ON-BOARD DIAGNOSTICS
On Board Diagnostic (OBD) describes monitoring strategy and malfunction criteria for the JATCO transaxle systems.
DTC SUMMARIES
For additional DTC information, refer to the following
- For 2002-03 models, see POWERTRAIN DTC SUMMARIES article.
- For 2004-05 models, see «POWERTRAIN DTC SUMMARIES - ALL MODELS»(ref-171104) article.
DIAGNOSTIC STRATEGY
The complexity of the electronics involved with the automatic transmission/transaxle preclude the use of workshop general electrical test equipment. Therefore, reference should be made to the Jaguar approved diagnostic system for detailed instructions on testing the automatic transmission/transaxle.
Where a fault involving the automatic transmission/transaxle is indicated by the Jaguar approved diagnostic system, some basic diagnostic methods may be necessary to confirm that connections are good and that the wiring is not damaged, before installing new components.
- Verify the customer concern by operating the vehicle. Refer to the automatic transmission diagnostic drive cycle in the DTC summary section.
- Check the fluid levels and condition of the fluid.
- Check for non-factory fitted items.
- Check the «SELECTOR LEVER CABLE ADJUSTMENT»(ref-173250-S00574924162005031100000) .
- Visually inspect for obvious signs of mechanical, electrical or hydraulic damage.
Scheme 11
PINPOINT TEST
| PINPOINT TEST | DESCRIPTION |
|---|---|
| Pinpoint Test A: P1745 | Low Clutch Timing Solenoid Malfunction |
| Pinpoint Test B: P1746 | Reduction Timing Solenoid Malfunction |
| Pinpoint Test C: P1747 | 2/4 Brake Timing Solenoid Malfunction |
| Pinpoint Test D: P0706 | Transmission Range Sensor Malfunction |
| Pinpoint Test E: P1780 | D-4 Switch Malfunction (To VIN D15361) |
| Pinpoint Test F: P1793 | TCM Ignition Switched Power Malfunction |
| Pinpoint Test G: P0791 | Intermediate Speed Sensor Malfunction (Only Up To VIN C79328) |
| Pinpoint Test H: P0720 | Output Speed Sensor Malfunction (To VIN C79328) |
| Pinpoint Test I: P0715 | Turbine Speed Sensor Malfunction (To VIN C79328) |
| Pinpoint Test J: P0710 | Oil Temperature Sensor Malfunction |
| Pinpoint Test K: P0753 | Shift Solenoid A Malfunction |
| Pinpoint Test L: P0758 | Shift Solenoid B Malfunction |
| Pinpoint Test M: P0763 | Shift Solenoid C Malfunction |
| Pinpoint Test N: P0743 | Torque Converter Clutch Solenoid Malfunction |
| Pinpoint Test O: P0748 | Line Pressure Control Solenoid Malfunction |
| Pinpoint Test P: P0778 | 2/4 Brake Duty Pressure Control Solenoid Malfunction |
| Pinpoint Test Q: P1710 | Control Valve Solenoid Ground |
| Pinpoint Test R: P0915 | J-Gate Signal Inputs To The TCM |
| Pinpoint Test S: P0791 | Intermediate Speed Sensor Malfunction (From VIN C79329) |
| Pinpoint Test T: P0720 | Output Speed Sensor Malfunction (From VIN C79329) |
| Pinpoint Test U: P0715 | Turbine Speed Sensor Malfunction (From VIN C79329) |
PINPOINT TEST TABLE
