS ACTIVE NOTE: Make sure the IOD fuse is installed and the battery is fully charged before proceeding. Turn the ignition on. Using the scan tool, read the active DTCs. Is the DTC active at this time? Yes Perform the U0100-Lost Communication with PCM diagnostic procedure. Refer to «DIAGNOSIS AND TESTING»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-dtcs-b10b4-to-b25ae) . . No Perform the Stored Lost Communication DTCs diagnostic procedure. Refer to «DIAGNOSIS AND TESTING»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#communication-non-dtc-based-diagnostics) . .

U0146-00-LOST COMMUNICATION WITH CENTRAL GATEWAY

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

Continuously when the ignition is on.

Battery voltage between 10 and 16 volts.

Ignition Off Draw (IOD) fuse installed.

Totally Integrated Power Module (TIPM) is configured correctly.

Bus messages not received from the Central Gateway for approximately two to five seconds.

1. VERIFY DTC IS ACTIVE NOTE: Make sure the IOD fuse is installed and the battery is fully charged before proceeding. Turn the ignition on. With the scan tool, read active DTCs. Is this DTC active? Yes Refer to «DIAGNOSIS AND TESTING»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-dtcs-b10b4-to-b25ae) and perform the U0141-Lost Communication with IPM (FCM/TIPM) diagnostic procedure. No Refer to «DIAGNOSIS AND TESTING»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#communication-non-dtc-based-diagnostics) and perform the Stored Lost Communication DTCs diagnostic procedure.

U0155-00-LOST COMMUNICATION WITH CLUSTER/CCN

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

Continuously when the ignition is on.

Battery voltage between 10 and 16 volts.

Ignition Off Draw (IOD) fuse installed.

Totally Integrated Power Module (TIPM) is configured correctly.

Bus messages not received from the Instrument Cluster (CCN) for approximately two to five seconds.

1. VERIFY DTC IS ACTIVE NOTE: Make sure the IOD fuse is installed and the battery is fully charged before proceeding. Turn the ignition on. With the scan tool, read active DTCs. Is this DTC active? Yes Refer to «DIAGNOSIS AND TESTING»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-dtcs-b10b4-to-b25ae) and perform the U0155-Lost Communication with Cluster/CCN diagnostic procedure. No Refer to «DIAGNOSIS AND TESTING»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#communication-non-dtc-based-diagnostics) and perform the Stored Lost Communication DTCs diagnostic procedure.

U1008-00-LIN 1 BUS

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

The Right Steering Wheel Switch communicates with the Steering Column Control Module (SCCM) via the LIN Bus. The SCCM is located near the top of the steering column below the steering wheel. The SCCM includes the steering column shroud, the Steering Angle Sensor (SAS), the Clockspring, the Multi-function Switch, a Steering Column Power Tilt and Telescope Switch (if equipped), and a trim cover. The SCCM is replaced as an entire assembly.

Continuously with the ignition on.

Fault signifies when the LIN Bus is shorted to ground, shorted to battery, or a defective Right Steering Wheel Switch (Speed Control Switch).

1. CHECK FOR AN ACTIVE DTC Turn the ignition on. With the scan tool, read DTCs Does the scan tool display this DTC as active? Yes WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. WARNING: Do not place an intact non-deployed airbag face down on a hard surface, the airbag propels into the air if accidentally deployed. Failure to follow these instructions may result in possible serious or fatal injury. NOTE: Visually and physically inspect the wiring harness between the Right Steering Wheel Switch (Speed Control Switch) harness connector and the SCCM harness connector. Repair any damaged wires, connectors, and open/spread terminals. If harness is OK, view repair. Replace the Right Steering Wheel Switch (Speed Control Switch) in accordance with the Service Information. Refer to «SWITCH, SPEED CONTROL , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/cruise-control-systems/#speed-control-service-information__removal) . Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .

U1175-00-LOST IGNITION STATUS MESSAGE

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

Continuously when the ignition is on.

The Steering Control Module does not receive the Ignition Switch status over the CAN Bus.

1. CHECK FOR AN ACTIVE DTC NOTE: Make sure the IOD fuse is installed and the battery is fully charged before proceeding. NOTE: Diagnose any CAN Bus DTCs that may be set in other modules before proceeding with this diagnostic procedure. Turn the ignition on. With the scan tool, read active DTCs. Dose the scan tool display this DTC as active? Yes If no other CAN Bus DTCs are set in other modules and the SCCM is the only one reporting this DTC, replace the SCCM in accordance with the Service Information. Refer to «MODULE, STEERING COLUMN , REMOVAL»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#electronic-control-modules-service-information) . Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .

See also:
• SWITCH, SPEED CONTROL , REMOVAL
• STANDARD PROCEDURE
• SWITCH, EVIC CONTROL , REMOVAL
• MODULE, STEERING COLUMN , REMOVAL
• SWITCH, HORN , REMOVAL
• DIAGNOSTIC CODE INDEX - 3.0L DIESEL
• DIAGNOSTIC CODE INDEX - NGC
• DIAGNOSIS AND TESTING
• DIAGNOSIS AND TESTING
• B1425-2A
• B1504-2A
• B1D9C-00
• B1D9C-2A
• B2225-00
• B2306-2A
• B232E-00
• B2332-2A
• B23A1-2A
• C1240-76
• C2129-16
• C2129-17
• C212A-16
• C212A-17
• C2205-00
• C2205-29
• C2205-2F
• C2205-41
• C2205-96
• P0579-00
• P0580-00
• P0581-00
• P0585-00
• P0591-00
• P0592-00
• P0593-00
• P1593-2A
• U0002-00
• U0100-00
• U0146-00
• U0155-00
• U1008-00
• U1175-00
