Seating: Removal & Installation Jaguar XF I

Seats 64 illustrations ~1241 words

INSTALLATION

  1. To install, reverse the removal procedure. TORQUE: 47 Nm
  2. TORQUE: 47 Nm
  3. TORQUE: 40 Nm

REMOVAL

  1. Make the air bag supplemental restraint system (SRS) safe. Refer to «Standard Workshop Practices»(ref-568389-S00771621212013072200000) information.
  2. Disconnect the battery ground cable. Refer to «Battery Disconnect and Connect»(ref-568400-S03532047432013072200000) information.
  3. Remove the front seat. See «Front Seat»(ref-568428-S22610106892013072200000) .
  4. Remove the front seat backrest assembly.
  5. Remove the front seat backrest cover. See «Front Seat Backrest Cover»(ref-568428-S09969820552013072200000) .
  6. Remove the backrest halo panel. Release the 5 wiring harness clips.
  7. Remove the front seat recliner motor. See «Front Seat Recliner Motor»(ref-568428-S36675464242013072200000) . .
  8. Remove the lumbar assembly. See «Lumbar Assembly»(ref-568428-S09282171672013072200000) .
  9. Remove the front seat head restraint motor. See «Front Seat Head Restraint Motor»(ref-568428-S15518103782013072200000) .

Scheme 8

Scheme 8: INSTALLATION
Scheme 8: INSTALLATION
  1. To install, reverse the removal procedure. TORQUE: 35 Nm
  2. If a new component has been installed, configure using Jaguar approved diagnostic equipment.

Scheme 9

Scheme 9: REMOVAL
Scheme 9: REMOVAL

Scheme 10

Scheme 10
Scheme 10

Scheme 11

Scheme 11
Scheme 11

Scheme 12

Scheme 12
Scheme 12

Scheme 13

Scheme 13
Scheme 13

Scheme 14

Scheme 14
Scheme 14

Scheme 15

Scheme 15
Scheme 15
  1. Make the air bag supplemental restraint system (SRS) safe. Refer to «Standard Workshop Practices»(ref-568389-S00771621212013072200000) information.
  2. Remove the front seat. See «Front Seat»(ref-568428-S22610106892013072200000) .
  3. Remove the side air bag module. Refer to «SIDE AIR BAG MODULE»(ref-568426-S11313686382013080700000) information.
  4. Reposition the front seat backrest thermo-electric device.
  5. Release the front seat backrest thermo-electric device duct
  6. Remove the front seat backrest thermo-electric device retaining screws.
  7. Remove the front seat backrest thermo-electric device. Disconnect the electrical connector.
  8. Remove the front seat head restraint.
  9. Remove the front seat head restraint motor. See «Front Seat Head Restraint Motor»(ref-568428-S15518103782013072200000) .
  10. Using a suitable tool, remove the front seat head restraint guide sleeves.
  11. Remove the front seat backrest cushion and cover from the front seat frame.
  12. Remove and discard the hog rings. Remove the 22 hog rings.
  13. Remove the front seat backrest cover.
  1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

Note. Some variation in the illustrations may occur, but the essential information is always correct.

Scheme 16

Scheme 16: REMOVAL
Scheme 16: REMOVAL

Scheme 17

Scheme 17
Scheme 17
  1. Refer to: «BATTERY DISCONNECT AND CONNECT»(ref-568400-S03532047432013072200000) .
  2. Refer to: «FRONT SEAT BACKREST COVER»(ref-568428-S09969820552013072200000) .
  3. See figure.
  4. See figure.
  1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

Note. Some variation in the illustrations may occur, but the essential information is always correct.

Scheme 18

Scheme 18: REMOVAL
Scheme 18: REMOVAL
  1. Refer to: «BATTERY DISCONNECT AND CONNECT»(ref-568400-S03532047432013072200000) .
  2. Refer to: «FRONT SEAT BACKREST COVER»(ref-568428-S09969820552013072200000) .
  3. See figure.
  1. To install, reverse the removal procedure.

Scheme 19

Scheme 19: REMOVAL
Scheme 19: REMOVAL

Scheme 20

Scheme 20
Scheme 20

Scheme 21

Scheme 21
Scheme 21

Scheme 22

Scheme 22
Scheme 22

Scheme 23

Scheme 23
Scheme 23

Scheme 24

Scheme 24
Scheme 24

Scheme 25

Scheme 25
Scheme 25

Scheme 26

Scheme 26
Scheme 26

Scheme 27

Scheme 27
Scheme 27

Scheme 28

Scheme 28
Scheme 28

Scheme 29

Scheme 29
Scheme 29
  1. Refer to «Front Safety Belt Buckle»(ref-568483-S27771834092013072200000) information.
  2. See figure.
  3. See figure.
  4. See figure.
  5. See figure.
  6. See figure.
  7. Torque: 35 Nm.
  8. See figure.
  9. See figure.
  10. See figure.
  11. See figure.
  12. See figure.
  13. See figure.
  1. To install, reverse the removal procedure.
  2. If a new component has been installed, configure using Jaguar approved diagnostic equipment.

