Electronic Engine Controls (2.0L DIESEL/2.2L Diesel): Specifications Jaguar X-type I рестайлинг

Engine Control Systems 1 illustration ~619 words

Specifications

DescriptionNm
Camshaft position sensor retaining bolt9
Crankshaft position sensor retaining bolt7
Cylinder head temperature sensor10
Power steering pump belt cover retaining nut10
Engine oil pressure sensor15
Fuel temperature sensor15
Knock sensor20
Fuel injection supply manifold high pressure pipe retaining nut10
Manifold absolute pressure and temperature sensor retaining clips4
Radiator support bar retaining bolts25
Charge air cooler upper hose retaining clip4
Charge air cooler lower hose retaining clip4

Torque Specifications

Scheme 33

Scheme 33: Electronic Engine Controls - Description & Operation
Item NumberDescription
1Camshaft position (CMP) sensor
2Engine control module (ECM)
3Cylinder head temperature (CHT) sensor
4Crankshaft position (CKP) sensor
5Mass airflow (MAF) sensor
6Fuel temperature sensor
7Engine oil pressure (EOP) sensor
8Knock (KS) sensor
9Manifold absolute pressure and temperature (MAP-T) sensor

Camshaft Position (CMP) Sensor

The camshaft position (CMP) sensor is located on the front of the cylinder head and it is a hall effect type sensor. The CMP sensor takes its signal from the inlet camshaft lobe. The signal is used to identify cylinder number three and thus allowing the individual cylinders to be identified. Should the CMP sensor fail the engine will not start.

Engine Control Module (ECM)

The engine control module (ECM) is located in the same position as the petrol version. The engine management system (EMS) uses signals from the various sensors as inputs to the ECM which contains a series of maps for the engine parameters. Based on the inputs from the sensors regarding current engine conditions and loads, the ECM determines the optimum settings to use for the EMS, and so gives the best performance and/or economy for a given set of conditions. The ECM also manages the speed control system, again based on information from the vehicle sensors to provide the optimum settings.

Cylinder Head Temperature (CHT) Sensor

The cylinder head temperature (CHT) sensor is located at the rear of the engine behind the rear end accessory drive camshaft pulley. The CHT sensor measures the temperature of the cylinder head and then provides the ECM and the instrument cluster with the engine temperature.

Crankshaft Position (CKP) Sensor

The crankshaft position (CKP) sensor is located at the rear of the engine mounted to the cylinder block. It is used to detect the engine position and speed of the crankshaft. It is a permanent inductive type sensor. Should the CKP sensor fail, the engine will not start.

Mass Airflow (MAF) Sensor

The mass airflow (MAF) sensor is mounted on the clean air side of the air filter and upstream of the turbocharger air compressor. The function of the MAF sensor is to measure the amount of air flow drawn into the engine. This airflow is used by the ECM to control the exhaust gas recirculation (EGR) operation.

Engine Oil Pressure (EOP) Sensor

The engine oil pressure (EOP) sensor is located on the left-hand side of the engine in the oil filter housing. The EOP is connected to the instrument cluster and is not directly part of the electronic engine control system.

Knock Sensor (KS)

The knock sensor (KS) is located on the left-hand side of the engine mounted on the cylinder head between cylinders two and three. The KS allows the ECM to analyze the quality of combustion by measuring the increase in vibration. The ECM will use this signal to calculate the quantity of fuel to be injected during phased injection. The correction to the fueling for the phased injection minimizes the combustion noise. Should the KS fail the result would be no phased injection and thus an increase in diesel knock when idling and accelerating.

Manifold Absolute Pressure and Temperature (MAP-T) Sensor

The manifold absolute pressure and temperature (MAP-T) sensor combines the manifold pressure sensor and inlet air temperature sensor in one component. It is located in the inlet boost pressure pipe, right side front after the charge air cooler. Its function and operation is to measure the positive charge pressure developed by the turbocharger and its temperature, and to inform the ECM.

Fuel Temperature Sensor

The fuel temperature sensor can be identified by a blue connector located in the low pressure fuel supply circuit on the back of the high pressure pump. The fuel temperature sensor is a negative thermal coefficient type sensor which measures the fuel temperature in the low pressure circuit. Should the fuel temperature sensor fail the cold running characteristic will be affected.
