Seating: Removal & Installation Jaguar XKR I рестайлинг

Seats 61 illustrations ~1725 words

Removal

WARNINGBEFORE ANY AIR BAG/SRS SERVICE IS PERFORMED, AT LEAST ONE MINUTE MUST ELAPSE AFTER DISCONNECTION OF THE BATTERY POSITIVE CABLE TO ALLOW DISSIPATION OF BACK-UP POWER SUPPLY ENERGY.
WARNINGIN THE EVENT OF A FAULT RUPTURING THE 10A BATTERY SUPPLY FUSE (F4 LOCATED IN THE FUSE BOX AT THE DRIVER END OF THE FASCIA) THE FUSE MUST NOT BE RENEWED UNTIL THE AIR BAG/SRS SYSTEM HAS BEEN DE-ACTIVATED. FUSES OF ANY OTHER VALUE MUST NEVER BE USED AS THIS CAN CAUSE DISARM FAILURE.
WARNINGAFTER DEPLOYMENT, THE AIR BAG SURFACE CAN CONTAIN DEPOSITS OF SODIUM HYDROXIDE, A PRODUCT OF THE GAS GENERATED DURING COMBUSTION THAT IS IRRITATING TO THE SKIN. WASH YOUR HANDS WITH SOAP AND WATER AFTERWARDS. FAILURE TO FOLLOW THIS INSTRUCTION MAY RESULT IN PERSONAL INJURY.
WARNINGNEVER PROBE THE CONNECTORS ON THE AIR BAG MODULE. DOING SO MAY RESULT IN AIR BAG DEPLOYMENT. FAILURE TO FOLLOW THIS INSTRUCTION MAY RESULT IN PERSONAL INJURY.
WARNINGTO AVOID ACCIDENTAL DEPLOYMENT AND POSSIBLE PERSONAL INJURY, THE BACKUP POWER SUPPLY MUST BE DEPLETED BEFORE REPAIRING OR REPLACING ANY AIR BAG SUPPLEMENTAL RESTRAINT SYSTEM (SRS) COMPONENTS. TO DEPLETE THE BACKUP POWER SUPPLY ENERGY, DISCONNECT THE BATTERY GROUND CABLE AND WAIT ONE MINUTE. FAILURE TO FOLLOW THIS INSTRUCTION MAY RESULT IN PERSONAL INJURY.

Scheme 6

Scheme 6
Scheme 6

Scheme 7

Scheme 7
Scheme 7

Scheme 8

Scheme 8
Scheme 8

Scheme 9

Scheme 9
Scheme 9
  1. Position the front seat fully rearwards.
  2. Remove the front seat base trim panel.
  3. Remove the front seat front retaining bolts.
  4. Position the front seat fully forwards.
  5. Disconnect the battery ground cable. Refer to «Battery, Mounting and Cables»(ref-311034) article.
  6. Remove the front seat rear retaining bolts.
  7. Remove the front seat. Disconnect the front seat base electrical connectors.

Scheme 10

Scheme 10
Scheme 10
  1. Loosely install the front seat.
  2. Connect the front seat base electrical connectors.
  3. Install the front seat rear retaining bolts. Tighten to 25 Nm.
  4. Carry out the battery reconnection procedure. Refer to «Battery, Mounting and Cables»(ref-311034) article.
  5. Position the front seat fully rearwards.
  6. Install the front seat front retaining bolts. Tighten to 25 Nm.
  7. Install the front seat base trim panel.

