SPECIAL TOOLS
10368 - Set, Universal Protective Cap 7700 - Tester, Cooling System (Originally Shipped In Kit Number(s) 7700-A.) 8116 - Adapter, Pressure PEP (Originally Shipped In Kit Number(s) 8201, 8201CC, 8204, 8204CC.) 8514 - Pins, Tensioner (Originally Shipped In Kit Number(s) 8283, 8283CC, 8527, 8527CC, 8575, 8575CC, 9975.) 9506 - Installer, Oil Seal (Originally Shipped In Kit Number(s) 9610, 9970.) 9509 - Installer, Oil Seal (Originally Shipped In Kit Number(s) 9610, 9970.) 9701 - Wedge, Locking (Originally Shipped In Kit Number(s) 9610, 9970.) 9703 - Pin, Tensioner (Originally Shipped In Kit Number(s) 9610, 9970.) 9706 - Installer, Crankshaft Rear Oil Seal (Originally Shipped In Kit Number(s) 9610, 9970.) 9707 - Holder, Vibration Damper (Originally Shipped In Kit Number(s) 9610, 9970.) 9879 - Adapter, Oil Pressure Test (Originally Shipped In Kit Number(s) 9998.) C-3685-A - Block-Check Kit C-4171 - Driver Handle, Universal (Originally Shipped In Kit Number(s) 9202, 9202A-CAN, 9202CC, 9299, 9299CC, 9299CC, 9300A-CAN.) C-4597 - Socket, Oil Pressure
Scheme 560
Scheme 561
Scheme 562
Scheme 563
Scheme 564
Scheme 565
Scheme 566
Scheme 567
Scheme 568
Scheme 569
Scheme 570
Scheme 571
Scheme 572
The engine serial number (1) is located between the oil pan and the bellhousing. The serial number contains engine build date, build location, and displacement.
Example: 8CAP1339710217
| WORLD ENGINE | |||||||
|---|---|---|---|---|---|---|---|
| 8 | C | A | P1 | 339 | 7 | 1 | 0217 |
| Model Year | Engine Displacement | Engine Build Variation (with oil cooler, turbo, for MMNA) | Engine Plant | Julian Day of Year | Julian Year 2007 | Shift | Build Sequence Number |
| 2008 | A = 1.8L | P1 = GEMA North | |||||
| B = 2.0L | P2 = GEMA South | ||||||
| C = 2.4L | |||||||
Scheme 573
Scheme 574
- Unlock the retainers (2) and remove the fresh air inlet duct (3) from air cleaner housing (1).
- Remove the support bracket bolt from the strut tower.
- Remove the screws that hold the cover on the air cleaner housing. CAUTION: Do Not unplug the electrical connectors from the Powertrain Control Module (PCM). A possible voltage spike can erase and damage the PCM.
- Position the air cleaner housing cover aside.
- Remove the air cleaner element (1).
- If necessary, clean the inside of the air cleaner housing.
Scheme 575
- Install the new cleaner element (1). CAUTION: Do Not unplug the electrical connectors from the Powertrain Control Module (PCM). A possible voltage spike can erase and damage the PCM.
- Place the cover over the air cleaner housing. Hand tighten the cover screws.
- Install the support bracket bolt to the strut tower and tighten to 10 N.m (89 in. lbs.).
- Install the fresh air inlet duct (3) on the air cleaner housing (1) and lock the retainers (2).
