External Controls: Adjustments Jaguar X-type I

SELECTOR LEVER CABLE ADJUSTMENT

SETTING PROCEDURE-ALL VEHICLES

1. Apply the parking brake.
2. Apply the footbrake.
3. Turn the ignition switch to position II.
4. Move the gear selector lever to "N".
5. Raise and support the vehicle.
6. Remove the gear selector cover plate.
7. Loosen the gear selector cable retaining bolt.

VEHICLES BUILT UP TO VIN D15360

1. Using the corner of the grey feature line that follows the edge of the "J" gate as a datum, use a rule and move the gear selector forwards or back two millimeters.

Note. Before starting the "J" gate setting procedure, make sure the vehicle is cold, or has been left to cool for at least two hours.

ALL VEHICLES

1. Fully tighten the cable retaining bolt. Tighten to 5 N.m.
2. Install the gear selector cover plate. Tighten to 10 N.m.
3. Check for correct operation. If setting is incorrect, repeat the above steps until correct operation is achieved.

Scheme 125