Scheme 11

Scheme 11: Removal
Scheme 11: Removal

Scheme 12

Scheme 12
Scheme 12

Scheme 13

Scheme 13
Scheme 13

Scheme 14

Scheme 14
Scheme 14

Scheme 15

Scheme 15
Scheme 15

Scheme 16

Scheme 16
Scheme 16

Scheme 17

Scheme 17
Scheme 17

Scheme 18

Scheme 18
Scheme 18

Scheme 19

Scheme 19
Scheme 19

Scheme 20

Scheme 20
Scheme 20

Scheme 21

Scheme 21
Scheme 21

Scheme 22

Scheme 22
Scheme 22
  1. Remove the front seat. Refer to «Front Seat - Removal and Installation»(ref-311033-S39206335792009032300000) .
  2. Remove the front seat head restraint.
  3. Remove the front seat head restraint retaining trims.
  4. Remove the front seat tilt knob.
  5. Remove the front seat tilt knob trim panel retaining screw trim cover.
  6. Remove the front seat tilt knob trim panel.
  7. Reposition both front seat backrest hinge covers.
  8. Release the front seat backrest cover rear lower retaining clips.
  9. Remove the front seat backrest support panel.
  10. Release the front seat backrest cover retaining straps. Remove and discard the hog rings.
  11. Reposition the front seat backrest cover. Release the front seat backrest cover internal retaining clips.
  12. Reposition the side air bag module chute. Remove and discard the rivet. Reposition the side air bag module chute.
  13. Reposition the side air bag module chute through the front seat backrest cover.
  14. Remove and discard the hog rings.
  15. Remove the front seat cover.

Installation

  1. To install, reverse the removal procedure.

Scheme 23

Scheme 23: Removal
Scheme 23: Removal

Scheme 24

Scheme 24
Scheme 24

Scheme 25

Scheme 25
Scheme 25

Scheme 26

Scheme 26
Scheme 26

Scheme 27

Scheme 27
Scheme 27

Scheme 28

Scheme 28
Scheme 28

Scheme 29

Scheme 29
Scheme 29
  1. Adjust the front seat to the tilted position.
  2. Release the front seat backrest cover rear lower retaining clip.
  3. Release the front seat backrest cover rear upper retaining clips.
  4. Using a suitable knife, detach the front seat backrest cover from the front seat frame.
  5. Remove the front seat backrest. Disconnect the front seat backrest heater mat electrical connector.
  6. Remove and discard the front seat backrest cover retaining staples.
  7. Remove and discard the hog rings.
  8. Remove the front seat backrest cover. Remove and discard the hog rings.
  1. To install, reverse the removal procedure

Scheme 30

Scheme 30
Scheme 30

Scheme 31

Scheme 31
Scheme 31
  1. Remove the front seat. Refer to «Front Seat - Removal and Installation»(ref-311033-S39206335792009032300000) .
  2. Reposition both front seat backrest hinge covers.
  3. Release the front seat backrest cover rear lower retaining clips.
  4. Remove the front seat backrest support panel.
  5. Release the front seat backrest cover retaining straps. Remove and discard the hog rings.
  6. Reposition the front seat backrest cover. Release the front seat backrest cover internal retaining clips.
  7. Disconnect the front seat backrest heater mat electrical connector.
  8. Remove the front seat backrest heater mat.
  1. To install, reverse the removal procedure.

Scheme 32

Scheme 32
Scheme 32
  1. Adjust the front seat to the tilted position.
  2. Release the front seat backrest cover rear lower retaining clip.
  3. Release the front seat backrest cover rear upper retaining clips.
  4. Using a suitable knife, detach the front seat backrest cover from the front seat frame.
  5. Remove the front seat backrest. Disconnect the front seat backrest heater mat electrical connector.
  6. Remove and discard the front seat backrest cover retaining staples.
  7. Remove and discard the hog rings.
  8. Reposition the front seat backrest cover.
  9. Remove the front seat backrest heater mat.
  1. To install, reverse the removal procedure.
  1. To install, reverse the removal procedure.
  1. To install, reverse the removal procedure. Tighten to 25 Nm.

Scheme 33

Scheme 33: Removal
Scheme 33: Removal
  1. Remove the front seat cushion cover. Refer to «Front Seat Cushion Cover - Removal and Installation (Vehicles Without: Sports Seats)»(ref-311033-S38718768812009032300000) .
  2. Remove the front seat cushion heater mat.
  1. To install, reverse the removal procedure.

Scheme 34

Scheme 34: Removal
Scheme 34: Removal
  1. Remove the front seat cushion cover. Refer to «Front Seat Cushion Cover - Removal and Installation (Vehicles With: Sports Seats)»(ref-311033-S39313058752009032300000) .
  2. Remove the seat cushion heater mat.
  1. To install, reverse the removal procedure.

