SPECIFICATIONS
| Application | Specification |
|---|
| Compressor Type | Nippondenso 10-Cyl. |
| Compressor Belt Tension | (1) |
| Compressor Oil Capacity | (2) 5.4-6.8 ozs. |
| Refrigerant (R-134a) Capacity | 21.2-24.7 ozs. |
| System Operating Pressures |
| High Side | (3) 152-192 psi |
| Low Side | (4) 34.4-39.9 psi |
| (1) Belt tension is automatically adjusted by belt tensioner. (2) Use PAG SP-20 refrigerant oil. (3) System high side operating pressure is dependent on ambient air temperature. Operating pressure is with ambient air temperature at 77°F (25°C). (4) System low side operating pressure is dependent on evaporator temperature. Operating pressure is with evaporator temperature at 37-41°F (2-3°C). |
| (1) | Belt tension is automatically adjusted by belt tensioner. |
| (2) | Use PAG SP-20 refrigerant oil. |
| (3) | System high side operating pressure is dependent on ambient air temperature. Operating pressure is with ambient air temperature at 77°F (25°C). |
| (4) | System low side operating pressure is dependent on evaporator temperature. Operating pressure is with evaporator temperature at 37-41°F (2-3°C). |
TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) |
|---|
| Compressor Mounting Bolt | 13-18 (18-24) |
| Power Steering Hose Nut | 16-21 (22-28) |
| Steering Column Mounting Bracket Bolt | 16-21 (22-28) |
| INCH Lbs. (N.m) |
| Compressor Line Bolt | 62-89 (7-10) |
| Evaporator Ling Bolt | 62-89 (7-10) |
| Heater/Evaporator Unit Mounting Nut | 44-62 (5-7) |
| Receiver-Drier Line Bolt | 62-89 (7-10) |
Automatic A/C-Heater System Wiring Diagram (2000-01 XKR & XK8 - 1 Of 3). Scheme 1
Scheme 1: Automatic A/C-Heater System Wiring Diagram (2000-01 XKR & XK8 - 1 Of 3)
Automatic A/C-Heater System Wiring Diagram (2000-01 XKR & XK8 - 2 Of 3). Scheme 2
Scheme 2: Automatic A/C-Heater System Wiring Diagram (2000-01 XKR & XK8 - 2 Of 3)
Automatic A/C-Heater System Wiring Diagram (2000-01 XKR & XK8 - 3 Of 3). Scheme 3
Scheme 3: Automatic A/C-Heater System Wiring Diagram (2000-01 XKR & XK8 - 3 Of 3)
