Starters: Overhaul Isuzu Axiom I

Disassembly

1. Remove the lead wire (1) from the magnetic switch.
2. Remove the through bolts (2). (Scheme 9)
3. Remove the yoke from the magnetic.
4. Remove the yoke cover. (Scheme 10)
5. Use the long nose pliers to remove the brush and brush holder. (Scheme 11)
6. Remove the armature.
7. Remove the housing.
8. Remove the overrunning clutch from the housing. (Scheme 12)
9. Remove the return spring from the magnetic switch. (Scheme 13)
10. Remove the steel ball from the overrunning clutch. (Scheme 14)
11. Remove the idle pinion from the magnetic switch. (Scheme 15)
12. Remove the retainer from the magnetic switch. (Scheme 15)
13. Remove the magnetic switch.

Scheme 9

Scheme 10

Scheme 11

Scheme 12

Scheme 13

Scheme 14

Scheme 15

Reassembly

To install, apply removal steps in the reverse order. Lubricate the following points

1. Bearing in rear cover
2. Gears in reduction gear
3. Sliding portion of pinion