Scheme 35

Scheme 35
Scheme 35

Scheme 36

Scheme 36
Scheme 36
  1. Remove the front seat. Refer to «Front Seat - Removal and Installation»(ref-311033-S39206335792009032300000) .
  2. Reposition the front seat backrest hinge covers.
  3. Release the front seat backrest cover rear lower retaining clips.
  4. Remove the front seat backrest support panel.
  5. Release the front seat backrest cover retaining straps. Remove and discard the hog rings.
  6. Reposition the front seat backrest cover. Release the front seat backrest cover internal retaining clips.
  7. Detach the front seat head restraint module.
  8. Remove the front seat head restraint module. Disconnect the electrical connector.
  1. To install, reverse the removal procedure. Tighten to 7 Nm.

Scheme 37

Scheme 37: Removal
Scheme 37: Removal

Scheme 38

Scheme 38
Scheme 38

Scheme 39

Scheme 39
Scheme 39

Scheme 40

Scheme 40
Scheme 40

Scheme 41

Scheme 41
Scheme 41

Scheme 42

Scheme 42
Scheme 42
  1. Remove the front seat. Refer to «Front Seat - Removal and Installation»(ref-311033-S39206335792009032300000) .
  2. Remove and discard the front seat height adjustment motor wiring harness tie strap.
  3. Disconnect the front seat height adjustment motor electrical connector.
  4. Remove and discard the front seat height adjustment motor clevis pin retaining clip.
  5. Remove the front seat height adjustment motor clevis pin.
  6. Remove the front seat track to front seat height adjustment motor pivot bar clevis pin. Remove the front seat track to front seat height adjustment motor pivot bar clevis pin clip.
  7. Detach the front seat height adjustment motor pivot bar.
  8. Remove the front seat height adjustment motor.
  1. To install, reverse the removal procedure.

Scheme 43

Scheme 43
Scheme 43

Scheme 44

Scheme 44
Scheme 44

Scheme 45

Scheme 45
Scheme 45

Scheme 46

Scheme 46
Scheme 46

Scheme 47

Scheme 47
Scheme 47

Scheme 48

Scheme 48
Scheme 48

Scheme 49

Scheme 49
Scheme 49
  1. Remove the front seat. Refer to «Front Seat - Removal and Installation»(ref-311033-S39206335792009032300000) .
  2. Reposition both front seat backrest hinge covers.
  3. Release the front seat backrest cover rear lower retaining clips.
  4. Remove the front seat backrest support panel.
  5. Release the front seat backrest cover retaining straps. Remove and discard the hog rings.
  6. Reposition the front seat backrest cover. Release the front seat backrest cover internal retaining clips.
  7. Disconnect the front seat recliner motor electrical connector.
  8. Remove and discard the front seat recliner motor wiring harness tie strap.
  9. Remove the front seat recliner motor retaining bolt.
  10. Remove the front seat backrest hinge trim covers.
  11. Remove and discard the front seat recliner motor spindle retaining clip.
  12. Reposition the front seat recliner motor spindle.
  13. Remove the front seat recliner motor.
  1. To install, reverse the removal procedure.

Scheme 50

Scheme 50
Scheme 50

Scheme 51

Scheme 51
Scheme 51

Scheme 52

Scheme 52
Scheme 52

Scheme 53

Scheme 53
Scheme 53

Scheme 54

Scheme 54
Scheme 54

Scheme 55

Scheme 55
Scheme 55
  1. Remove the front seat. Refer to «Front Seat - Removal and Installation»(ref-311033-S39206335792009032300000) .
  2. Release the front seat backrest cover rear lower retaining clip.
  3. Detach the front seat backrest cover rear upper retaining clips.
  4. Using a suitable knife, detach the front seat backrest cover from the front seat frame.
  5. Remove the front seat backrest. Disconnect the front seat backrest heater mat electrical connector.
  6. Remove the front seat tilt knob.
  7. Remove the front seat tilt knob trim panel retaining screw trim cover.
  8. Remove the front seat tilt knob trim panel retaining screw.
  9. Remove the front seat tilt knob trim panel. Release the front seat tilt knob trim panel retaining tang from inside the front seat backrest frame.
  10. Detach the front seat backrest trim panel lower retaining clips.
  11. Remove the front seat backrest trim panel.
  12. Disconnect the front seat recliner motor electrical connector.
  13. Remove and discard the front seat recliner motor wiring harness tie strap.
  14. Remove the front seat recliner motor retaining bolt.
  15. Remove the front seat backrest hinge trim covers.
  16. Remove and discard the front seat recliner motor spindle retaining clip.
  17. Reposition the front seat recliner motor spindle.
  18. Remove the front seat recliner motor.
  1. To install, reverse the removal procedure.
  1. To install, reverse the removal procedure.

