Electronic Engine Controls (V8 5.0L Petrol): Removal & Installation Jaguar XF I

Engine Control Systems 31 illustrations ~977 words

REMOVAL

Note. Removal steps in this procedure may contain installation details.

Scheme 50

Scheme 50: REMOVAL
  1. Disconnect the battery ground cable. Refer to «Specifications»(ref-568476) information.
  2. Raise and support the vehicle.
  3. Refer to: «Thermostat Housing»(ref-568454-S17061061482013072200000)
  4. Torque: 10 Nm

INSTALLATION

  1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

Scheme 51

Scheme 51: REMOVAL
  1. Disconnect the battery ground cable. Refer to «Specifications»(ref-568476) information.
  2. Raise and support the vehicle.
  3. Refer to: «Thermostat Housing»(ref-568454-S17061061482013072200000)
  4. Torque: 10 Nm
  1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

Scheme 52

Scheme 52: REMOVAL

Scheme 53

Scheme 53
  1. Refer to «Battery Disconnect and Connect»(ref-568400-S03532047432013072200000) information.
  2. Raise and support the vehicle.
  3. Refer to «Air Deflector»(ref-568406-S42840487662013072200000) information.
  4. Torque: 48 Nm
  1. To install, reverse the removal procedure.
  2. If required, carry out a long drive cycle. Refer to «Powertrain Control Module (PCM) Long Drive Cycle Self-Test»(ref-568420-S37791637132013072200000) information.

Note. Removal steps in this procedure may contain installation details.

Scheme 54

Scheme 54: REMOVAL

Scheme 55

Scheme 55
  1. Refer to «Battery Disconnect and Connect»(ref-568400-S03532047432013072200000) information.
  2. Raise and support the vehicle.
  3. Refer to «Air Deflector»(ref-568406-S42840487662013072200000) information.
  4. Torque: 48 Nm
  1. To install, reverse the removal procedure.
  2. If required, carry out a long drive cycle. Refer to «Powertrain Control Module (PCM) Long Drive Cycle Self-Test»(ref-568420-S37791637132013072200000) information.

Note. Removal steps in this procedure may contain installation details.

Scheme 56

Scheme 56: REMOVAL
  1. Raise and support the vehicle.
  2. Refer to «Air Deflector»(ref-568406-S42840487662013072200000) information.
  3. Torque: 10 Nm
  1. To install, reverse the removal procedure.

Note. Some variation in the illustrations may occur, but the essential information is always correct.

Scheme 57

Scheme 57: REMOVAL

Scheme 58

Scheme 58

Scheme 59

Scheme 59

Scheme 60

Scheme 60

Scheme 61

Scheme 61

Scheme 62

Scheme 62
  1. Refer to «Battery Disconnect and Connect»(ref-568400-S03532047432013072200000) information.
  2. Refer to «Cowl Vent Screen»(ref-568406-S32289223332013072200000) information.
  3. Refer to «Secondary Bulkhead Panel LH - 5.0L/3.0L Diesel»(ref-568406-S25565044692013072200000) information.
  4. Torque: 25 Nm
  5. Torque: 25 Nm
  6. Torque: 8 Nm
  7. Torque: 6 Nm
  8. Torque: 10 Nm
  1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

Scheme 63

Scheme 63: REMOVAL
  1. Raise and support the vehicle.
  2. Refer to «Engine Cover - 5.0L, Vehicles Without: Supercharger»(ref-568405-S41842828132013072200000) information.
  3. Refer to «Cooling System Draining and Vacuum Filling - Vehicles Without: Supercharger»(ref-568464) information.
  4. Refer to «Secondary Bulkhead Center Panel»(ref-568406-S23451519502013072200000) information.
  5. Lift the tang and rotate the engine coolant temperature (ECT) sensor counter-clockwise.
  1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

Scheme 64

Scheme 64: REMOVAL
  1. Raise and support the vehicle.
  2. Refer to «Air Deflector»(ref-568406-S42840487662013072200000) information.
  3. Refer to «Engine Oil Draining and Filling»(ref-568453) information.
  4. Torque: 11 Nm
  1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

Scheme 65

Scheme 65: REMOVAL
  1. Refer to «Battery Disconnect and Connect»(ref-568400-S03532047432013072200000) information.
  2. Refer to «Intake Manifold»(ref-568451-S33136023632013072200000) information.
  3. Torque: 20 Nm
  1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

Scheme 66

Scheme 66: REMOVAL
  1. Refer to «Battery Disconnect and Connect»(ref-568400-S03532047432013072200000) information.
  2. Refer to «Intake Manifold»(ref-568451-S33136023632013072200000) information.
  3. Torque: 20 Nm
  1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

