Audio Unit: Removal & Installation Jaguar XKR I рестайлинг

Entertainment Systems 4 illustrations ~592 words

Installation

  1. Slide radio into mounting panel and position at console for access.
  2. Connect aerial co-axial lead to radio and stow excess harness and lead lengths in radio mounting aperture.
  3. Fully seat radio in console, ensuring that retaining clips are fully seated and harnesses and leads do not obstruct.
  4. Install radio mounting panel on the console.
  5. Holding radio console in position, route radio harness multi-plugs into center console.
  6. Connect radio harness and radio console harness multi-plugs.
  7. Route ground and aerial leads through radio console.
  8. Finally position radio console and install the six securing screws.
  9. Position ground lead on radio stud and install securing nut.
  10. Connect aerial lead to radio.
  11. Ensuring harness and leads do not obstruct, push radio fully home.
  12. Install center console. Refer to «FLOOR CONSOLE - REMOVAL AND INSTALLATION»(ref-311041-S21848229192009032300000) .
  13. Return gear selector to 'P'.
  14. Install 'J' gate surround. Refer to «SELECTOR LEVER CABLE AND BRACKET - REMOVAL AND INSTALLATION»(ref-311060-S32835138532009032300000) .
  15. Connect ground cable to battery terminal and install battery cover. Refer to «BATTERY CONNECT - GENERAL PROCEDURES»(ref-311034-S33760101132009032300000) .

Scheme 2

Scheme 2: Removal
Scheme 2: Removal

Scheme 3

Scheme 3
Scheme 3

Scheme 4

Scheme 4
Scheme 4
  1. Remove battery cover and disconnect ground cable from battery terminal. Refer to «BATTERY GROUND CABLE - REMOVAL AND INSTALLATION»(ref-311034-S13267168892009032300000) .
  2. Remove RH side liner from trunk. Refer to «LUGGAGE COMPARTMENT SIDE TRIM PANEL - REMOVAL AND INSTALLATION»(ref-311064-S04102832332009032300000) .
  3. Disconnect amplifier harness multi-plugs.
  4. Disconnect CD auto changer data cable.
  5. Remove upper bolts securing amplifier mounting bracket to outer mounting bracket.
  6. Remove side bolts securing amplifier mounting bracket to outer mounting bracket.
  7. Withdraw amplifier/mounting bracket assembly from trunk and remove bolts securing amplifier to bracket.
  1. Position amplifier on mounting bracket and install securing bolts.
  2. Position amplifier/mounting bracket assembly in trunk.
  3. Install upper bolts securing amplifier mounting bracket to outer mounting bracket.
  4. Install side bolts securing amplifier mounting bracket to outer mounting bracket.
  5. Connect amplifier harness multi-plugs.
  6. Connect CD auto changer data cable.
  7. Install trunk RH liner .
  8. Connect ground cable to battery terminal and install battery cover. Refer to «BATTERY CONNECT - GENERAL PROCEDURES»(ref-311034-S33760101132009032300000) .

Removal

  1. Open the driver's door, or both doors if necessary, to allow the side windows to drop. Ensure that the doors remain open until after the battery has been disconnected.
  2. Disconnect the battery ground cable. Remove the battery cover.
  3. Raise the vehicle on a ramp.
  4. Disconnect the multi-plug from the mounting bracket clip. Disconnect the multi-plug. Remove the three bolts which secure the suppression module to the mounting bracket. Remove the suppression module.
  1. Connect the battery ground cable. Refit the battery cover.
  2. Reconnect the battery in accordance with 414-01.

Scheme 5

Scheme 5
Scheme 5
  1. Remove battery cover and disconnect ground cable from battery terminal. Refer to «BATTERY GROUND CABLE - REMOVAL AND INSTALLATION»(ref-311034-S13267168892009032300000) .
  2. Remove RH side liner from trunk. Refer to «LUGGAGE COMPARTMENT SIDE TRIM PANEL - REMOVAL AND INSTALLATION»(ref-311064-S04102832332009032300000) .
  3. Premium ICE only: Disconnect amplifier harness multi-plugs.
  4. Disconnect CD auto changer data cable.
  5. Remove upper bolts securing auto changer mounting bracket to outer mounting bracket.
  6. Remove side bolts securing auto changer mounting bracket to outer mounting bracket
  7. Withdraw auto changer/mounting bracket assembly from trunk and remove four bolts securing auto changer to bracket.
  1. Position auto changer on mounting bracket and fit and install securing bolts.
  2. Position auto changer/mounting bracket assembly in trunk.
  3. Install upper bolts securing auto changer mounting bracket to outer mounting bracket.
  4. Install side bolts securing auto changer mounting bracket to outer mounting bracket.
  5. Connect amplifier harness multi-plugs.
  6. Connect CD auto changer data cable
  7. Install trunk RH liner .
  8. Connect ground cable to battery terminal and install battery cover. Refer to «BATTERY CONNECT - GENERAL PROCEDURES»(ref-311034-S33760101132009032300000) .
