Specifications
| Description | Specification |
|---|---|
| High-temperature grease | ESD-M1C220-A |
| Metal surface cleaner | WSW-M5B392-A |
| Sealant | WSS-M4G323-A6 |
Lubricant, Sealers and Solvents
| CAUTION | Use only WSS-M2C922-A1 automatic transmission fluid. Use of any other fluids may result in a transmission malfunction or failure. |
| Intervals | |
|---|---|
| Normal Maintenance | Not necessary. Filled for life. |
| Severe Duty Maintenance | Change the fluid at 48,000 km (30,000 miles) intervals. |
Fluid Maintenance
| Engine | Approximate Liters | Refill Capacity Approximate dry capacity, includes cooler and tubes. Check the level at normal operating temperature. DO NOT OVERFILL. If it is necessary to add or change fluid, use only fluid which has been certified by the supplier as meeting the Jaguar Cars Ltd. specification shown. U.S. Quarts | Fluid Type |
|---|---|---|---|
| 2.0L, 2.5L and 3.0L | 8.8 | 8.32 | WSS-M2C9 22-A1 |
General Specifications
| Description | Nm |
|---|---|
| Main control valve body screws | 8 |
| Torque converter access cover retaining bolts | 10 |
| Torque converter retaining bolts | 55 |
| Transaxle retaining bolts | 48 |
| Transaxle dust cover retaining bolt | 10 |
| Solenoid retaining bolt | 8 |
| Transaxle support insulator retaining nut | 133 |
| Transaxle mount bracket retaining bolts | 80 |
| Transmission control module retaining nuts | 10 |
| Transmission fluid drain plug | 45 |
| Transmission fluid level plug | 15 |
| Transmission mount to body retaining bolts | 80 |
| Transmission range sensor retaining bolts | 10 |
| Valve body cover retaining bolts | 8 |
| Starter motor retaining bolts | 35 |
| Starter motor solenoid electrical connector retaining nut | 6 |
| Starter motor electrical connector retaining nut | 12 |
| Wiring harness to camshaft cover retaining stud, retaining nut | 6 |
| Intake manifold support bracket retaining bolts | 10 |
| Air cleaner mount bracket retaining nuts and bolt | 6 |
| Left-hand driveshaft retaining nuts - vehicles with 2.0L and 2.0L diesel engine | 25 |
| Shock absorber and spring assembly securing nuts | 25 |
| Transaxle ground lead | 25 |
| Support bar retaining bolts | 25 |
Scheme 1
Pinpoint Test N: P0743. TORQUE CONVERTER CLUTCH SOLENOID MALFUNCTION
Pinpoint Test N
N1
CHECK THE TORQUE CONVERTER CLUTCH SOLENOID GROUND CIRCUIT.
- Disconnect the transmission electrical connector, JB155.
- Measure the resistance between JB155, pin 18 (B) and GROUND.
Is the resistance greater than 5 ohms?
N2
CHECK THE TORQUE CONVERTER CLUTCH SOLENOID RESISTANCE.
- Measure the resistance between JB155, pin 17 and pin 18 at the transmission.
Is the resistance 12.6 ohms?
YES Go to step 4 . → N4
NO INSTALL a new TCC solenoid. CLEAR the DTC and TEST the system for normal operation.
N3
CHECK THE TORQUE CONVERTER CLUTCH SOLENOID GROUND WIRE FOR CONTINUITY.
- Disconnect the TCM electrical connector, JB131.
- Measure the resistance between JB155, pin 18 (B) and JB131, pin 17 (B).
Is the resistance greater than 5 ohms?
YES REPAIR the high resistance circuit. For additional information, refer to the appropriate SYSTEM WIRING DIAGRAMS article. CLEAR the DTC and TEST the system for normal operation.
NO Contact dealer technical support for advice on possible module failure.
N4
CHECK THE TORQUE CONVERTER CLUTCH SOLENOID SIGNAL WIRE FOR CONTINUITY.
- Measure the resistance between JB155, pin 17 (O) and JB131, pin 16 (O).
Is the resistance greater than 5 ohms?
YES REPAIR the high resistance circuit. For additional information, refer to the appropriate SYSTEM WIRING DIAGRAMS article. CLEAR the DTC and TEST the system for normal operation.
NO Contact dealer technical support for advice on possible module failure.
Torque Converter Service and Replacement - Assembly and Disassembly (Seal)
Special Tools Tool Illustration Tool Name Tool Number Link shaft oil seal installer 205-115
Scheme 2
Scheme 3
Scheme 4
Scheme 5
- Remove the transmission assembly. For additional information, refer to «Transaxle - Removal»(ref-311854-S20934752212009040700000) .
- Remove the torque converter. Drain any remaining fluid into a suitable container.
- Using a suitable tool, remove the torque converter seal.
- Clean and inspect the transmission housing seal face.
- Using the special tool, install a new torque converter seal.
- Install the torque converter.
- Install the transmission assembly. For additional information, refer to «Transaxle - Installation»(ref-311854-S36623732132009040700000) .
Transaxle - Installation
Special Tools Tool Illustration Tool Name Tool Number Halfshaft oil seal installer 205-115 Powertrain assembly jack HTJ1200-2 Engine support bracket 303-021 Engine support brackets 303-1068
