Removal & Installation
Door module is mounted to inside of front door trim panel. Remove front door trim panel. See DOOR TRIM PANEL . Disconnect door module harness connector. Remove 3 screws securing door module to door trim panel. Remove door module from trim panel. To install, reverse removal procedure. Tighten trim panel screws to 20 INCH lbs. (2.2 N.m).
Removal & Installation (Front Door Panel)
Disconnect negative battery cable. Remove door panel screws. Using a trim stick, starting at bottom of panel, gently pry around perimeter of trim panel. Lift door trim upward and away from door to disengage top of panel from inner weather-stripping. Pull door trim panel outward and disconnect handle-to-latch rods. Disconnect door module harness connectors. Remove door trim panel from door. To install, reverse removal procedure.
Removal & Installation (Rear Door Panel)
Put window in down position. Disconnect negative battery cable. Remove door trim panel mounting screws. Using trim stick, starting at bottom of panel, gently pry around perimeter of trim panel. Pull door trim panel outward and disconnect handle-to-latch rods. Disconnect power window harness connector. Remove trim panel from door. To install, reverse removal procedure.
Removal & Installation (Front Window Motor)
- Disconnect negative battery cable. Remove front door trim panel. See «DOOR TRIM PANEL»(ref-91529-S20705940622001032300000). Pry up on weather-stripping corner. Remove inner and outer weather-stripping. (Scheme 1)
- Remove bolts securing glass to regulator assembly. Remove glass. Loosen bolts securing power window regulator assembly to inner door panel. Loosen upper power window regulator assembly to inner door panel. (Scheme 2)
- Disconnect power window motor harness connector. Remove regulator assembly through access hole in inner door panel. To install, reverse removal procedure.
Scheme 1
Scheme 2
Removal & Installation (Rear Window Motor)
Disconnect negative battery cable. Remove rear door trim panel. See DOOR TRIM PANEL. Remove bolt securing glass to regulator assembly, and support. Remove lower regulator assembly mounting bolts to inner door panel. (Scheme 3) Remove power window motor nuts. Loosen upper regulator assembly mounting bolt to inner door panel. Disconnect power window motor harness connector. Remove regulator assembly. To install, reverse removal procedure.
Scheme 3
Removal & Installation (Rear Window Switch)
Disconnect negative battery cable. Remove rear door trim panel. See DOOR TRIM PANEL . Using a trim stick, gently pry snap clips at sides of power window switch. Remove power window switch from receptacle in trim panel. To install, reverse removal procedure.