Scheme 30

Scheme 30: REMOVAL
Scheme 30: REMOVAL

Scheme 31

Scheme 31
Scheme 31

Scheme 32

Scheme 32
Scheme 32
  1. Make the air bag supplemental restraint system (SRS) safe. Refer to «Standard Workshop Practices»(ref-568389-S00771621212013072200000) information.
  2. Remove the front seat. See «Front Seat»(ref-568428-S22610106892013072200000) .
  3. See figure.
  4. See figure.
  5. See figure.
  6. See figure.
  1. To install, reverse the removal procedure.
  2. If a new component has been installed, configure using Jaguar approved diagnostic equipment.

Scheme 33

Scheme 33: REMOVAL
Scheme 33: REMOVAL

Scheme 34

Scheme 34
Scheme 34
  1. Make the air bag supplemental restraint system (SRS) safe. Refer to «Standard Workshop Practices»(ref-568389-S00771621212013072200000) information.
  2. See «Front Seat Backrest Cover»(ref-568428-S09969820552013072200000) .
  3. See figure.
  4. See figure.
  1. To install, reverse the removal procedure.
  2. If a new component has been installed, configure using Jaguar approved diagnostic equipment.

Scheme 35

Scheme 35: REMOVAL
Scheme 35: REMOVAL
  1. Refer to «Front Door Trim Panel»(ref-568405) information.
  2. See figure.
  1. To install, reverse the removal procedure.
WARNINGTo avoid accidental deployment, the restraints control module backup power supply must be depleted. Wait at least one minute after disconnecting the battery ground cable(s) before commencing any repair or adjustment to the supplemental restraint system (SRS), or any component(s) adjacent to the SRS sensors. Failure to follow these instructions may result in personal injury.
WARNINGAlways wear safety glasses when working on an air bag equipped vehicle and when handling an air bag module. Failure to follow this instruction may result in personal injury.
WARNINGTo minimize the possibility of premature deployment, do not use radio key code savers when working on the supplemental restraint system. Failure to follow this instruction may result in personal injury.
WARNINGTo minimize the possibility of injury in the event of premature deployment, always carry a live air bag module with the bag and trim cover pointed away from the body. Failure to follow this instruction may result in personal injury.
WARNINGTo minimize the possibility of premature deployment, live air bag modules must only be placed on work benches which have been ground bonded and with the trim cover facing up. Failure to follow these instructions may result in personal injury.
WARNINGNever probe the electrical connectors of air bag modules or any other supplemental restraint system component. Failure to follow this instruction may result in personal injury.
WARNINGPainting over the driver air bag module trim cover or instrument panel could lead to deterioration of the trim cover and air bags. Do not for any reason attempt to paint discolored or damaged air bag module trim covers or instrument panel. Install a new component. Failure to follow this instruction may result in personal injury.

Note. Some variation in the illustrations may occur, but the essential information is always correct.

Note. Removal steps in this procedure may contain installation details.

Scheme 36

Scheme 36
Scheme 36

Scheme 37

Scheme 37
Scheme 37

Scheme 38

Scheme 38
Scheme 38

Scheme 39

Scheme 39
Scheme 39
  1. Make the air bag supplemental restraint system (SRS) safe. Refer to «Standard Workshop Practices»(ref-568389-S00771621212013072200000) information.
  2. See «Front Seat»(ref-568428-S22610106892013072200000) .
  3. Refer to «Front Safety Belt Buckle»(ref-568483-S27771834092013072200000) information.
  4. See «Front Seat Cushion Cover»(ref-568428-S41929751252013072200000) .
  5. See figure.
  6. See figure.
  7. See figure.
  8. Torque: 35 Nm.
  1. To install, reverse the removal procedure.

Scheme 40

Scheme 40: REMOVAL
Scheme 40: REMOVAL

Scheme 41

Scheme 41
Scheme 41

Scheme 42

Scheme 42
Scheme 42

Scheme 43

Scheme 43
Scheme 43

Scheme 44

Scheme 44
Scheme 44

Scheme 45

Scheme 45
Scheme 45

Scheme 46

Scheme 46
Scheme 46
  1. Remove the rear seat cushion. See «Rear Seat Cushion»(ref-568428-S13803481932013072200000) .
  2. Release both the rear seat back rest catches.
  3. Fold down the rear seat backrest.
  4. Remove the rear seat head restraint(s). Lower both rear seats.
  5. Remove both rear seat bolsters.
  6. With assistance, remove the rear seat backrest. Both rear seat backrests need to be in an upright position but not latched for access to retaining bolts.
  7. Release the backrest cover. Release all 4 sides.
  8. Remove the rear seat backrest hinge(s).
  9. Remove the rear armrest retaining screw covers.
  10. Remove the rear armrest retaining screws. Remove the 2 Torx screws.
  11. Remove the rear seat armrest.
  12. Release the rear seat backrest cover from the armrest aperture. Release the 3 plastic retaining strips from the securing clips.
  13. Remove the cappings from the rear head restraint retaining posts. Release the rear backrest cover over the head restraint posts.
  14. Remove the rear seat backrest cushion and cover from the rear seat backrest.
  15. Remove and discard the hog rings. Remove the 36 hog rings securing the rear 60% seat backrest cover to the backrest seat cushion. Remove the 26 hog rings securing the rear 40% seat backrest cover to the backrest seat cushion.
  16. Remove the rear seat backrest cover.
  1. To install, reverse the removal procedure.

