Automatic Transmission/transaxle: Removal & Installation Jaguar XJ X351

REMOVAL

Note. Removal steps in this procedure may contain installation details.

All vehicles

Scheme 4

Scheme 5

1. Refer to «Battery Disconnect and Connect»(ref-570102-S06137827622013080600000) information.
2. Raise and support the vehicle.
3. Refer to «Transmission - 3.0L V6 - TdV6»(ref-570091-S01044122382013080600000) . .
4. Refer to «Transmission - 3.0L NA V6 - AJ27»(ref-570091-S01044122382013080600000) . .
5. Refer to «Transmission - 5.0L NA V8 - AJ133/5.0L SC V8 - AJ133»(ref-570091-S01044122382013080600000) . .
6. Holding Pins, Torque Converter (307-613)
7. Slide Hammer (100-012) Slide Hammer Adaptor (100-012-01) Remover, Input and Output Seal (308-375)

INSTALLATION

All vehicles

Scheme 6

Scheme 7

Scheme 8

1. Installer, Front Seal (308-246)
2. Holding Pins, Torque Converter (307-613)
3. Refer to «Transmission - 5.0L NA V8 - AJ133/5.0L SC V8 - AJ133»(ref-570091-S01044122382013080600000) . .
4. Refer to «Transmission - 3.0L NA V6 - AJ27»(ref-570091-S01044122382013080600000) . .
5. Refer to «Transmission - 3.0L V6 - TdV6»(ref-570091-S01044122382013080600000) . .
6. Refer to «Battery Disconnect and Connect»(ref-570102-S06137827622013080600000) information.

All vehicles

Scheme 9

Scheme 10

1. Refer to «Battery Disconnect and Connect»(ref-570102-S06137827622013080600000) information.
2. Raise and support the vehicle.
3. Refer to «Driveshaft - 3.0L V6 - TdV6»(ref-570159) information.
4. Refer to «Transmission Support Insulator - 3.0L V6 - TdV6»(ref-570091-S19534338232013080600000) .
5. Refer to «Driveshaft - 3.0L NA V6 - AJ27/5.0L NA V8 - AJ133/5.0L SC V8 - AJ133»(ref-570159-S37907939572013080600000) information.
6. Refer to «Transmission Support Insulator - 5.0L NA V8 - AJ133/5.0L SC V8 - AJ133»(ref-570091-S15064122532013080600000) .
7. Retainer, Drive Flange (205-053)
8. Puller, General Purpose (303-D121)
9. Slide Hammer (100-012) Slide Hammer Adaptor (100-012-01) Remover, Input and Output Seal (308-375)

All vehicles

Scheme 11

1. Pinion Seal Replacer (204-264)
2. Torque: 60 Nm
3. Refer to «Transmission Support Insulator - 5.0L NA V8 - AJ133/5.0L SC V8 - AJ133»(ref-570091-S15064122532013080600000) .
4. Refer to «Driveshaft - 3.0L NA V6 - AJ27/5.0L NA V8 - AJ133/5.0L SC V8 - AJ133»(ref-570159-S37907939572013080600000) information.
5. Refer to «Transmission Support Insulator - 3.0L V6 - TdV6»(ref-570091-S19534338232013080600000) .
6. Refer to «Driveshaft - 3.0L V6 - TdV6»(ref-570159) information.
7. Refer to «Battery Disconnect and Connect»(ref-570102-S06137827622013080600000) information.

Note. The transmission control module (TCM) is part of the main control valve body and cannot be serviced separately.

Scheme 12

Scheme 13

Scheme 14

1. Refer to «Battery Disconnect and Connect»(ref-570102-S06137827622013080600000) information.
2. Raise and support the vehicle.
3. Refer to «Transmission Fluid Pan, Gasket and Filter»(ref-570091-S28281820112013080600000) .

Scheme 15

1. Install a new seal block.
2. Torque: 8 Nm
3. Refer to «Transmission Fluid Pan, Gasket and Filter»(ref-570091-S28281820112013080600000) .
4. Refer to «Battery Disconnect and Connect»(ref-570102-S06137827622013080600000) information.
5. If a new component has been installed, configure using Jaguar approved diagnostic equipment.

Note. Removal steps in this procedure may contain installation details.

