Automatic Drive Positioner: Overview Infiniti M45 II

Manual Operation

The driving position (seat position, steering wheel position, door mirror position) can be adjusted with the power seat switch or ADP (Automatic Drive Positioned) steering switch.

Note. The seat and steering wheel position can be manually operated with the ignition switch OFF. The door mirrors can be manually operated with the ignition switch in either ACC or ON.

Automatic Operation

Note. Disconnecting the battery erases the stored memory. After connecting the battery, insert the key into the ignition cylinder and turn the driver door switch ON (open)-->OFF (close)-->ON (open), the Entry / Exiting function becomes possible.

Scheme 1

Scheme 2

Note. During automatic operation, if the ignition switch is turned ON-->START, the automatic operation is suspended. When the ignition switch returns to ON, it resumes.

System Description

1. The system automatically moves the driver seat and steering wheel to facilitate entry/exit to/from the vehicle by connecting the BCM (Body Control Module) to the driver seat control unit the multiple communication line. The BCM can also store the optimum driving positions (driver seat, steering wheel and door mirror position) for 2 people. If the driver is changes, one-touch operation allows changing to the other driving position.
2. The settings (ON/OFF) of the automatic tilt steering wheel and sliding seat (Entry/exiting function) at entry/exit can be changed as desired, using the display unit in the center of the instrument panel.

RETURN OPERATION

When the seat and steering wheel are on the turnout positions, the following operation moves the seat and steering wheel to the previous position before the turnout operation.

Scheme 3

Note. The seat sliding, steering wheel tilt, and telescoping return to the original positions simultaneously.

TURNOUT OPERATION

At exit, the seat and steering wheel are automatically moved to the turnout position.

Scheme 4

1. Seat: moves backward.
2. Steering wheel: tilted upward and extended fully.

Note. The seat sliding, steering wheel tilt, and telescoping are moved to the turnout position simultaneously.

Scheme 5

Scheme 6

Scheme 7

Operation Procedure

1. Touch "IVMS-COMM CHECK" on "SELECT TEST ITEM".
2. Touch "IVMS-COMM DIAGNOSIS" on the "SELECT DIAG ITEM" screen.
3. Touch "START" on the "IVMS-COMM DIAGNOSIS" screen to start the diagnosis.
4. After the diagnosis is completed, the malfunctioning system name is displayed.
5. When the malfunctioning items are displayed, touch "PRINT" to keep the records.
6. Touch "ERASE".
7. Carry out the communication inspection again to check that any malfunctioning item is displayed.
8. Check the displayed items.

1. Touch "IVMS-COMM CHECK" on the "SELECT TEST ITEM" screen.
2. Touch "WAKE-UP DIAGNOSIS" on the "SELECT DIAG ITEM" screen.
3. Touch "START" on the "WAKE-UP DIAGNOSIS" screen to start the diagnosis.
4. Touch "NEXT" to select the local control unit (LCU) to be diagnosed.
5. Check that any malfunction is displayed. If necessary, touch "PRINT" to keep the record.
6. Carry out the inspection of the malfunctioning item.

Scheme 8

Note. For a specific local control unit (LCU), either "PAST COMM DATA" or "PAST NO RESPONSE" may be displayed instead of the above results. The data record, causes this, so erase the records. (The display only shows the incident records, they are not malfunctions caused during the diagnosis. One possible cause is that an intermittent incident occurred.) Follow the steps below to erase the memory. Carry out either disconnect BCM battery power supply or erase memory with CONSULT-II. With the battery connected, if the local control unit (LCU) connector is disconnected and left for approximately 1 minute, the BCM stores "NO RESPONSE" record.
