Engine Controls - Basic Diagnostic Procedures: Other Isuzu Oasis I

Testing & Diagnostics 3 illustrations ~724 words

Compression

Check engine mechanical condition with a compression gauge, vacuum gauge, or an engine analyzer. See engine analyzer manufacturer's manual for specific instructions.

WARNINGDO NOT use ignition switch during compression test. Use a remote starter to crank engine. Fuel injectors on many models are triggered by ignition switch during cranking mode, which can create a fire hazard, contaminate the engine's oiling system or cause damage to catalytic converter.

Check compression pressure with engine at normal operating temperature, all spark plugs removed, throttle valves wide open and at specified cranking speed. Crank engine at least 6 revolutions to determine engine compression. See ENGINE COMPRESSION .

ModelStandard psi (kPa)Minimum psi (kPa)Minimum (2) RPM
Accord
2.3L178 (1230)135 (930)200
3.0L178 (1230)135 (930)200
Civic184 (1270)135 (930)250
CR-V220 (1520)135 (930)250
Oasis & Odyssey242 (1670)135 (930)200
Prelude185 (1270)135 (930)250
(1) Maximum variation between cylinders is 28 psi (2.0 kg/cm 2 ). (2) RPM with throttle held wide open.
(1)Maximum variation between cylinders is 28 psi (2.0 kg/cm 2 ).
(2)RPM with throttle held wide open.

ENGINE COMPRESSION (1)

Exhaust System Backpressure

Exhaust system can be checked using a vacuum or pressure gauge. Remove front (primary) heated oxygen sensor (HO2S). Connect a 0-5 psi pressure gauge, and run engine at 2500 RPM. If exhaust system backpressure exceeds 2 psi (12-14 kPa), exhaust system or catalytic converter is plugged.

If using a vacuum gauge, connect vacuum gauge hose to intake manifold vacuum port and start engine. Observe vacuum gauge. Open throttle part way and hold steady. If vacuum slowly drops after stabilizing, check exhaust system for restrictions.

FUEL SYSTEM

WARNINGAlways relieve fuel pressure before disconnecting any fuel injection-related component. DO NOT allow fuel to contact engine or electrical components.

Civic, CR-V, Oasis, Odyssey & Prelude

Remove negative battery terminal. Remove fuel tank filler cap. Locate 12-mm sealing nut at end of fuel rail. Place clean shop rag around sealing nut and slowly loosen nut one complete turn. Replace copper washers on sealing nut before re-tightening.

FUEL PRESSURE

Note. If vehicle starts and runs, fuel pump main relay is okay.

Spark

Check for spark at secondary coil wire and each spark plug wire using a spark tester. Check spark plug wire resistance on suspect wires. Resistance should be less than 25,000 ohms at 68°F (20°C).

Scheme 9

Scheme 9: Ignition Coil Resistance Test (External Coil)

Scheme 10

Scheme 10
  1. Turn ignition off. Remove Primary and secondary leads from ignition coil. Using an ohmmeter, check primary resistance between ignition coil connector terminals "A" and "B". (Scheme 9)and (Scheme 10). Resistance should be as specified. See «IGNITION COIL RESISTANCE»(ref-16344-S15674037622001010800000).
  2. Check secondary resistance between ignition coil connector terminal "A" and secondary output terminal (coil tower). See «IGNITION COIL RESISTANCE»(ref-16344-S15674037622001010800000). Check for continuity between terminals "A" and "C". Continuity should exist. If readings are not within specification, replace coil.

Scheme 11

Scheme 11: Ignition Coil Resistance Test (Internal Coil)
  1. Turn ignition off. Remove distributor cap. Remove primary leads from ignition coil. Using an ohmmeter, check primary resistance between ignition coil terminals "A+" and "B-". (Scheme 11) Resistance should be as specified. See «IGNITION COIL RESISTANCE»(ref-16344-S15674037622001010800000).
  2. Check secondary resistance between ignition coil terminal "A" (+) and secondary output terminal (coil tower). See «IGNITION COIL RESISTANCE»(ref-16344-S15674037622001010800000). If readings are not as specified, replace ignition coil. IGNITION COIL RESISTANCE - Ohms @ 68°F (20°C) Application Primary Secondary Accord 2.3L F23A1 Engine 0.45-0.55 16,800-25,200 F23A4 Engine 0.45-0.55 16,800-25,200 F23A5 Engine 0.63-0.77 12,800-19,200 3.0L J30A1 Engine 0.30-1.20 17,100-20,900 Civic Hitachi 0.45-0.55 22,400-33,600 TEC 0.63-0.77 12,800-19,200 CR-V 0.63-0.77 12,800-19,200 Oasis & Odyssey 0.40-0.60 22,400-33,600 Prelude 0.64-0.78 14,400-21,600

IGNITION CONTROL MODULE

Note. If MIL comes on, check for Diagnostic Trouble Codes (DTCs). See TESTS W/CODES - INTRODUCTION article. Before preforming IGNITION CONTROL MODULE INPUT TEST, ensure ignition, fuel and emissions systems are operating properly. Ignition Control Module (ICM) is located in distributor housing. see scheme 4- see scheme 10.

Note. Manufacturer does not provide tests for the ICM, they provide a series of input test to ensure the rest of the system is working properly before replacing components. If all tests check okay, the ICM should be replaced.