Scheme 16

Scheme 17

1. Refer to «Battery Disconnect and Connect»(ref-570102-S06137827622013080600000) information.
2. Raise and support the vehicle.
3. Refer to «Transmission Fluid Drain and Refill»(ref-570091-S26893128262013080600000) .
4. Torque: 8 Nm

1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

Note. Some variation in the illustrations may occur, but the essential information is always correct.

Scheme 18

1. Raise and support the vehicle.
2. Torque: 48 Nm
3. Torque: 70 Nm

1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

Note. Some variation in the illustrations may occur, but the essential information is always correct.

Scheme 19

Scheme 20

1. Raise and support the vehicle.
2. Torque: 10 Nm
3. Torque: 48 Nm
4. Torque: 70 Nm

1. To install, reverse the removal procedure.

Note. Some variation in the illustrations may occur, but the essential information is always correct.

Note. Some illustrations may show the transmission removed for clarity.

Scheme 21

Scheme 22

Scheme 23

Scheme 24

Scheme 25

Scheme 26

Scheme 27

Scheme 28

Scheme 29

Scheme 30

Scheme 31

Scheme 32

Scheme 33

Scheme 34

Scheme 35

Scheme 36

Scheme 37

Scheme 38

Scheme 39

Scheme 40

1. Refer to «Battery Disconnect and Connect»(ref-570102-S06137827622013080600000) information.
2. Raise and support the vehicle.
3. Refer to «Exhaust System»(ref-570143-S28185596992013080600000) information.
4. Make sure that the alignment mark is visible through the inspection hole on removal of the last torque converter bolt.
5. Align the powertrain assembly jack to the transmission.
6. Lower the rear of the transmission for access.
7. Install the torque converter retainer.

Scheme 41

Scheme 42

Scheme 43

1. Torque: 5 Nm
2. Raise the powertrain assembly jack and transmission assembly.
3. Torque: 48 Nm
4. Torque: 48 Nm
5. Torque: 48 Nm
6. Torque: 45 Nm
7. Remove the transmission jack.
8. Torque: 127 Nm
9. Torque: 63 Nm
10. Torque: 10 Nm
11. Torque: 10 Nm
12. Refer to «Exhaust System»(ref-570143-S28185596992013080600000) information.
13. Refer to «Battery Disconnect and Connect»(ref-570102-S06137827622013080600000) information.
14. Check and top up the cooling system as required.
15. Set the heater controls to HOT.
16. Start the engine and allow to idle until hot air is emitted at the face registers.
17. Raise the engine speed to 2000 RPM and maintain at 2000 RPM until the engine cooling fan operates.
18. Switch the engine off and allow to cool.
19. Visually check the engine and cooling system for signs of coolant leakage.
20. Check and top-up the coolant if required.
21. Refer to «Transmission Fluid Level Check»(ref-570091-S01044122382013080600000) . .

Note. Some variation in the illustrations may occur, but the essential information is always correct.

Note. Some illustrations may show the transmission removed for clarity.

1. Refer to «Battery Disconnect and Connect»(ref-570102-S06137827622013080600000) information.
2. Raise and support the vehicle.
3. Refer to «Exhaust System»(ref-570143-S28185596992013080600000) information.
4. Make sure that the alignment mark is visible through the inspection hole on removal of the last torque converter bolt.
5. Align the powertrain assembly jack to the transmission.
6. Lower the rear of the transmission for access.
7. Install the torque converter retainer.

1. Torque: 5 Nm
2. Raise the powertrain assembly jack and transmission assembly.
3. Torque: 48 Nm
4. Torque: 48 Nm
5. Torque: 48 Nm
6. Torque: 45 Nm
7. Remove the transmission jack.
8. Torque: 127 Nm
9. Torque: 63 Nm
10. Torque: 10 Nm
11. Torque: 10 Nm
12. Refer to «Exhaust System»(ref-570143-S28185596992013080600000) information.
13. Refer to «Battery Disconnect and Connect»(ref-570102-S06137827622013080600000) information.
14. Check and top up the cooling system as required.
15. Set the heater controls to HOT.
16. Start the engine and allow to idle until hot air is emitted at the face registers.
17. Raise the engine speed to 2000 RPM and maintain at 2000 RPM until the engine cooling fan operates.
18. Switch the engine off and allow to cool.
19. Visually check the engine and cooling system for signs of coolant leakage.
20. Check and top-up the coolant if required.
21. Refer to «Transmission Fluid Level Check»(ref-570091-S01044122382013080600000) . .
