CHECKING BLOWER

  1. Press fan switch (up side) one time. Blower should operate on low speed. The fan symbol should have one blade lit.
  2. Press fan switch (up side) one more time, and continue checking blower speed and fan symbol until all speeds are checked.
  3. Leave blower on MAX speed.

If NG, go to trouble diagnosis procedure for blower motor " BLOWER MOTOR CIRCUIT ".

Scheme 182

Scheme 182
Scheme 182

If OK, continue with next check.

Scheme 183

Scheme 183: CHECKING DISCHARGE AIR
Scheme 183: CHECKING DISCHARGE AIR

Scheme 184

Scheme 184
Scheme 184
  1. Press mode switch four times and DEF button.
  2. Each position indicator should change shape.
  3. Confirm that discharge air comes out according to the air distribution table. Refer to Discharge Air Flow " «DISCHARGE AIR FLOW»(ref-181236-S18308730682005080100000) ".

Intake door position is checked in the next step.

If NG, go to trouble diagnosis procedure for intake door motor " INTAKE DOOR MOTOR CIRCUIT ".

If OK, continue with next check.

Note. Confirm that the compressor clutch is engaged (visual inspection) and intake door position is at FRESH when the DEF is selected.