IDLE SPEED & IGNITION TIMING

Ensure idle speed and ignition timing are set to specification. See IDLE SPEED SPECIFICATIONS and IGNITION TIMING tables. For adjustment procedures, see ADJUSTMENTS article. Before checking or adjusting idle, ensure MIL has not been reported on, timing is correct, and that spark plugs, air cleaner and PCV system are okay.

IDLE SPEED & IDLE CO LEVELS

For further information on idle speed adjustments and specifications, see ADJUSTMENTS article.

ApplicationStep "A" RPMStep "B" RPM
Accord
2.3L650-750720-820
3.0L630-730630-730
Oasis & Odyssey650-750720-820
(1) For idle speed checking procedures see ADJUSTMENTS article.
(1)For idle speed checking procedures see ADJUSTMENTS article.

IDLE SPEED SPECIFICATIONS (ACCORD, OASIS & ODYSSEY) (1)

Step "A" RPMStep "B" RPMStep "C" RPM
650-750650-750760-860
(1) For idle speed checking procedures see ADJUSTMENTS article.
(1)For idle speed checking procedures see ADJUSTMENTS article.

IDLE SPEED SPECIFICATIONS (CIVIC D16Y5 ENGINE CVT) (1)

Step "A" RPMStep "B" RPMStep "C" RPMStep "D" RPM
400-500 (2)620-720 (2)700-800 (2)(2) 760-860
430-530 (3)700-800 (3)700-800 (3)(3) 730-830
(1) For idle speed checking procedures see ADJUSTMENTS article. (2) Civic D16Y5 engine with M/T. (3) CR-V.
(1)For idle speed checking procedures see ADJUSTMENTS article.
(2)Civic D16Y5 engine with M/T.
(3)CR-V.

IDLE SPEED SPECIFICATIONS (CIVIC D16Y5 ENGINE M/T & CR-V) (1)

Application RPMStep "A" RPMStep "B" RPM
D16Y7 A/T & D16Y8 (2)650-750760-860
D16Y7 M/T (2)620-720760-860
D16Y7 & D16Y8 (3)700-800760-860
(1) For idle speed checking procedures see ADJUSTMENTS article. (2) USA. (3) Canadian.
(1)For idle speed checking procedures see ADJUSTMENTS article.
(2)USA.
(3)Canadian.

IDLE SPEED SPECIFICATIONS (CIVIC D16Y8 A/T & D16Y7 ENGINES) (1)

Step "A" RPMStep "B" RPMStep "C" RPMStep "D" RPM
400-500(2)700-800760-860
(1) For idle speed checking procedures see ADJUSTMENTS article. (2) Idle speed should be 620-720 RPM on USA models or 700-800 RPM on Canadian models.
(1)For idle speed checking procedures see ADJUSTMENTS article.
(2)Idle speed should be 620-720 RPM on USA models or 700-800 RPM on Canadian models.

IDLE SPEED SPECIFICATIONS (CIVIC D16Y8 ENGINE M/T) (1)

Step "A" RPMStep "B" RPMStep "C" RPMStep "D" RPM
500-600650-750740-840740-840
(1) For idle speed checking procedures see ADJUSTMENTS article.
(1)For idle speed checking procedures see ADJUSTMENTS article.

IDLE SPEED SPECIFICATIONS (PRELUDE) (1)

ApplicationCO Level
All Models0.1%

IDLE CO LEVEL

FAST IDLE SPEED

ApplicationRPM
Accord
2.3L1350-1450
3.0L(2)
Civic(2)
CR-V1300-1700
Oasis & Odyssey1100-1500
Prelude1200-1600
(1) Transmission in Neutral or Park. (2) Information not available from manufacturer.
(1)Transmission in Neutral or Park.
(2)Information not available from manufacturer.

FAST IDLE SPEED SPECIFICATIONS (1)

ApplicationSpecification
Accord
2.3L10-14 @ 650-750
3.0L8-12 @ 630-730
Civic
A/T Or CVT(2) (3) 10-14 @ 650-750
M/T(2) (3) 10-14 @ 620-720
CR-V14-18 @ 700-800
Oasis & Odyssey10-14 @ 650-750
Prelude13-17 @ 650-750
(1) Check in no load condition (headlights, blower motor, rear defogger, A/C and cooling fan off) with M/T in neutral or A/T in Neutral or Park position. (2) Canadian 10-14 @ 700-800. (3) With SCS service connector (T/N 07PAZ-0010100 ) connected to 2-pin service check connector located under passenger side instrument panel.
(1)Check in no load condition (headlights, blower motor, rear defogger, A/C and cooling fan off) with M/T in neutral or A/T in Neutral or Park position.
(2)Canadian 10-14 @ 700-800.
(3)With SCS service connector (T/N 07PAZ-0010100 ) connected to 2-pin service check connector located under passenger side instrument panel.

IGNITION TIMING (Degrees BTDC - RED MARK @ RPM) (1)

SUMMARY

If no faults were found while performing BASIC TESTING proceed to TESTS W/CODES - INTRODUCTION article. If no hard codes are found in self-diagnostics, proceed to TESTS W/O CODES article for diagnosis by symptom (i.e., NO-START, LOW POWER, etc.), or intermittent diagnostic procedures.
