ADJUSTMENT
| WARNING | Observe due care when draining, as the fluid can be very hot. |
| WARNING | Observe due care when working near a hot exhaust system. |
Note. Some variation in the illustrations may occur, but the essential information is always correct.
Scheme 1
Scheme 2
Scheme 3
- If the transmission fluid does not come out of the transmission fluid fill plug hole the transmission fluid level is insufficient. If this is the case add the transmission fluid in 0.5 liter units into the transmission fluid fill plug hole until fluid comes out.
- Allow the transmission fluid to drain from the transmission fluid filler plug hole until the flow almost stops.
- Using the special tool, install the new transmission fluid fill plug.
- To make sure the transmission fill plug is torqued to the correct specification. Using the special tool and torque wrench the following calculation steps must be followed. Step 1. Multiply 35 Nm by the effective length of the torque wrench (1). Step 2. Add the effective length of the special tool (2) to the effective length of the torque wrench (1). Step 3. Divide the total of step 1 by the total of step 2. Step 4. Set the torque wrench to the figure arrived at in step 3. Tighten the transmission fluid fill plug to the torque given by the calculation.
- Remove the special tool.
- Remove the container.
- Refer to «Air Deflector»(ref-570100-S33802335332013080600000) information.
- Lower the vehicle.
- Disconnect the diagnostic tool.
