Electronic Engine Controls (V8 S/c 5.0L Petrol): Removal & Installation Jaguar XF I

Engine Control Systems 35 illustrations ~1027 words

REMOVAL

Note. Removal steps in this procedure may contain installation details.

Scheme 89

Scheme 89: REMOVAL
Scheme 89: REMOVAL
  1. Disconnect the battery ground cable. Refer to «Specifications»(ref-568476) information.
  2. Raise and support the vehicle.
  3. Thermostat Housing Refer to: «Thermostat Housing V8 S/C 5.0L Petrol»(ref-568454-S07823677632013072200000)
  4. Torque: 10 Nm

INSTALLATION

  1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

Scheme 90

Scheme 90: REMOVAL
Scheme 90: REMOVAL
  1. Disconnect the battery ground cable. Refer to «Specifications»(ref-568476) information.
  2. Raise and support the vehicle.
  3. Thermostat Housing Refer to: «Thermostat Housing V8 S/C 5.0L Petrol»(ref-568454-S07823677632013072200000)
  4. Torque: 10 Nm
  1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

Scheme 91

Scheme 91: REMOVAL
Scheme 91: REMOVAL

Scheme 92

Scheme 92
Scheme 92
  1. Refer to «Battery Disconnect and Connect»(ref-568400-S03532047432013072200000) information.
  2. Raise and support the vehicle.
  3. Refer to «Air Deflector»(ref-568406-S42840487662013072200000) information.
  4. Torque: 48 Nm
  1. To install, reverse the removal procedure.
  2. If required, carry out a long drive cycle. Refer to «Powertrain Control Module (PCM) Long Drive Cycle Self-Test»(ref-568420-S37791637132013072200000) information.

Note. Removal steps in this procedure may contain installation details.

Scheme 93

Scheme 93: REMOVAL
Scheme 93: REMOVAL

Scheme 94

Scheme 94
Scheme 94
  1. Refer to «Battery Disconnect and Connect»(ref-568400-S03532047432013072200000) information.
  2. Raise and support the vehicle.
  3. Refer to «Air Deflector»(ref-568406-S42840487662013072200000) information.
  4. Torque: 48 Nm
  1. To install, reverse the removal procedure.
  2. If required, carry out a long drive cycle. Refer to «Powertrain Control Module (PCM) Long Drive Cycle Self-Test»(ref-568420-S37791637132013072200000) information.

Note. Removal steps in this procedure may contain installation details.

Scheme 95

Scheme 95: REMOVAL
Scheme 95: REMOVAL
  1. Raise and support the vehicle.
  2. Refer to «Air Deflector»(ref-568406-S42840487662013072200000) information.
  3. Torque: 10 Nm
  1. To install, reverse the removal procedure.

Note. Some variation in the illustrations may occur, but the essential information is always correct.

Scheme 96

Scheme 96: REMOVAL
Scheme 96: REMOVAL

Scheme 97

Scheme 97
Scheme 97

Scheme 98

Scheme 98
Scheme 98

Scheme 99

Scheme 99
Scheme 99

Scheme 100

Scheme 100
Scheme 100

Scheme 101

Scheme 101
Scheme 101
  1. Refer to «Battery Disconnect and Connect»(ref-568400-S03532047432013072200000) information.
  2. Refer to «Cowl Vent Screen»(ref-568406-S32289223332013072200000) information.
  3. Refer to «Secondary Bulkhead Panel LH»(ref-568406-S25565044692013072200000) information.
  4. Torque: 25 Nm
  5. Torque: 25 Nm
  6. Torque: 8 Nm
  7. Torque: 6 Nm
  8. Torque: 10 Nm
  1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

Scheme 102

Scheme 102: REMOVAL
Scheme 102: REMOVAL
  1. Raise and support the vehicle.
  2. Refer to «Engine Cover - 5.0L, Vehicles With: Supercharger»(ref-568405) information.
  3. Refer to «Cooling System Draining and Vacuum Filling - Vehicles With: Supercharger»(ref-568464) information.
  4. Refer to «Secondary Bulkhead Center Panel»(ref-568406-S23451519502013072200000) information.
  5. Lift the tang and rotate the engine coolant temperature (ECT) sensor counter-clockwise.
  1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

Scheme 103

Scheme 103: REMOVAL
Scheme 103: REMOVAL
  1. Raise and support the vehicle.
  2. Refer to «Air Deflector»(ref-568406-S42840487662013072200000) information.
  3. Refer to «Engine Oil Draining and Filling»(ref-568453) information.
  4. Torque: 11 Nm
  1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

Scheme 104

Scheme 104: REMOVAL
Scheme 104: REMOVAL
  1. Refer to «Battery Disconnect and Connect»(ref-568400-S03532047432013072200000) information.
  2. Raise and support the vehicle.
  3. Refer to «Supercharger»(ref-568408-S33649561512013072200000) information.
  4. Torque: 20 Nm
  1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

Scheme 105

Scheme 105: REMOVAL
Scheme 105: REMOVAL
  1. Refer to «Battery Disconnect and Connect»(ref-568400-S03532047432013072200000) information.
  2. Raise and support the vehicle.
  3. Refer to «Supercharger»(ref-568408-S33649561512013072200000) information.
  4. Torque: 20 Nm
  1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