Scheme 67

Scheme 67: REMOVAL
  1. Refer to «Fuel System Pressure Release - 5.0L»(ref-568404) information.
  2. Disconnect the battery ground cable. Refer to «Battery Disconnect and Connect»(ref-568400-S03532047432013072200000) information.
  3. Refer to «Cowl Vent Screen»(ref-568406-S32289223332013072200000) information.
  4. Refer to «Secondary Bulkhead Panel RH - 5.0L/3.0L Diesel»(ref-568406-S22586568902013072200000) information.
  5. Refer to «Secondary Bulkhead Panel LH - 5.0L/3.0L Diesel»(ref-568406-S25565044692013072200000) information.
  6. Refer to «Secondary Bulkhead Center Panel»(ref-568406-S23451519502013072200000) information.
  7. Refer to «Engine Cover - 5.0L, Vehicles Without: Supercharger»(ref-568405-S41842828132013072200000) information.
  8. Torque: 32 Nm
  1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

Scheme 68

Scheme 68: REMOVAL

Scheme 69

Scheme 69
  1. Refer to «Battery Disconnect and Connect»(ref-568400-S03532047432013072200000) information.
  2. Raise and support the vehicle.
  3. Refer to «Air Deflector»(ref-568406-S42840487662013072200000) information.
  4. Refer to «Catalytic Converter LH»(ref-568457-S11704519152013072200000) information.
  5. Wrench, H02S (310-121) Torque: 48
  1. To install, reverse the removal procedure.
  2. If required, carry out a long drive cycle. Refer to «Powertrain Control Module (PCM) Long Drive Cycle Self-Test»(ref-568420-S37791637132013072200000) information.

Note. Removal steps in this procedure may contain installation details.

Scheme 70

Scheme 70: REMOVAL

Scheme 71

Scheme 71
  1. Refer to «Battery Disconnect and Connect»(ref-568400-S03532047432013072200000) information.
  2. Raise and support the vehicle.
  3. Refer to «Air Deflector»(ref-568406-S42840487662013072200000) information.
  4. Refer to «Catalytic Converter RH»(ref-568457-S03385691802013072200000) information.
  5. Wrench, H02S (310-121) Torque: 48
  1. To install, reverse the removal procedure.
  2. If required, carry out a long drive cycle. Refer to «Powertrain Control Module (PCM) Long Drive Cycle Self-Test»(ref-568420-S37791637132013072200000) information.

Note. Removal steps in this procedure may contain installation details.

Scheme 72

Scheme 72: REMOVAL
  1. Refer to «Engine Cover - 5.0L»(ref-568405-S41842828132013072200000) information.
  2. Torque: 5 Nm
  1. To install, reverse the removal procedure.
  2. If required, carry out a short drive cycle. Refer to «Powertrain Control Module (PCM) Short Drive Cycle Self-Test»(ref-568420-S05827087332013072200000) information.

Note. Removal steps in this procedure may contain installation details.

Scheme 73

Scheme 73: REMOVAL
  1. Refer to «Battery Disconnect and Connect»(ref-568400-S03532047432013072200000) information.
  1. To install, reverse the removal procedure.
  2. If required, carry out a short drive cycle. Refer to «Powertrain Control Module (PCM) Short Drive Cycle Self-Test»(ref-568420-S05827087332013072200000) information.

Note. Removal steps in this procedure may contain installation details.

Scheme 74

Scheme 74: REMOVAL
  1. Refer to «Battery Disconnect and Connect»(ref-568400-S03532047432013072200000) information.
  2. Refer to «Intake Manifold»(ref-568451-S33136023632013072200000) information.
  3. Torque: 20 Nm
  1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

Scheme 75

Scheme 75: REMOVAL
  1. Refer to «Battery Disconnect and Connect»(ref-568400-S03532047432013072200000) information.
  2. Refer to «Intake Manifold»(ref-568451-S33136023632013072200000) information.
  3. Torque: 20 Nm
  1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

Scheme 76

Scheme 76: REMOVAL

Scheme 77

Scheme 77
  1. Disconnect the battery ground cable. Refer to «Specifications»(ref-568476) information.
  2. Raise and support the vehicle.
  3. Refer to: «Thermostat Housing»(ref-568454-S17061061482013072200000)
  4. Torque: 10 Nm
  1. To install, reverse the removal procedure.
  2. If required, carry out a short drive cycle. Refer to «Powertrain Control Module (PCM) Short Drive Cycle Self-Test»(ref-568420-S05827087332013072200000) information.

Note. Removal steps in this procedure may contain installation details.

Scheme 78

Scheme 78: REMOVAL

Scheme 79

Scheme 79

Scheme 80

Scheme 80
  1. Disconnect the battery ground cable. Refer to «Specifications»(ref-568476) information.
  2. Raise and support the vehicle.
  3. Refer to: «Thermostat Housing»(ref-568454-S17061061482013072200000)
  4. Torque: 10 Nm
  1. To install, reverse the removal procedure.
  2. If required, carry out a short drive cycle. Refer to «Powertrain Control Module (PCM) Short Drive Cycle Self-Test»(ref-568420-S05827087332013072200000) information.
