Front Seat Head Restraint - Vehicles Without: Recaro Seats

Note. Left-hand seat backrest shown, right-hand seat backrest similar.

Scheme 67

The front seat head restraint position is controlled by three components. The front seat head restraint control module, the front seat head restraint motor and the front seat head restraint control switch.

Seat Backrest Tilt Feature - Vehicles Without: Recaro Seats

Note. The front seat head restraint will lower in the event that the seat backrest tilt microswitch fails. In this condition, the front seat head restraint will not work until the front seat is tilted forward, responding to the front seat latch microswitch changing state.

Scheme 68

The front seat head restraint control module controls the front seat head restraint motor by responding to the status of three seat control switches. The front seat backrest tilt microswitch, the front seat latch microswitch and the front seat head restraint switch.

The front seat head restraint automatically lowers when the front seat backrest is tilted forward. This feature is controlled by two microswitches. The front seat backrest tilt knob actuates the front seat backrest tilt microswitch causing the front seat head restraint to fully retract. When the front seat backrest is returned to the normal driving position, the front seat latch microswitch causes the front seat head restraint to return to its previous position. The vehicle occupant can position the front seat head restraint to suit their stature by pressing the front seat head restraint switch which is the center switch of the front seat control switch.

Scheme 69

The rear seat frames are not common between the coupe and convertible. They are wire framed units trimmed to match the front seats. There is no provision for rear seat adjustment on either model.

Child seat lower International Standards Organization fix (ISOfix) anchors are fitted. Refer to Safety Belt System article.

Seats - Diagnostic Procedures

With the increase in complexity of electronic modules and the multiplexed communication network, the general use of electrical test equipment is no longer practical. The approved Jaguar diagnostic equipment should be used in the diagnosis and testing of seat functions.

For detailed instructions on the diagnosis and testing of these functions, refer to the approved Jaguar diagnostic equipment user guide.

Driver seat and front passenger seat

1. Remove the front seat. Refer to «Front Seat - Removal and Installation»(ref-311033-S39206335792009032300000) .
2. Remove the seat control switch. Refer to «Seat Control Switch - Removal and Installation»(ref-311033-S34014730902009032300000) .

Driver seat

1. Remove the driver seat module (DSM). Refer to «Multifunction Electronic Modules»(ref-311086) article.

Front passenger seat

1. Remove the passenger seat module (PSM). Refer to «Multifunction Electronic Modules»(ref-311086) article.

Scheme 70

Scheme 71

Scheme 72

1. Remove the seat base retaining nuts.
2. Detach the lower finish panel.
3. Disconnect the front seat cushion heater mat electrical connector.

Scheme 73

1. Disconnect the front passenger seat occupant classification sensor electrical connector.
2. Detach the front passenger seat occupant classification sensor.

Scheme 74

Scheme 75

Scheme 76

Scheme 77

Scheme 78

Scheme 79

Scheme 80

Scheme 81

Scheme 82

1. Detach the electrical connectors.
2. Disconnect the electrical connectors.
3. Detach the seat wiring harness.
4. Detach the seat wiring harness.
5. Remove the front seat cushion from the seat base.
6. Detach the front seat cushion cover from the seat base. Remove and discard the hog rings. Release the retaining clips.
7. Remove and discard the front seat cushion cover retaining staples.
8. Detach the front seat cushion cover.
9. Remove the front seat cushion cover. Remove and discard the hog rings.

1. Remove the front seat. Refer to «Front Seat - Removal and Installation»(ref-311033-S39206335792009032300000) .
2. Remove the seat control switch. Refer to «Seat Control Switch - Removal and Installation»(ref-311033-S34014730902009032300000) .

1. Remove the driver seat module (DSM). Refer to «Multifunction Electronic Modules»(ref-311086) article.

1. Remove the passenger seat module (PSM). Refer to «Multifunction Electronic Modules»(ref-311086) article.

Scheme 83

1. Remove the seat base retaining nuts.
2. Detach the lower finish panel.
3. Detach the front seat cushion cover from the seat base.
4. Disconnect the front seat cushion heater mat electrical connector.

1. Disconnect the front passenger seat occupant classification sensor electrical connector.
2. Detach the front passenger seat occupant classification sensor.

Scheme 84

Scheme 85

Scheme 86

Scheme 87

1. Detach the electrical connectors.
2. Disconnect the electrical connectors.
3. Detach the seat wiring harness.
4. Detach the seat wiring harness.
5. Remove the front seat cushion from the seat base.
6. Remove and discard the front seat cushion cover front retaining clips.
7. Detach the front seat cushion cover from the seat base. Remove and discard the hog rings. Release the retaining clips.
8. Remove and discard the front seat cushion cover retaining staples.
9. Detach the front seat cushion cover.
10. Remove the front seat cushion cover. Remove and discard the hog rings.

Driver seat and passenger seat

1. Remove the front seat height adjustment motor. Refer to «Front Seat Height Adjustment Motor - Removal and Installation»(ref-311033-S22544934382009032300000) .

1. Remove the driver seat module (DSM). Refer to «Multifunction Electronic Modules»(ref-311086) article.

Passenger seat

1. Remove the passenger seat module (PSM). Refer to «Multifunction Electronic Modules»(ref-311086) article.

Scheme 88

Scheme 89

Scheme 90

1. Disconnect the front seat track motor electrical connector.
2. Remove the front seat track motor retaining bolts.
3. Remove the front seat track motor. Detach the front seat track motor from the drive cables.