Scheme 56

Scheme 56
Scheme 56

Scheme 57

Scheme 57
Scheme 57
  1. Remove the front seat. Refer to «Front Seat - Removal and Installation»(ref-311033-S39206335792009032300000) .
  2. Reposition both front seat backrest hinge covers.
  3. Release the front seat backrest cover rear lower retaining clips.
  4. Remove the front seat backrest support panel.
  5. Release the front seat backrest cover retaining straps. Remove and discard the hog rings.
  6. Reposition the front seat backrest cover. Release the front seat backrest cover internal retaining clips.
  7. Disconnect the lumbar motor electrical connector.
  8. Remove the lumbar motor.
  1. To install, reverse the removal procedure.

Scheme 58

Scheme 58
Scheme 58

Scheme 59

Scheme 59
Scheme 59

Scheme 60

Scheme 60
Scheme 60

Scheme 61

Scheme 61
Scheme 61
  1. Detach the front seat backrest cover rear lower retaining clip.
  2. Detach the front seat backrest cover rear upper retaining clips.
  3. Using a suitable knife, detach the front seat backrest cover from the front seat frame.
  4. Remove the front seat backrest. Disconnect the front seat backrest heater mat electrical connector.
  5. Remove the front seat tilt knob.
  6. Remove the front seat tilt knob trim panel retaining screw trim cover.
  7. Remove the front seat tilt knob trim panel retaining screw.
  8. Remove the front seat tilt knob trim panel. Release the front seat tilt knob trim panel retaining tang from inside the front seat backrest frame.
  9. Detach the front seat backrest trim panel lower retaining clips.
  10. Remove the front seat backrest trim panel.
  11. Disconnect the lumbar motor electrical connector.
  12. Remove and discard the lumbar motor wiring harness tie strap.
  13. Remove the lumbar motor retaining screws. Remove the lumbar motor retaining screw clamps.
  14. Remove the lumbar motor.
  1. To install, reverse the removal procedure.

Scheme 62

Scheme 62: Removal
Scheme 62: Removal
  1. Remove rear seat cushion. Refer to «Rear Seat Cushion - Removal and Installation»(ref-311033-S35789268452009032300000) .
  2. Slacken and remove the two rear seat squab securing screws.
  3. Move seat squab upwards to release body tangs.
  4. Position rear seat belts for access and remove squab from vehicle.
  1. Position seat squab placing seat belts over.
  2. Finally position squab, engaging body tangs by applying downward hand pressure.
  3. Fit and tighten the two squab securing screws.
  4. Fit rear seat cushion. Refer to «Rear Seat Cushion - Removal and Installation»(ref-311033-S35789268452009032300000) .

Scheme 63

Scheme 63: Removal
Scheme 63: Removal

Scheme 64

Scheme 64
Scheme 64
  1. Using the rear passenger access knobs, position the back of each front seat fully forward.
  2. Slacken and remove the two rear seat cushion securing nuts.
  3. Raise seat cushion for access, pass seat belt anchors through central penetration and remove seat cushion from vehicle.
  1. Position seat cushion for access and pass rear seat belt anchors through central penetration.
  2. Finally position cushion and fit and tighten securing nuts.
  3. Return front seat backs to the upright position.

Scheme 65

Scheme 65: Removal
Scheme 65: Removal

Scheme 66

Scheme 66
Scheme 66
  1. Disconnect the battery ground cable. Refer to «Battery, Mounting and Cables»(ref-311034) article.
  2. Detach the seat control switch.
  3. Remove the seat control switch. Disconnect the seat control switch electrical connector.
  1. To install, reverse the removal procedure.

More articles — Seating
