TORQUE SPECIFICATIONS
| Description | N.m | Ft. Lbs | In. Lbs |
|---|---|---|---|
| EGR Air Flow Control Valve Bolt | 9 | 80 | |
| EGR Back Pressure Transducer | 25 | 18 | |
| EGR Bypass Valve | 9 | 80 | |
| EGR Bypass Vacuum Diaphragm Bolt | 12 | 106 | |
| EGR Cooler Support Bolt | 9 | 80 | |
| EGR Manifold Bolts | 9 | 80 | |
| EGR Support Bracket Bolts | 9 | 80 | |
| EGR Tube Bolt | 9 | 80 | |
| EGR Vacuum Solenoid Bolts | 9 | 80 | |
| EGR Valve Bolts | 9 | 80 | |
| Vacuum Tube Bolt | 9 | 80 |
TORQUE SPECIFICATIONS TABLE
Scheme 18
The EGR solenoid (2) is attached to a bracket that is mounted to the top of intake manifold. The EGR solenoid serves two different functions. One is to control vacuum bleed-off of the EGR valve. The other is to control the "on time" of the EGR valve.
Scheme 19
- Disconnect the negative battery cable.
- Remove the engine cover (1).
- Disconnect the EGR solenoid wire harness connector (3).
- Disconnect the EGR vacuum harness (1) from the EGR solenoid (2).
- Remove bolts (4) and the EGR vacuum solenoid (2) from the intake manifold.