Scheme 47

Scheme 47: REMOVAL
Scheme 47: REMOVAL

Scheme 48

Scheme 48
Scheme 48
  1. Detach the rear seat cushion. Release the rear seat cushion retaining clips. Detach the rear seat cushion.
  2. Remove the rear seat cushion. Guide the safety belt buckles through the rear seat cushion aperture. Remove the rear seat cushion.
  1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

Scheme 49

Scheme 49
Scheme 49

Scheme 50

Scheme 50
Scheme 50

Scheme 51

Scheme 51
Scheme 51

Scheme 52

Scheme 52
Scheme 52
  1. Make the air bag supplemental restraint system (SRS) safe. Refer to «Standard Workshop Practices»(ref-568389-S00771621212013072200000) information.
  2. Disconnect the battery ground cable. Refer to «Battery Disconnect and Connect»(ref-568400-S03532047432013072200000) information.
  3. Remove the front seat. See «Front Seat»(ref-568428-S22610106892013072200000) .
  4. See figure.
  5. See figure.
  6. See figure.
  7. See figure.
  8. See figure.
  9. Torque: 35 Nm.
  10. Torque: 35
  11. See figure.
  12. See figure.
  1. To install, reverse the removal procedure.
  2. If a new component has been installed, configure using Jaguar approved diagnostic equipment.

Scheme 53

Scheme 53: REMOVAL
Scheme 53: REMOVAL

Scheme 54

Scheme 54
Scheme 54

Scheme 55

Scheme 55
Scheme 55

Scheme 56

Scheme 56
Scheme 56
  1. See «Front Seat»(ref-568428-S22610106892013072200000) .
  2. See figure.
  3. See figure.
  4. Remove and discard the retaining clips.
  5. See figure.

Scheme 57

Scheme 57
Scheme 57

Scheme 58

Scheme 58
Scheme 58
  1. See figure.
  2. Install new clips.
  3. See figure.
  4. See figure.
  5. See figure.
  6. See figure.
  7. See «Front Seat»(ref-568428-S22610106892013072200000) .

Scheme 59

Scheme 59
Scheme 59

Scheme 60

Scheme 60
Scheme 60

Scheme 61

Scheme 61
Scheme 61
  1. See «Front Seat»(ref-568428-S22610106892013072200000) .
  2. See figure.
  3. See figure.
  4. See figure.
  5. See figure.
  6. See figure.

Scheme 62

Scheme 62: INSTALLATION
Scheme 62: INSTALLATION

Scheme 63

Scheme 63
Scheme 63

Scheme 64

Scheme 64
Scheme 64
  1. Install new clips.
  2. Install the front seat back rest cover trim panel.
  3. See figure.
  4. See figure.
  5. See figure.
  6. See figure.
  7. See «Front Seat»(ref-568428-S22610106892013072200000) .

Scheme 65

Scheme 65
Scheme 65

Scheme 66

Scheme 66
Scheme 66

Scheme 67

Scheme 67
Scheme 67

Scheme 68

Scheme 68
Scheme 68
  1. Refer to «Standard Workshop Practices»(ref-568389-S00771621212013072200000) information.
  2. Refer to «Battery Disconnect and Connect»(ref-568400-S03532047432013072200000) information.
  3. See «Front Seat»(ref-568428-S22610106892013072200000) .
  4. Refer to «Front Safety Belt Buckle»(ref-568483-S27771834092013072200000) information.
  5. See figure.
  6. See figure.
  7. See figure.
  8. See figure.
  9. Remove and discard the retaining clips.
  10. See figure.
  11. See figure.
  12. See figure.
  13. See figure.

Scheme 69

Scheme 69: INSTALLATION
Scheme 69: INSTALLATION

Scheme 70

Scheme 70
Scheme 70

Scheme 71

Scheme 71
Scheme 71
  1. See figure.
  2. See figure.
  3. See figure.
  4. Install new clips.
  5. Install the front seat backrest cover.
  6. See figure.
  7. See figure.
  8. See figure.
  9. See figure.
  10. Refer to «Front Safety Belt Buckle»(ref-568483-S27771834092013072200000) information.
  11. See «Front Seat»(ref-568428-S22610106892013072200000) .
  12. Refer to «Battery Disconnect and Connect»(ref-568400-S03532047432013072200000) information.
  1. See figure.
  2. See figure.
  3. See figure.
  1. To install, reverse the removal procedure.
