Emissions Control: Removal & Installation Jeep Compass I рестайлинг 2

INSTALLATION

1. Install evaporator purge solenoid (1) to body bracket (5). Make sure the tab secures the solenoid to the bracket.
2. Install quick connect fuel tank hose (2) to evaporator purge solenoid (1).
3. Install purge hose (3) to evaporator purge solenoid (1).
4. Connect electrical connector (4) to evaporator purge solenoid (1).
5. Connect negative battery cable, tighten nut to 5 N.m (45 in. lbs.).

Scheme 52

It threads into the valve cover.

Scheme 53

When the engine is not operating or during an engine backfire, the spring forces the plunger back against the seat. This prevents vapors from flowing through the valve.

Scheme 54

When the engine is at idle or cruising, high manifold vacuum is present. At these times manifold vacuum is able to completely compress the spring and pull the plunger to the top of the valve. In this position there is minimal vapor flow through the valve.

Scheme 55

During periods of moderate intake manifold vacuum the plunger is only pulled part way back from the inlet. This results in maximum vapor flow through the valve.

1. Install EGR vacuum solenoid (2) onto the intake manifold. Tighten bolts (4) to 9 N.m (80 in. lbs.).
2. Connect EGR vacuum harness (1) to the EGR solenoid (2).
3. Connect EGR solenoid wire harness connector (3).
4. Install the engine cover (1).
5. Connect the negative battery cable.

Scheme 56

Scheme 57

1. Disconnect the negative battery cable.
2. Remove the engine cover (1).
3. Disconnect the EGR back pressure transducer wire harness connector (1).
4. Remove the EGR back pressure transducer (1).

Scheme 58

1. Using a new sealing washer (1), install the EGR back pressure transducer (2). Tighten transducer (2) to 25 N.m (18 ft. lbs.).
2. Connect the EGR back pressure transducer wire harness connector (1).
3. Install the engine cover (1).
4. Connect the negative battery cable.

Scheme 59

1. Disconnect the negative battery cable.
2. Remove the engine cover (1).
3. Remove the four bolts (1) and the EGR tube (2).

Scheme 60

Scheme 61

1. Clean all gasket mating surfaces.
2. Install a new EGR tube gasket (1) onto the EGR actuator.
3. Install a new EGR tube gasket (1) onto the mixing chamber.
4. Install the EGR tube (2). Tighten bolts (1) to 9 N.m (80 in. lbs.).
5. Install the engine cover (1).
6. Connect the negative battery cable.
