Specifications
| Description | Nm |
|---|
| Front seat cushion retaining nuts | 25 |
| Front seat recliner motor retaining bolt | 8 |
| Front seat retaining bolts | 25 |
| Front seat control module retaining nuts | 7 |
| Front seat control module bracket retaining nuts | 4 |
| Front seat head restraint control module retaining nuts | 7 |
Scheme 1
Scheme 2
The front seat frames are common to both the coupe and convertible and are equipped with the following
- Seat control switch
- Front seat cushion front height adjustment
- Front seat cushion rear height adjustment
- Front seat backrest adjustment
- Front seat head restraint adjustment - vehicles without sport seats
- Lumbar adjustment
- Front seat forward and backward adjustment
- Side air bag module
- Front seat backrest heating
- Front seat cushion heating
| WARNING | Prior to removal of the front seats and before disconnecting the front seat wiring harness electrical connectors (which includes the side air bag module electrical connectors), the battery ground cable should be disconnected and a period of at least one minute allowed to elapse. The same amount of care should be taken when handling and storing the front seats, as would be taken when handling and storing air bag modules. |
The driver and passenger front seats, although almost identical, have some unique components. The front driver seat has a seat position sensor and the front passenger seat has a weight sensing system. In both instances the components form an integral part of the air bag supplemental restraint system (SRS). Refer to Supplemental Restraint System article.
Scheme 3
Scheme 3: Seat Control Switch
| Item Number | Description |
|---|
| 1 | Front seat forward and backward adjustment, front seat cushion front height adjustment and front seat cushion rear height adjustment |
| 2 | Front seat backrest adjustment and front seat head restraint adjustment |
| 3 | Front seat lumbar adjustment |
The front seat control switches are installed in the outboard side of both the driver and passenger front seats.
Scheme 4
Scheme 4: Driver Seat Underside
| Item Number | Description |
|---|
| 1 | Driver seat module (DSM) |
| 2 | Front seat cushion front height adjustment motor |
| 3 | Seat track position sensor |
| 4 | Front seat cushion rear height adjustment motor |
Scheme 5
Scheme 5: Passenger Seat Underside
| Item Number | Description |
|---|
| 1 | Passenger seat module (PSM) |
| 2 | Front seat cushion front height adjustment motor |
| 3 | Front passenger seat occupant classification sensor hose |
| 4 | Front seat cushion rear height adjustment motor |