Scheme 106

Scheme 106: REMOVAL
Scheme 106: REMOVAL
  1. Refer to «Fuel System Pressure Release - 5.0L»(ref-568404) information.
  2. Disconnect the battery ground cable. Refer to «Battery Disconnect and Connect»(ref-568400-S03532047432013072200000) information.
  3. Refer to «Cowl Vent Screen»(ref-568406-S32289223332013072200000) information.
  4. Refer to «Secondary Bulkhead Panel RH - 5.0L/3.0L Diesel»(ref-568406-S22586568902013072200000) information.
  5. Refer to «Secondary Bulkhead Panel LH - 5.0L/3.0L Diesel»(ref-568406-S25565044692013072200000) information.
  6. Refer to «Engine Cover - 5.0L»(ref-568405-S41842828132013072200000) information.
  7. Torque: 32 Nm
  1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

Scheme 107

Scheme 107: REMOVAL
Scheme 107: REMOVAL

Scheme 108

Scheme 108
Scheme 108
  1. Refer to «Battery Disconnect and Connect»(ref-568400-S03532047432013072200000) information.
  2. Raise and support the vehicle.
  3. Refer to «Air Deflector»(ref-568406-S42840487662013072200000) information.
  4. Refer to «Catalytic Converter LH»(ref-568457-S11704519152013072200000) information.
  5. Wrench, H02S (310-121) Torque: 48 Nm
  1. To install, reverse the removal procedure.
  2. If required, carry out a long drive cycle. Refer to «Powertrain Control Module (PCM) Long Drive Cycle Self-Test»(ref-568420-S37791637132013072200000) information.

Note. Removal steps in this procedure may contain installation details.

Scheme 109

Scheme 109: REMOVAL
Scheme 109: REMOVAL

Scheme 110

Scheme 110
Scheme 110
  1. Refer to «Battery Disconnect and Connect»(ref-568400-S03532047432013072200000) information.
  2. Raise and support the vehicle.
  3. Refer to «Air Deflector»(ref-568406-S42840487662013072200000) information.
  4. Refer to «Catalytic Converter RH»(ref-568457-S03385691802013072200000) information.
  5. Wrench, H02S (310-121) Torque: 48 Nm
  1. To install, reverse the removal procedure.
  2. If required, carry out a long drive cycle. Refer to «Powertrain Control Module (PCM) Long Drive Cycle Self-Test»(ref-568420-S37791637132013072200000) information.

Note. Removal steps in this procedure may contain installation details.

Scheme 111

Scheme 111: REMOVAL
Scheme 111: REMOVAL

Scheme 112

Scheme 112
Scheme 112

Scheme 113

Scheme 113
Scheme 113

Scheme 114

Scheme 114
Scheme 114

Scheme 115

Scheme 115
Scheme 115
  1. Refer to «Engine Cover - 5.0L»(ref-568405-S41842828132013072200000) information.
  2. Refer to «Cowl Vent Screen»(ref-568406-S32289223332013072200000) information.
  3. Torque: 10 Nm
  4. Torque: 10 Nm
  5. Torque: 5 Nm
  1. To install, reverse the removal procedure.
  2. If required, carry out a short drive cycle. Refer to «Powertrain Control Module (PCM) Short Drive Cycle Self-Test»(ref-568420-S05827087332013072200000) information.

Note. Removal steps in this procedure may contain installation details.

Scheme 116

Scheme 116: REMOVAL
Scheme 116: REMOVAL
  1. Refer to «Battery Disconnect and Connect»(ref-568400-S03532047432013072200000) information.
  1. To install, reverse the removal procedure.
  2. If required, carry out a short drive cycle. Refer to «Powertrain Control Module (PCM) Short Drive Cycle Self-Test»(ref-568420-S05827087332013072200000) information.

Note. Removal steps in this procedure may contain installation details.

Scheme 117

Scheme 117: REMOVAL
Scheme 117: REMOVAL
  1. Refer to «Battery Disconnect and Connect»(ref-568400-S03532047432013072200000) information.
  2. Raise and support the vehicle.
  3. Refer to «Supercharger»(ref-568408-S33649561512013072200000) information.
  4. Torque: 20 Nm
  1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

Scheme 118

Scheme 118: REMOVAL
Scheme 118: REMOVAL
  1. Refer to «Battery Disconnect and Connect»(ref-568400-S03532047432013072200000) information.
  2. Raise and support the vehicle.
  3. Refer to «Supercharger»(ref-568408-S33649561512013072200000) information.
  4. Torque: 20 Nm
  1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

Scheme 119

Scheme 119: REMOVAL
Scheme 119: REMOVAL

Scheme 120

Scheme 120
Scheme 120
  1. Disconnect the battery ground cable. Refer to «Specifications»(ref-568476) information.
  2. Raise and support the vehicle.
  3. Thermostat Housing Refer to: «Thermostat Housing V8 S/C 5.0L Petrol»(ref-568454-S07823677632013072200000)
  4. Torque: 10 Nm
  1. To install, reverse the removal procedure.
  2. If required, carry out a short drive cycle. Refer to «Powertrain Control Module (PCM) Short Drive Cycle Self-Test»(ref-568420-S05827087332013072200000) information.

Note. Removal steps in this procedure may contain installation details.

Scheme 121

Scheme 121: REMOVAL
Scheme 121: REMOVAL

Scheme 122

Scheme 122
Scheme 122

Scheme 123

Scheme 123
Scheme 123
  1. Disconnect the battery ground cable. Refer to «Specifications»(ref-568476) information.
  2. Raise and support the vehicle.
  3. Thermostat Housing Refer to: «Thermostat Housing V8 S/C 5.0L Petrol»(ref-568454-S07823677632013072200000)
  4. Torque: 10 Nm
  1. To install, reverse the removal procedure.
  2. If required, carry out a short drive cycle. Refer to «Powertrain Control Module (PCM) Short Drive Cycle Self-Test»(ref-568420-S05827087332013072200000) information.
