Starters: Removal & Installation Isuzu Axiom I

Removal

1. Disconnect battery ground cable.
2. Disconnect heated O2 Sensor connector (1).
3. Remove exhaust front left pipe (2). (Scheme 5)
4. Disconnect starter wiring connector from terminals "30" (1) and "50" (2).
5. Remove starter assembly mounting bolts on inside and outside (3).
6. Remove starter assembly (4) toward the bottom of engine. (Scheme 6)

Scheme 5

Scheme 6

Installation

1. Install starter assembly (4).
2. Install mounting bolts and tighten bolts (3). See «TORQUE SPECIFICATIONS»(ref-167897-S21964760152004102500000).
3. Reconnect the connectors to terminals "50" (2) and tighten terminals "30" (1). (Scheme 7)
4. Install exhaust front left pipe (2) and tighten bolts and nuts. See «TORQUE SPECIFICATIONS»(ref-167897-S14951368312004102500000).
5. Connect two heated O2 Sensor Connector (1). (Scheme 5)

Scheme 7

Note. For overhaul procedure, see exploded view of starter. (Scheme 8)

Scheme 8
