Specifications
| Description | Specification |
|---|---|
| Engine oil, SAE 5W-30 | WSS-M2C-912A |
| Engine assembly lubricant | SQM-2C9003 AA EP90 |
| Sealant | WSS M4G 320-A3 |
| Hose assembly surfactant | ESE-M99 B144-B |
Lubricants, Fluids, Sealers and Adhesives
| Description | Liters |
|---|---|
| Engine oil, initial fill | 7.0 |
| Engine oil, service fill with oil filter change | 6.5 |
Capacities
| Description | Nm |
|---|---|
| Accessory drive belt idler pulley retaining bolt | 25 |
| Accessory drive belt tensioner retaining bolt | 48 |
| A/C compressor retaining bolts | 25 |
| A/C compressor mounting bracket retaining bolts | 25 |
| A/C manifold retaining bolt | 20 |
| Camshaft bearing caps retaining bolts | A |
| Camshaft position sensor retaining bolt | 7 |
| Connecting rod cap retaining bolts | A |
| Coolant by-pass tube to cylinder head retaining bolts | 10 |
| Crankshaft position sensor retaining bolt | 10 |
| Crankshaft pulley retaining bolt | A |
| Cylinder head retaining bolts | A |
| Engine ground strap retaining bolt | 10 |
| Engine front cover retaining bolts | A |
| Engine mounting bracket retaining bolts | 40 |
| Engine mount bracket to engine mount retaining nuts | 55 |
| Engine mount retaining bolts to crossmember retaining nuts | 63 |
| Engine mount/oil filter housing retaining bolts | A |
| Engine wiring harness retaining bracket | 7 |
| Exhaust manifold heat shield retaining bolts | 10 |
| Exhaust manifold retaining studs | 9 |
| Exhaust manifold retaining nuts | A |
| Flywheel retaining bolts | 80 |
| Flexplate retaining bolts | 80 |
| Generator retaining bolts | 48 |
| Ignition coils retaining bolts | 7 |
| Knock sensor retaining bolts | 25 |
| Lower cylinder block retaining bolts | A |
| Lower intake manifold retaining bolts | A |
| Oil level indicator tube retaining bolt | 10 |
| Oil pan retaining bolts | A |
| Oil pan drain plug | 24 |
| Oil pressure sensor | 16 |
| Oil pump to engine block retaining bolts | 10 |
| Oil separator blanking plate | 10 |
| Oil temperature sensor | 14 |
| Power steering pump retaining bolts | 25 |
| Spark plugs | 15 |
| Timing chain guide retaining bolts | A |
| Timing chain tensioner retaining bolts | 25 |
| Upper intake manifold retaining bolts | A |
| Upper intake manifold support retaining bolts | 10 |
| Variable camshaft timing oil control unit retaining bolt | 40 + 90° |
| Valve cover studs and retaining bolts | A |
| Water pump retaining bolts | 25 |
| Wiring harness to valve cover retaining nuts | 10 |
| A = refer to the procedure for correct torque sequence |
Torque Specifications
Scheme 38
The 2.5 and 3.0 liter 24 valve V6 engine has four overhead camshafts and are driven by two timing chains. The engine incorporates electronic engine management with distributorless ignition system, sequential electronic fuel injection. It also has two catalytic converters in the exhaust system which includes two oxygen sensors and two catalytic monitor sensors.
Viewed from the driving position, the right-hand cylinder bank is numbered 1 to 3, from the front of the vehicle and the left-hand cylinder bank are numbered 4 to 6, from the front of the vehicle.
The engines include the following
- Vehicles fitted with 2.5L engine 10.3:1 Compression ratio.
- Vehicles fitted with 3.0L engine 10.5:1 Compression ratio.
- 3 Stage variable geometry intake manifold.
- Lightweight valve gear.
- Unique camshaft lift and duration.
- Twin knock sensor engine management control.
- Fully variable camshaft timing (VCT) system.
- Twin mass flywheel (manual transmission).
