RIDE HEIGHT SPECIFICATIONS (XKR)
| Application | (2) Showroom - In. (mm) | (3) Curb - In. (mm) |
|---|
| Front | 15.20-16.38 (386-416) | 15.16-16.34 (385-415) |
| Rear | 15.75-16.93 (400-430) | 15.35-16.54 (390-420) |
| (1) Ride height is measured from the horizontal centerline of the wheel to the apex of the wheel opening. (Scheme 1) (2) Showroom specification is with all fluids levels full and approximately 2.5 gallons of fuel. (3) Curb specification is with all fluid levels full and fuel tank full. |
| (1) | Ride height is measured from the horizontal centerline of the wheel to the apex of the wheel opening. (Scheme 1) |
| (2) | Showroom specification is with all fluids levels full and approximately 2.5 gallons of fuel. |
| (3) | Curb specification is with all fluid levels full and fuel tank full. |
RIDE HEIGHT SPECIFICATIONS (XKR) (1)
Scheme 1
RIDE HEIGHT SPECIFICATIONS (XK8)
Before adjusting alignment or check riding height. Press down on front bumper to depress car, and slowly release. Bounce vehicle several times, and allow suspension to settle. Ensure tire inflation is correct.
| Application | (2) Showroom - In. (mm) | (3) Curb - In. (mm) |
|---|
| Front | 15.20-16.38 (386-416) | 15.16-16.34 (385-415) |
| Rear | 15.78-16.97 (401-431) | 15.35-16.54 (390-420) |
| (1) Ride height is measured from the horizontal centerline of the wheel to the apex of the wheel opening. (Scheme 1) (2) Showroom specification is with all fluids levels full and approximately 2.5 gallons of fuel. (3) Curb specification is with all fluid levels full and fuel tank full. |
| (1) | Ride height is measured from the horizontal centerline of the wheel to the apex of the wheel opening. (Scheme 1) |
| (2) | Showroom specification is with all fluids levels full and approximately 2.5 gallons of fuel. |
| (3) | Curb specification is with all fluid levels full and fuel tank full. |
RIDE HEIGHT SPECIFICATIONS (XK8) (1)
TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) |
|---|
| Camber Adjustment Cam Bolts | 83-113 (113-153) |
| Tie Rod End Lock Nut | 52-63(71-85) |
| Upper Control Arm Bolts | 72-97 (98-132) |
| Wheel Lug Nuts | 75 (102) |
WHEEL ALIGNMENT SPECIFICATIONS
| Application | (2) Minimum | (2) Maximum |
|---|
| Camber (Front) |
| Left | .1.18 | .18 |
| Right | 1.30 | .30 |
| Balance (3) | .83 | .57 |
| Camber (Rear) |
| Left | .90 | .10 |
| Right | .90 | .10 |
| Balance (3) | 1.00 | 1.00 |
| Caster (Front) |
| Left | 5.87 | 7.27 |
| Right | 6.64 | 8.04 |
| Balance (4) | .06 | 1.46 |
| Toe-In (Front) |
| Total | .08 | .42 |
| Toe-Out On Turns | (5) | (5) |
| Toe-In (Rear) |
| Left | .08 | .25 |
| Right | .08 | .25 |
| Total | .17 | .50 |
| Thrust Angle (6) | .08 | .08 |
| (1) All specification are with tires at normal inflation pressure and are showroom ride height specifications. For additional information, see RIDING HEIGHT ADJUSTMENT . (2) Measurement in degrees. (3) Camber balance equals right camber reading minus left camber reading. (4) Caster balance equals right caster reading minus left caster reading. (5) Information is not available from manufacturer. (6) Thrust angle equals right rear toe reading minus left rear toe reading. |
| (1) | All specification are with tires at normal inflation pressure and are showroom ride height specifications. For additional information, see RIDING HEIGHT ADJUSTMENT . |
| (2) | Measurement in degrees. |
| (3) | Camber balance equals right camber reading minus left camber reading. |
| (4) | Caster balance equals right caster reading minus left caster reading. |
| (5) | Information is not available from manufacturer. |
| (6) | Thrust angle equals right rear toe reading minus left rear toe reading. |
WHEEL ALIGNMENT SPECIFICATIONS (1)
